  • Page 1 User’s manual 7IS-80395 06/03/2020...

  • Page 2: Table Of Contents

    General Notes ................. 4 Making the installation ..............4 DESCRIPTION .................. 5 Features ....................6 LED ......................7 GSM500 hardware description ..............8 3G hardware description ................9 INSTALLATION ................10 Installation recommendations ..............10 EU declaration of conformity ..............10 Inserting the SIM card ................
  • Page 3 Reading SIM card expiration ............32 Reading the battery status ............32 Activation relay ................33 SENDING SMS THROUGH DB-9 ..........34 Sending received SMS text messages............ 35 Sending SMS from device wired in the DB-9 connector ...... 36 DATA TRANSMISSION ..............37 FEMALE DB-9 CONNECTOR ............

  • Page 4: General Installation Instructions

     The product must be EXCLUSIVELY used for the purpose it was designed for. Esse-ti shall not be responsible for damages arising from improper use.  The product has been designed in compliance with the regulations in force and must be installed in systems that comply with the provisions of law.

  • Page 5: Description

    DESCRIPTION GSM500 GSM500 is a gateway that, connected to a fixed telephone or to the PSTN input terminals of a PABX or autodialer, allows you to make and receive calls over the GSM network. For correct operation, a GSM SIM card is required.

  • Page 6: Features

    Receiver and transmitter gain adjustment  Remote reboot function  Data transmission through standard RS-232, RS-485 and CAN-bus (only available on GSM500.net)  Data transmission through standard RS-232 and CAN-bus (optional RS-485; only available on 3G.next)  Incoming text messages transmission towards devices wired in the DB-9 connector under RS-232 standard (only available on GSM500.net and 3G.next)

  • Page 7: Led

    12 Vdc power supply input  230 Vac external adapter input  Female DB-9 connector (only available on GSM500.net and 3G.next)  Micro USB A/B port (optional, only available on 3G.next)  Relay output (1 A, 24 V; only available on models: R2R and 3G) ...

  • Page 8: Gsm500 Hardware Description

    GSM500 hardware description Remove the cover by pressing the upper side.  ANTENNA cable connector SIM CARD housing with front panel LED indicating signal strength (green), LED indicating device operation status (red), LED indicating line status / data transmission (white) and LED indicating power supply status (blue) Female DB-9 connector (.net models only)

  • Page 9: 3G Hardware Description

    3G hardware description Remove the cover by pressing the upper side.  Micro USB A/B port (optional, 3G.next) ANTENNA cable connector SIM CARD housing with front panel LED indicating signal strength (green), LED indicating device operation status (red), LED indicating line status / data transmission (white) and LED indicating power supply status (blue) Female DB-9 connector (3G.next) RS-485 termination jumper (3G.next)

  • Page 10: Installation

    (e.g. installation is not allowed in hospitals, airplanes, etc.). EU declaration of conformity Hereby, Esse-ti S.r.l. declares that the equipment type GSM500/3G.next is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available from the following Internet address: https://www.esse-ti.it/en/dichiarazioni-di-conformita...

  • Page 11: Inserting The Sim Card

    Inserting the SIM card Before inserting or replacing the SIM card, always make sure that the gateway has been disconnected from the mains and that no electrostatic discharge is present in order to avoid damaging it. Take all necessary measures to avoid electrostatic discharge. Shift the SIM card housing cover downward until it unblocks and ...

  • Page 12: Connection To The Telephone Line

    Connection to the telephone line Connect the gateway to a standard telephone or to the PSTN input  terminals of a PABX or autodialer via the RJ-11 connector (F in the picture at page 8 / H in the picture at page 9); Connect the gateway to a standard telephone or to the PSTN input ...

  • Page 13: Turning The Gateway On

    12 Vdc power supply Connect the power supply cable to the specific terminal (I in the  picture at page 8 / M in the picture at page 9) taking care to respect the polarity. Connect the backup batteries (if present) to the dedicated input (M ...

  • Page 14: Gateway Mounting Operations

    Gateway mounting operations Check the GSM/UMTS signal strength through the green indicator  LED (see chapter “SIGNALS”, page 42) and identify an area where the signal is strong enough. Note: the signal strength may vary according to the telephone provider. Drill two holes with 5 mm diameter on the wall at a distance of 50 ...

  • Page 15: Gsm500 Absorption Chart

    GSM500 absorption chart 10Vdc 12Vdc 13,8Vdc 10Vdc 12Vdc 13,8Vdc Power supply (battery not connected) (battery connected) Telephone 30mA 30mA 25mA 40mA 60mA 50mA handset down Telephone handset up 90mA 80mA 70mA 100mA 105mA 90mA Conversation 130mA 115mA 110mA 140mA 135mA...

  • Page 16: Programming

    PROGRAMMING Programming can be carried out locally via a multi-frequency telephone or remotely via SMS. ROGRAMMING BY TELEPHONE Connect a standard telephone to the gateway via the RJ-11  connector (F in the picture at page 8 / H in the picture at page 9) or using the TEL terminals (H in the picture at page 8 / L in the picture at page 9).
  • Page 17 PROGRAMMING BY TELEPHONE TELEPHONE LINE VOLTAGE X: option, from 0 to 1 (TEL terminals **61*X# 0= 36 Vdc and RJ-11 1= 52 Vdc connector) X: option, from 1 to 4 1= default 2= mode recommended for autodialers or other devices effecting tone detection over the line USE MODE **2X#...
  • Page 18 PROGRAMMING BY TELEPHONE **5*1# Enabling Disabling XXX: MCC of your telephone operator Y…Y: MNC of your telephone operator ROAMING **5*0*XXXY...Y# (when roaming is disabled, in case the gateway registers with a different provider than the programmed, it is not possible to make or receive any calls) Default: roaming enabled X…X: telephone number appointed for SMS...
  • Page 19 PROGRAMMING BY TELEPHONE X: option, from 0 to 1 **5X# 0= check enabled 1= check disabled X: option, from 0 to 7 0= 7 h 1= 6 h e 30’ 2= 6 h BATTERY 3= 5 h e 30’ CHECK 4= 4 h **52*X# 5= 2 h e 30’...
  • Page 20 PROGRAMMING BY TELEPHONE X: option, from 0 to 6 0= notifications disabled 1= the relay is deactivated in case of external power failure 2= the relay is deactivated in case of mobile RELAY-BASED network loss NOTIFICATION 3= the relay is deactivated in case of OF EXTERNAL external power failure or in case of POWER FAILURE...

  • Page 21: Sim Card Expiration Check

    VOICE CALLS rate) enabled with EFR preference CODEC SETTING **15*X# 1= EFR and HR enabled with HR preference (GSM500 only) 2= EFR enabled, HR disabled 3= FR enabled, HR disabled X…X: country calling code of the country **09*X…X# where the gateway is installed...

  • Page 22: Battery Check

    Battery check If the battery check is enabled, in case of power failure the gateway constantly checks the battery status. When the charge goes below the previously-programmed threshold ensuring the minimum number of operating hours in idle mode, a notification SMS is sent with the following text message: “Low battery”.

  • Page 23: Relay-Based Notification Of External Power Failure And/Or Mobile Network Loss

    If the external power supply is restored for a time interval equal to the preset threshold a new SMS will be sent with the following text message: “External power restored”. The external power failure control is only available on models: GC, R2R, .net and 3G.
  • Page 24 Example: preset this table Selected tel. number Preset tel. number Location (code 25) (code 26) 3331234567 0717506065 3339876543 0717506066 0733434343 0717506067 0733445566 0717506068 0733778899 0717506069 - when selecting tel. number 3331234567, the gateway will make a call to 0717506065 - when selecting number 3339876543 , the gateway will make a call to 0717506066 - etc - when selecting any number not included in the “Selected...
  • Page 25 If not, it will match the dialed number to the first available preset number and will make a call to it. In case there are not available preset numbers, but it’s still possible to make associations, the dialed number will be automatically matched with the first preset number.

  • Page 26: Programming Via Sms

    Programming outgoing SMS from the Internet may not be successful if the requested format is not respected. Message format The message format is required to be as follows for GSM500: ET-IG5*xxx#c..c# The message format is required to be as follows for 3G: ET-IU1*xxx#c..c#...
  • Page 27 Programming Code (x..x) Telephone line voltage 61*X Use mode Inter-digit dialling time Enabling CLIP 7*1*GGMMAA*HHMM Disabling CLIP CLIR permanent setting CLIR temporary activation CLIR temporary deactivation Enabling roaming service Disabling roaming service 5*0*XXXY…Y Setting telephone number for notification service 40*X…X*X…X Deleting notification number Setting administrator number 18*X…X*X…X...

  • Page 28: Notification Message Format

    The format of the message notifying the user or the administrator who previously sent out a programming SMS, is the same as the programming message format. SMS notifying an accepted command for GSM500: ET?IG5*xxx#c..c# SMS notifying a rejected command for GSM500: ET?IG5*xxx#c..cERR#...
  • Page 29 Example (GSM500): outgoing SMS to enable battery check and to set the following incoming notification number: 3330123456. Outgoing message text: ET-IG5*0#50#40*3330123456*3330123456# Message text notifying accepted command: ET?IG5*0#50#40*3330123456*3330123456# Example (3G): outgoing SMS to enable battery check and to set the following incoming notification number: 3330123456.

  • Page 30: Services

    SERVICES NCOMING CALLS Allows you to answer incoming calls. Upon receiving a phone call, the LED indicating the line status (white) will blink shortly 4 times every 4 seconds as described at chapter “SIGNALS” (see page 43) and the telephone will be ringing. Pick up the handset to answer the call.

  • Page 31: Measuring The Signal Level

    Note: in the event you receive the dissuasion tone picking up the handset, check if the signal is present and make sure the SIM card is working correctly. EASURING THE SIGNAL LEVEL This procedure allows you to check the GSM/UMTS signal level through your telephone.

  • Page 32: Reading Sim Card Expiration

    EADING CARD EXPIRATION This procedure allows you to check how many days until the SIM card expiration. Lift the handset and dial **54#.  After the confirmation tone hang up.  After receiving the request, the gateway will send an SMS to the number programmed for notifications.

  • Page 33: Activation Relay

    for notifications has not been previously entered or if the gateway is not correctly registered to the GSM/UMT network. CTIVATION RELAY Allows you to activate or deactivate the relay available in the R2R and 3G versions when it is not used to signal the external power supply and/or GSM/UMTS network failure.

  • Page 34: Sending Sms Through Db-9

    SENDING SMS THROUGH DB-9 GSM500.net and 3G.next allows to: - send received SMS text messages to devices wired in the DB-9 connector (in RS-232 standard); - send SMS text messages from devices wired in the DB-9 connector (in RS-232 or CAN-bus standard).

  • Page 35: Sending Received Sms Text Messages

    **71#X…X# Disabling Sending received SMS text messages The SMS received by GSM500.net (or by 3G.next) can be forwarded to devices wired in the DB-9 connector (in RS-232 standard). The format of incoming SMS is required to be as follows: &XXXXy…y where: &...

  • Page 36: Sending Sms From Device Wired In The Db-9 Connector

    CAN-bus standard), can be sent via SMS. text format transmitted by the external device GSM500.net/3G.next, through the DB-9 connector in RS-232 standard, is required to be as follows: SMSX…X:Y…Y<CTRL+Z> where: string start X…X telephone number on which the SMS must be sent Y...Y...

  • Page 37: Data Transmission

    DATA TRANSMISSION The COMNet system allows users to connect remotely with devices equipped with RS232/RS485/CAN BUS, replacing traditional serial communication which is commonly performed locally (i.e. between peripherals and custom boards – Fig. A – or between a PC-based proprietary application and a lift controller board – Fig. B –). Figure A: example of local serial communication Figure B: example of local serial communication Figure C: general example of remote serial communication...
  • Page 38 Setting up a COMNet system requires: - connecting a GSM500.net or a 3G.next gateway (properly programmed) to the serial port of the remote device to be controlled (the SIM card to be inserted into the gateway must be enabled for voice, SMS...
  • Page 39 Figure F: example of COMNet system with GSM500.net/3G.next used as gateway for voice transmission Please see the user manual of the COMNet for the data transmission programming of the GSM500.net/3G.next and for the installation and use of the COMNet PC client software.. Page 39...

  • Page 40: Female Db-9 Connector

    FEMALE DB-9 CONNECTOR RS-232 PIN2 PIN3 PIN5 RS-485 TXD- PIN6 TXD+ PIN7 PIN5 CAN-bus CANH PIN8 CANL PIN9 PIN5 Page 40...

  • Page 41: Signals

    SIGNALS ONES Dialling It indicates that the gateway is ready for dialing. Dissuasion It indicates that t he gateway has not properly registered with the GSM/UMTS delay in dialling or the end of conversation or an access to provider or a services not permitted.

  • Page 42: Call Signals

    Medium signal level. Good signal level. High signal level. No signal. ALL SIGNALS It indicates an incoming call. GSM/UMTS signal indicator LED (GREEN) No signal. Low signal level. Medium signal level. Good signal level. High signal level. Page 42...

  • Page 43: Status Indicator Led (Red)

    Status indicator LED (RED) Upon switch on, it indicates GSM/UMTS network login in progress; if it keeps blinking, it may indicate that the gateway has not been correctly registered with the network, the SIM card is protected by the PIN code or other problems.

  • Page 44: Power Supply Status Indicator Led (Blue)

    Power supply status indicator LED (BLUE) It indicates that the external power supply is connected. It indicates that the power supply is disconnected and the battery guarantees more than 7-hour operation in idle state. It indicates that the power supply is disconnected and the battery guarantees up to 7-hour operation in idle state.

  • Page 45: Problem-Detection Guide

    Check the SIM card damaged operation on your mobile phone SIM card not supported with Use a GSM SIM card GSM500 The red LED blinks Make a test with a SIM (e.g. UMTS or 4G) quickly card from a different GSM...
  • Page 46 During conversation Increase protection echo is heard echo-related occurrences by setting use mode 3 (or 4) by the programming “Use Mode” Page 46...
  • Page 47 Page 47...
  • Page 48 GSM500 / 3G.next 06/03/2020 Esse-ti s.r.l. Via G. Capodaglio, 9 – 62019 Recanati (MC) – ITALY Tel. +39 071 7506066 – Fax +39 071 7506057 www.esse-ti.it – e-mail: support@esse-ti.it...
