1.2 general Safety information

The HELIOSCREEN RUBIX awning has been designed and manufactured in conformity with DIN EN 13561.
However, when the awning is mounted or operated, the persons involved in the respective activity may be put at risk
if the relevant instructions are not observed.
Only qualified and duly specialized companies or trained specialist personnel may be permitted to mount the awning.
Always observe the information and notes in the installation and operation instructions.
A failure to observe the relevant information will render the manufacturer's liability null and void.
The safety-at-work and accident prevention regulations specific to each country must be complied with. In particular, a
person performing special work at height must be suitably secured.
The notes on the product and its packaging must be observed.

2. inStallation

2.1 toolS and materialS
• Drill
• Drill bits, suitable for the drilling substrate and the mounting pieces
• SW 3, SW 5 and SW 10 Allen keys
• Ratchet with SW 17 socket
• SW 13 ring or fork spanner
• Spirit level and string for alignment
• String for alignment of the brackets
• Test cable, resp. adjustment set (for initial operation)

2.2 PreParing the inStallation

Transport the awning to the site of installation, ensuring that the orientation is correct.
Secure the installation zone (the secured zone must be at least equivalent to the size of the fully deployed awning). If
the awning is hoisted to higher installation positions with ropes, the awning must be removed from the packaging.
When attaching the hoisting ropes, ensure that the awning is properly fastened, but not damaged. Hoist the awning
exclusively in horizontal position and evenly.
Before commencing the installation, please verify whether the type and number of brackets is in conformity with the order and
whether the base material is the same as that stated on your order.
If significant differences make the safe installation of the awning seem doubtful, please consult the manufacturer of the system
and a mounting/installation specialist.
If the information above is not observed, the awning system may fall down and put the health of persons at risk!
www.helioscreen.com.au | Phone 1300 766 319 Helioscreen Rubix • INSTALLATION GUIDE | 3
