Extended Environments – typically outdoors:
These environments are characterized by temperatures either below or above that of the moderate
environment, and / or where the machine is exposed to additional weather elements. We recommend a
properly equipped Rear Load model changer for these locations. Whenever possible, we highly
recommend the rear load changer be placed in an area that minimizes the machine's exposure to excessive
dust/dirt, direct sunlight, and/or direct rainfall. A canopy or other cover, that protects the machine from
direct exposure to sunlight and the elements, is strongly recommended. This simple precaution will not
only reduce maintenance issues for the changer's major operating components; it will also increase the
potential operating life of the machine.
o
o
For climates that see sustained temperatures below the previously defined moderate levels (0
C / 32
F),
an optional Heater Kit is strongly recommended. For climates that see sustained temperatures above the
o
o
previously defined moderate levels (41
C / 106
F), the optional Outdoor Rated Power Supply is strongly
recommended.
The Outdoor Rated Power Supply will continue to function properly when exposed to temperatures up to
o
o
60
C (140
F). Therefore, it is strongly recommended for regions in the Southern and Southwestern United
States.
1.14 Bill Acceptor Considerations
The performance and life of the bill acceptor supplied with your machine is limited to the particular
manufacturers' specifications. See the Bill Acceptor owners' manual for the recommended operating
specifications.
o
o
o
o
NOTE: Most OEM bill acceptors are specified to operate properly between 0
C (32
F) and 50
C (122
F) ambient temperature. These conditions meet our recommended specifications for a moderate
environment application. If the precautions, outlined above, for extended environment applications are
met, we do not anticipate any adverse operating conditions associated with OEM bill acceptors.
1.15 Bill Dispenser Considerations
The performance and life of the bill dispenser supplied with your machine is limited to the particular
manufacturers' specifications. Most bill dispensers will perform more reliably in environments that have
o
o
o
o
low humidity and are operated between a 0
C (32
F) and 50
C (122
F) ambient temperature. A cabinet
heating kit will help keep the humidity level low during daily temperature transitions (night to day when
humidity can increase rapidly) and seasonal changes.
2.0 INSTALLATION DETAILS
2.1 Cabinet Installation Instructions
(REFER TO MANUAL: #8M00356 Modular Series Machine Installation Manual on our web site)
Standard Change-Makers manufactures change machines in the following cabinet styles: 1) Free standing
consoles, 2) Front loading wall mount, 3) Through-the-wall rear load and 4) Slim-line vending changer.
Because physical locations vary, we do not suggest an exact method of installation. To assure proper
operation of your changer the following general guidelines should be observed:
16
