EXPERT MODE - IMPORTANT PARAMETERS ..............
Parameter Function
Selection control
function, DIN1
(terminal 5), fixed
frequency 5.
(P046)**
Selection control
function, DIN2
(terminal 6), fixed
frequency 4.
(P044)**
Selection control
function, DIN3
(terminal 7), fixed
frequency 3.
(P043)**
Selection control
function, DIN4
(terminal 8), fixed
frequency 2.
(P042)**
Selection control
function, DIN5
(terminal 16), fixed
frequency 1.
(P041)**
Selection control
function, DIN6
(terminal 17), fixed
frequency 6.
(P047)**
** Fixed frequency enabled when P051 to
P055 and P356 is set to 6 or 18.
should then be set to 2
Description/Notes
Range
(Default)
0-24
Value Function of P051
[01]
0 Input disabled
1 ON right
0-24
[10]
4 OFF2
5 OFF3
6 Fixed frequencies 1-
6
0-24
9 Start / stop
[6]
command selection
from keypad OR
digital terminals
(for USS
0-24
communications
[6]
operation P910 = 1
or 3)
10 Fault reset
0-24
11 Increase frequency*
[6]
12 Decrease frequency*
13 Switch between
analog input
frequency setting
0-24 and digital/keypad
frequency setting
[6]
14 Disable ability to
change parameters
18 Fixed frequencies 1-
6, but input high will
also request RUN
P006
when P007 = 0 See
P040 to P047
19 External trip
22 Download parameter
set 0 from OPe***
23 Download parameter
set 1 from OPe***
24 Switch analog
setpoint
* Only effective when P007 = 0.
*** The motor must be stopped before
downloading begins
Downloading takes approx. 30 seconds
Function,
to P055 and low state
P356 (0 V)
-
Off
OFF2
OFF3
Off
Local
keypad start
/ stop
Off
Off
Off
Analog
setpoint
P' enabled
Off
Off
Off
Off
Analog
input 1
active
Function,
high state
(>10V)
-
On right
On
On
On
Digital
terminal start
/ stop (or
USS
communi-
cation
control)
Reset on
rising edge
Increase
Decrease
Keypad /
Digital
setpoint
P' disabled
On
EM
On
Download
Download
Analog input
2 active
