SECTION 503-603-101
Note: A number up to 15 digits in length (b) For sets equipped with the dial tone detector
may be recorded. The RECORD lamp will only, go off-hook, listen for dial tone, and
go out momentarily as each digit is dialed, depress the desired memory button.
If exactly 15 digits are recorded, the RECORD
lamp will go out and stay out, indicating that (c) For sets equipped with the one-touch calling
the dialer has been reset. If a memory button option (with speakerphone and dial tone
has not been depressed, the RECORD lamp detector), simply depress the memory button.
will go out when the first digit is dialed and
recording operation will be voided.
E. LAST NUMBER DIALED Feature
(7) Depress the RECORD OFF button if less 5.05 The TOUCH-A-MATIC telephone set
than 15 digits are recorded. The RECORD automatically records into the LAST NUMBER
lamp will go out. The dialer will be reset. The DIALED position (Fig. 1) any number dialed using
number is now stored in the selected memory, the standard telephone dial. Each number in the
The dialer will also be reset by a line switch, LAST NUMBER DIALED position is automatically
line key, or speakerphone operation, replaced by the next number manually dialed.
Although the unit is recording, the RECORD lamp
B. Change A Number In Memory
does not light at any time during this operation.
Note: If set is equipped with a D-180818 Note: If set is equipped with a D-180818
Kit of Parts, switch must be in the OFF Kit of Parts, and dial intermix feature is
position, provided, LAST NUMBER DIALED feature
is functional only when the feature switch is
5.02 Whenever a new number is recorded in a in the OFF position.
previously used memory position, it will
automatically replace the previously stored number. 5.06 Operation of LAST NUMBER DIALED
feature.
C. Delete A Number From Memory
(a) With no access digit(s) required.
Note: If set is equipped with a D-180818 (1) Go off-hook.
Kit of Parts, switch must be in the OFF
position. (2) Listen for dial tone.
5.03 Complete the following operations in succession. (3) Manually dial telephone number.
(1) Depress the RECORD button. (4) To redial same number automatically--
(2) Depress the memory button corresponding (a) For factory-wired sets, go off-hook,
to the name and number to be deleted, listen for dial tone and depress LAST
NUMBER DIALED button.
(3) Depress the RECORD OFF button.
(b) For sets equipped with the dial tone
detector only, go off-hook, listen for
D. Automatically Dial A Number From Memory dial tone, and depress the LAST NUMBER
DIALED button.
5.04 To automatically dial a number.
(c) For sets equipped with the one-touch
(a) For factory-wired sets go off-hook, listen calling option (with speakerphone and
for dial tone, and depress the desired dial tone detector), simply depress the
memory button. If WAIT input has been recorded, LAST NUMBER DIALED button.
automatic dialing will stop. When second dial
tone is heard, depress memory button again to (b) When an access code and pause for second
complete automatic dialing, dial tone is required.
Page 20
