Gocycle Service Notice 8.0: Battery Installation

OCYCLE

ERVICE

IGHLY

ECOMMENDED

Battery Installation

Frame numbers affected: All

Installing the battery pack for the first time can be challenging due to the internal cables in the frame

being in a 'relaxed' state. Forcing the battery pack into the frame without first pulling the cables tight

could damage the battery pack.

8.1

Access the battery aperture in the frame as shown.

See

http://www.youtube.com/watch?v=iYTQwDwGjSA

8.0

OTICE

WITHOUT SERVICE ACTION

DAMAGE CAN OCCUR

COMPONENT

Battery aperture in

frame. Look inside to

see if the cables are

'relaxed' as show in

step 8.2.

IGHLY

ECOMMENDED

Table of Contents

Do you have a question about the G1 and is the answer not in the manual?

Page 1 Gocycle Service Notice 8.0: Battery Installation OCYCLE ERVICE OTICE IGHLY WITHOUT SERVICE ACTION COMPONENT IGHLY ECOMMENDED DAMAGE CAN OCCUR ECOMMENDED Battery Installation Service Issue Frame numbers affected: All Installing the battery pack for the first time can be challenging due to the internal cables in the frame being in a ‘relaxed’...
Page 2 Gocycle Service Notice 8.0: Battery Installation Look inside the battery aperture in the frame. The picture below shows the cables in a ‘relaxed’ state making it very difficult to install the battery pack. Cables can be ‘relaxed’ and bunched up, which can make it hard to insert the battery pack.
Page 3 Gocycle Service Notice 8.0: Battery Installation Notice how the cables are now tightened inside the frame. This will allow the battery to be installed easily. This shows the cables now ‘tightened’ and out of the way of the battery pack.
