OPERATOR´S MANUAL
MANUAL DE OPERADOR
PULVERIZADOR DE MOCHILA
4.2 US GAL LITER SPRAYER
PULVERIZADOR 16 LITROS
Model MX04/SP06 is a very innovative
model with a unique internal central
piston system.
With this sprayer you may apply liquid
products as: insecticides, herbicides,
fertilizers, etc. in an easy, practical and
safe way.
El modelo MX04/SP06 es un modelo
novedoso único en el mundo con "siste-
ma de bombeo central interno de pistón".
Con este equipo usted puede aplicar
productos líquidos como: insecticidas,
herbicidas, fertilizantes, etc. de forma
práctica y segura.
MODEL/MODELO
406195/406185
Litho´d in México
Impreso en México
04
BNSP/MX406-0619E/EX
R00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Advanced SP 06 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for swissmex Advanced SP 06 Series

  • Page 1 OPERATOR´S MANUAL MANUAL DE OPERADOR 2 YEAR SEE INSIDE FOR DETAILS PULVERIZADOR DE MOCHILA 2 AÑOS CONSULTE EL MANUAL EN EL INTERIOR 3 YEAR SEE INSIDE FOR DETAILS 3 AÑOS CONSULTE EL MANUAL EN EL INTERIOR 4.2 US GAL LITER SPRAYER PULVERIZADOR 16 LITROS Model MX04/SP06 is a very innovative model with a unique internal central...
  • Page 2: English Version

    INTRODUCTION Thank you for buying a Swissmex equipment, we guarantee that the product you have acquired was made with an unbeatable quality, because it was developed with state of the art technology following all quality standards required. This equipment was carefully designed and built with the purpose of providing the maximum performance, economy and ease of operation.
  • Page 3: Safety Measures

    2.2 SAFETY MEASURES Read carefully the entire owner’s manual before filling, using or cleaning the sprayer. Do not leave the sprayer in reach of children or persons not qualified to handle it properly. Do not modify your equipment; it may compromise your equipment and put into risk third party safety. Any modifications or adaptation is under your own risk and it voids the warranty.
  • Page 4: Technical Data

    3.2 TECHNICAL DATA ESPECIFICATIONS 406195 406185 Model Tank capacity 16.0 L /4.2 US gal Filling port 13.8 cm / 5.43” Cushioned with belt Carrying Straps Pumping system Central internal piston Piston Sleeve 45 mm / 1.37” elastomer Hose fiber vinil reinforced 3/8” ID Shut-Off valve Professional with filter Spray wand...
  • Page 5: Operation

    Move the nozzle cap to change the spraying pattern. NOTE: To ensure good performance use original “SWISSMEX-RAPID” spare parts MAINTENANCE Since the sprayer needs little maintenance, if you follow the steps mentioned in this manual its lifespan will be very long.
  • Page 6: Troubleshooting Guide

    5.1 MAINTENANCE GUIDE Below are instructions for maintaining your spray: Rinse with clean water externally and internally, to avoid risk of contamination. To keep your sprayer in good condition it is recommended to change the following parts when servicing your sprayer (No. 501-204 -C1): - Checks for O-rings and cylinder - Piston Ring - Gun o-rings...
  • Page 7 E219-099 -15.74” / 40 cm Shut-offs complete with filter and E219-117 - 8.6” / 22 cm filter housing Shut-offs without grip E809-073-C E808-073-C E803-073-C E807-073-C COMPLETE NOZZLES E219-610-C E219-710-C E803-092-C For more technical information please look into our Nozzle Chart at www.swissmex.com...
  • Page 8: Carrying Straps

    CARRYING STRAPS MORE ACCESSORIES Key tool Extension adapter Filter housing E501-336-C E501-230-C E080-034-C E501-034-C E501-134-C E803-602-C E219-555 E219-003 SPRAY TIPS E1102.022 E1030.020 FILTERS PRESSURE REGULATORS E1210.050 EY11-16SY E1210.080 ER11-16SY E1210.100 EBM-16SR E1210.150 EG11-16SY E1210.180 SPARE PARTS LIST Spare parts and consumables always available. Medium-use parts, available at discretion Description Part No.
  • Page 9 4a (model 406185) model 406195 5a (model 406185) model 406185 model 406185 model 406185 model 406195 E189-200-C SEAL KIT E406-200-C SEAL KIT FELT RING ORING (to nozzle body) FELT RING GASKET (to nozzle body) ORING ORING (to cap) PISTON ORING (to plunger PISTON ORING (to plunger) BREATHER CHECK...
  • Page 10: Warranty

    Any claim made under this warranty must adhere to the Warranty Policy described below: The warranty will be granted by SWISSMEX RAPID SA DE CV when the product presents manufacturing, assembly or material defects and this has been established after conclusive analysis at Swissmex plant (Lagos de Moreno, Jalisco, Mexico). The warranty consists of replacement of damaged parts or replacement of damaged equipment depending on conclusions of the analysis of the claim.
  • Page 11: Versión En Español

    3.3.2 Como ensamblar su pulverizador INTRODUCCIÓN Gracias por comprar un equipo Swissmex, le garantizamos que el producto que ha adquirido cuenta con calidad insuperable ya que fue desarrollado con tecnología de punta, siguiendo los estándares de calidad requeridos. Este equipo fue cuidadosamente diseñado y fabricado con el fin de proporcionar el máximo rendimiento, economía y facilidad de operación.
  • Page 12: Medidas De Seguridad

    MEDIDAS DE SEGURIDAD Antes de poner su equipo en funcionamiento lea cuidadosamente este manual de instrucciones. La manipulación incorrecta y por personas no capacitadas pueden ocasionar accidentes graves. No haga adaptaciones o improvisaciones; estas comprometen su equipo y ponen en riesgo su seguridad y la de terceros.
  • Page 13: Datos Técnicos

    DATOS TÉCNICOS ESPECIFICACIONES 406195 406185 Modelo Capacidad del tanque 16.0 L /4.2 US gal Boca del tanque 13.8 cm / 5.43” Cintas Acojinadas con cinturón Sistema de bombeo Piston central interno Anillo pistón Elastómero 45 mm / 1.37” Manguera Vinilo reforzado con fibra 3/8” ID PIstola Profesional con filtro Tubo rociador...
  • Page 14: Operación

    Necesitará bombear cada 3 o 4 segundos para mantener la presión deseada. Para una pulverización continua, asegure la palanca de la pistola con el gancho seguro. Gire el boquerel para cambiar el patrón de pulverización. NOTA: Para asegurar un mejor funcionamiento use solo refacciones originales “SWISSMEX-RAPID”...
  • Page 15: Mantenimiento

    MANTENIMIENTO El pulverizador no requiere de mucho mantenimiento, si usted sigue a detalle los pasos que le mencionamos en este manual, la vida útil de su equipo será muy prolongada. Al terminar su jornada de trabajo, no deberá dejar el pulverizador con presión, por lo tanto, deberá dejar salir toda la presión por la boquilla, posteriormente quite la tapa y la coladera del tanque y voltéela, para vaciar la solución restante en un recipiente apropiado para ello.
  • Page 16 POSIBLES PROBLEMAS Y SOLUCIONES PROBLEMA CAUSA SOLUCIÓN El champiñón de la tapa está reseco Al estar bombeando el tanque Lubrique el champiñón o sustituya en caso de que esté (sin lubricación). se colapsa. dañado. El anillo pistón está hinchado por el El pistón no desliza suavemente y su Engrase el anillo pistón o cambiélo si es necesario.
  • Page 17: Otros Accesorios

    EXTENSIONES Extensión 2 salidas FVR Extensión 3 salidas FVR E219-138-C - 39.37” - de 1 m E219-151-C - 59.0 de 1.5 m E219-140-C - 19” / 50 cm Extensión 3 salidas latón E219-147-C - 39.37” / 20 cm E219-148-C - 28.7” / 73 cm E219-420-C - 39.37 - 1.0 m Extensión 4 salidas FVR E219-282-C - 39.0”...
  • Page 18 PUNTAS CINTAS E501-336-C E1030.020 E501-230-C E1102.022 E080-034-C E501-034-C E501-134-C FILTROS REGULADORES DE PRESIÓN E1210.050 EY11-16SY E1210.080 ER11-16SY E1210.100 EBM-16SR E1210.150 EG11-16SY E1210.180 8. REFACCIONES Piezas de uso medio disponibles a discreción. Piezas de desgaste y consumibles siempre disponibles No. Parte Código No.
  • Page 19 4a (mod. 406185) modelo 406195 (mod. 406185) modelo 406185 modelo 406185 para modelo 406185 para modelo 406195 E189-200-C JUEGO DE EMPAQUES Y CONTIENE: E406-200-C JUEGO DE EMPAQUES Y CONTIENE: ESTOPERO DE FIELTRO AROSELLO P/BOQUEREL ESTOPERO DE FIELTRO EMPAQUE P/BOQUEREL AROSELLO P/CILINDRO AROSELLO P/TAPON ANILLO PISTON AA AROSELLO GRANDE...
  • Page 20 Para hacer válida su garantía deberá apegarse a la Póliza de Garantía descrita a continuación: La garantía será concedida por SWISSMEX RAPID SA DE CV, gratuitamente, cuando las piezas y los componentes presenten defectos de fabricación o de montaje y después de análisis conclusivo en planta (Lagos de Moreno, Jalisco). La garantía consiste en la sustitución de piezas dañadas por nuevas, o cambio del equipo dañado por uno nuevo, una vez que se haya verificado y evaluado el tipo de daño en el...
