3.3 ComPleting the inStallation / tranSfer to the Client

• Clear site. Remove packaging materials from site and dispose according to local regulations.
• Hand over to client all instructions concerning the installation and operation of the awning as well as the instructions for the
electrical connections of control units and switches.
Give client comprehensive instructions about the operation of the awning. Failure to observe the instructions and incorrect
operation can result in damages to the awning and accidents.
Notify client of the wind resistance class of the awning.
4. diSmounting
Ensure that the area around the awning is free of unauthorized personnel. Shut off power to motor-driven awnings and
take steps to ensure they cannot be switched on again.
• Dismount the awning exclusively in retracted condition.
• Dismounting of the awning is the reverse of the mounting procedure.
5. troubleShooting
tyPe of fault
motor drive does not work
System does not extend or retract fully
awning makes grating noises
drop profile does not close exactly
System does not close on one side
www.helioscreen.com.au | Phone 1300 766 319
CauSe
No power
Motor drive not correctly connected
Thermal protection of the motor drive activated Wait for 15-20 mins, then operate again
Remote control batteries empty
Higher-level control unit prevents manual
operation
End positions of the motor drive changed, or
incorrect end position setting
Insufficient lubrication
Adjustment of the drop profile inaccurate
Fabric unevenly sewn
remedy
Check connection (specialized company)
Check connection (specialized company)
Check light signal on sending unit, replace
batteries
Wait until higher-level signal is not activated
any more.
Reset or re-program end positions (see motor
adjustment manual)
Spray arm articulation bearing with a suitable
lubricant (e.g. Teflon spray)
Adjust drop profile according to Item 3.2
Line covering on this side by applying fabric
tape to cloth roller
