Vitronics Soltec myReflow Installation Manual page 7

SAFETY RULES
GENERAL INFORMATION
ICON DESCRIPTION
Only Qualified personnel is allowed to work on the
equipment.
Never eat, drink or smoke while working on the
machine.
Wash thoroughly before eating, drinking or smoking.
Always wear heat resistant gloves and protective
clothing when working on the machine.
If possible allow the machine to cool down before
starting working on the machine.
When burned, immerse in cold water immediately.
When the burn is severe, consult a physician as soon
as possible.
No smoking or open fire near the machine.
Be sure a fire-extinguisher is in the surroundings of
the machine.
All moving parts of the system, including pulleys,
belts, chains, coolingfans, sprocketwheels, vacuum-
doors and cylinders presents a potential danger.
The vapours in the board preparation module are
chemical. When the board is heated, a noxious
vapour will be liberated. This vapour must be
extracted. Also the dust on the surface of the solder-
pot is dangerous when inhaled.
Avoid inhaling this vapours / dust by using mouth
protection.
Nitrogen Follow the safety precautions and procedures
described in the Material Safety Data Sheet of
N
the Nitrogen supplier.
2
Signal light RED
- E-stop Active
Signal light ORANGE
- Steady = Overload (outfeed full), Machine will
block,
- Flashing slow = Alarm
- Flashing fast = Critical alarm. Machine will block
If these rules are not observed it can cause personal injury and/or damage to the machine
ICON DESCRIPTION
High voltages are present on various parts of the sys-
tem.
Before working on the electrical circuit, turn main
power off and block the mainswitch with a padlock.
Always wear heat resistant gloves and protective
clothing when working on the machine.
If possible allow the machine to cool down before
starting working on the machine
When burned, immerse in cold water immediately.
When the burn is severe, consult a physician as soon
as possible.
No smoking or open fire near the machine.
Be sure a fire-extinguisher is in the surroundings of
the machine.
Be careful with covers and doors. Always pay atten-
tion to opening and closing.
When working on the machine, always protect your
eyes with safety glasses.
UPS When mainswitch is switched OFF for a longer
period, switch the UPS to OFF.
Uninterruptible
Power Source
Signal light GREEN
- Steady = Machine Run,
- Flashing slow = Machine not at setpoint, machine
stop
LASER RADIATION
Do not stare into beam.
Class 2 Laser product.
Only applicable for Soldering machines
equipped with laser measurement systems.
