- Page 1 I N S T R U C T I O N M A N U A L A S A - H V 5 0 Extraction arm for high vacuum www.geovent.com Version 1.0 30.01.17...
- Page 3 Contents Art. No. Description 74-480 ASA-HV50 Arm for High Vacuum 2 m. ø50 1.0 General safety precautions 1.1 Danger 74-481 ASA-HV50 Arm for High Vacuum 3 m. ø50 1.2 Field of application 74-482 ASA-HV50 Arm for High Vacuum 4 m. ø50 1.3 Handling...
- Page 4 Arms and friction joint: 25x25 mm aluminium pipe, connected via knee joints with friction discs and disc Alu centerfork springs. The inner reinforced arm is executed in 30x30 Ø114 mm electro galvanised steel pipe and supplied with a friction discs gas damper.
- Page 5 Recommended installation height HV50 arm: 2500 Procedure: 1. The wall bracket is firmly attached to the wall by means of 4 off 10 mm bolts. (When using the exten- sion arm, please fix this bracket first – refer to item 2.1) 2.
- Page 6 Wear parts like hoses, etc. are not included in the war- ranty. User liability In order for Geovent to be capable of granting the decla- red warranty, the user/fitter must follow this Instruction Manual in all respects. Under no circumstances may the products be changed in any way, without prior written agreement with Ge- ovent A/S.
- Page 7 6.0 Declaration of conformity 6 . 0 E F - HOVEDGADEN 86 • DK-8831 LØGSTRUP (+45) 8664 2211 • salg@geovent.dk Hereby declares that: Date: 30/01-17 The product: Extraction Arms Position: Managing Director Models: ASA-HV50 Namn: Thomas Molsen have been manufactured in compliance with the directi-...
- Page 8 HOVEDGADEN 86 • DK-8831 LØGSTRUP (+45) 8664 2211 • salg@geovent.dk...
