1. GENERAL
This section contains identification, installation,
1.01
and connection information for the 911Al
and 2911Al (Fig. 1) DESIGN LINE* telephone
( Telstar)
sets.
*Trademark AT&TCo.
Fig. 1 -2911A 1-03 Telephone Set with Cover Open
Whenever this section is reissued, the reason
1.02
for reissue will be listed in this paragraph.
TEL SET*
911Al·03
2911Al·03
* These set are available in Black ( -03) only.
BSP 503-200-105-i01_1978-07-0l.jpg Scanned by Frank Harrell, (Cowboy Frank) Castle Rock, Colorado
TELEPHONE SETS
911 A 1 AND 2911 A 1
HANDSET
DIAL RINGER
SHA-119
PlA
KlA-03
35BB3D
Not for use or disclosure outside the
Bell System except under written agreement
The customer's premises must be properly
1.03
wired with an appropriate connecting block
or jack in order to accept the D4BU-29 plug-ended
mounting cord.
Warning:
wiring shall not be installed in a
location where minimum separation
from other
Se ction 460-300-149 cannot
maintained.
2. IDENTIFICATION
The 911Al-03 (rotary dial) and 2911Al-03
2.01
(TOUCH-TONE® dial) equipped telephone
sets are new DESIGN LINE telephone sets being
made available to the customer.
buys the housing and handset from the telephone
company and the telephone company retains
ownership of the transmission and signaling
components.
Refer to Table A for available codes and
2.02
ordering information.
These telephone sets are intended to be
2.03
used as single line or two-party desk sets
and are not recommended for use on four- and
eight-party service.
TABLE A
ORDERING GUIDE
JACK
TRMTR
IN
UNIT
HANDSET
Tl
616W
NOTICE
Printed in U.S.A .
Feb 08, 2012 18:31:54
SECTION 503-200-1 05
Issue 1, July
T elephone apparatus or
wiring as specified in
The customer
MTG
RCVR MTG
CORD
UNIT CORD
JACK
LBl D4BU-29 623P4
1978
b e
CORD
REEL
5C
Page 1
