1.6 S
AFETY
1.6.1 A
UDIBLE AND VISUAL INDICATIONS
The machine has both audible and visual signals: 1 buzzer and 3 signallights.
T 1.1
ABLE
SIGNAL
Fast
T 1.2
ABLE
SIGNAL
Steady
Flashing slow
T 1.3
ABLE
SIGNAL
Steady
Flashing slow
Flashing fast
T 1.4
ABLE
SIGNAL
Continuous
Installation Guide myReflow
1.6 - S
AFETY
B
UZZER
G
REEN LIGHT
Y
ELLOW LIGHT
R
ED LIGHT
FUNCTION
Critical alarm. Machine will block
FUNCTION
Machine run
Machine not at setpoint, machine stop
FUNCTION
Overload (outfeed full). Machine will block
Alarm.
Critical alarm. Machine will block.
FUNCTION
E-stop active
