- Page 1 550 Series Washdown Bench Scale Operators Manual MAN353 – Rev 1 Doran Scales, Inc. www.doranscales.com...
-
Page 2: Table Of Contents
Table of Contents Section 1. Introduction and Specifications ................1 Unpacking Your Scale ........................1 Specifications ........................... 2 Section 2. Scale Operation Guide .................... 3 Scale Display ............................ 3 Scale Operation ..........................4 Battery Operation ..........................5 Recharging Battery .......................... 5 Section 3. -
Page 3: Section 1. Introduction And Specifications
Section 1. Introduction and Specifications Thank you for purchasing a Doran Scales product. Please read this manual to ensure obtaining all the benefits that this scale can provide. If any questions arise, please contact the Doran Scales Technical Support Department at 630-879-1288. -
Page 4: Specifications
Specifications NTEP Certificate Class III – 3,000d; Cert. 19-XXX Enclosure Stainless Steel and ABS Plastic base Product Dimensions 9.5” W x 4.7” H x 11” D Environmental IP68 – Certified Protection Legal for Trade 14 °F to 104 °F (-10 °C to +40 °C) Temperature Range Power Input 100 –... -
Page 5: Section 2. Scale Operation Guide
Section 2. Scale Operation Guide This section contains information and instructions for basic scale operation. Fig. 1: Front Panel Scale Display Stability indicator. Indicates when stability is sensed on the platform. Changes in weight, vibration or air currents can cause the scale to go into motion and turn off the stability indicator. -
Page 6: Scale Operation
Scale Operation Adjust leveling feet of your scale until the bubble of the spirit level is within the horizontal range. Then you can use scale buttons to perform scale operations. NOTE: The button may be referred to as ON/ZERO or ZERO. Power Press ON/ZERO to turn the scale on Press Off to turn off... -
Page 7: Battery Operation
Battery Operation The indicator runs on lithium battery. To maximize battery life, set the Automatic Shutoff Timer (FnC 02) which will automatically power down the scale after a period of non-use. Recharging Battery To charge the battery, plug in the charging pad and place into the receptacle on the bottom rear of the scale. -
Page 8: Section 3. Scale Setup Guide
Section 3. Scale Setup Guide Parameter Setup With power on press NET/GROSS and ON/ZERO at the same time to enter Function Mode menu, then press ON/ZERO or UNITS to navigate: ON/ZERO key Þ Next / digits up (0à9) 9 à 0 0 à... - Page 9 01 FnC Function Setting menu details FnC 01 Backlight Setting When set to on, Backlight will dim when scale is not in use oFF, on and will automatically turn on when in use. FnC 02 Automatic Shutoff Timer Select number of minutes before the scale automatically shuts off.
- Page 10 FnC 05 Filter Settings (non approval only) Adjustments to offset environmental weighing interferences Press TARE to enter sequence 1. ZEro “Weight Noise Threshold” eliminates minor weighing Zero: 0-9 noise when weight on scale is over 1/3 full capacity: 0=off; (default 0) 1-9 = 1d to 9d threshold (weighing fluctuation below this threshold is de-noised).
-
Page 11: Section 4. Troubleshooting
TARE. 6. After 3 beeps, remove weight from weigh pan. 7. Calibration now finished. Section 4. Troubleshooting If any problem persists, contact Doran Tech Support at 630-879-1288. Problem What to Do or Check Weight reading will Examine the weighing platform for any interferences. Be... -
Page 12: Operation Error Codes
Operation Error Codes Error Descriptions Message Initial zero is higher than the zero range when switching the indicator on Initial zero is lower than the zero range when switching the indicator on A/D Error The weight of the object is over 9 divisions of the maximum capacity ------ Startup zero is below the allowed range... - Page 14 Doran Scales, Inc. 883 Enterprise Ct St. Charles, IL 60174 www.doranscales.com 630-879-1200...
