Installation and Maintenance Instructions
CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . 1
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
DIMENSIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Step 1 - Unpack and Inspect Units . . . . . . . . . . . . 7
Step 2 - Position the Unit . . . . . . . . . . . . . . . . . . . . 7
Step 3 - Mount the Unit . . . . . . . . . . . . . . . . . . . . . . 8
Step 4 - Connect Piping . . . . . . . . . . . . . . . . . . . . . 11
ACB Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Pre-Start Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Drain Pump and Drainage Test . . . . . . . . . . . . . . . 17
System Operation Check . . . . . . . . . . . . . . . . . . . . 17
MAINTENANCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
INDOOR UNIT ADDRESSING. . . . . . . . . . . . . . . . . 18
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . 20
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . 21

SAFETY CONSIDERATIONS

Improper
installation,
maintenance, or use can cause explosion, fire, electrical shock,
or other conditions, which may cause death, personal injury, or
property damage. The qualified installer or agency must use
factory-authorized kits or accessories when modifying this
product.
Follow all safety codes. Wear safety glasses, protective
clothing, and work gloves. Use quenching cloth for brazing
operations. Have fire extinguisher available. Read these
instructions thoroughly, and follow all warnings or cautions
included in literature and attached to the unit. Consult local
building codes and the current editions of the National
Electrical Code (NEC) ANSI/NFPA (American National
Standards Institute/National Fire Protection Association) 70. In
Canada, refer to the current editions of the Canadian Electrical
Code CSA (Canadian Standards Association) C22.1.
Understand the signal words -
.
identifies the most serious hazards,
CAUTION
DANGER
which will result in severe personal injury or death.
signifies hazards that could result in personal injury
WARNING
or death.
is used to identify unsafe practices, which
CAUTION
would result in minor personal injury or product and property
damage.
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 20-40VMI002-01
adjustment,
alteration,
,
DANGER
WARNING
Printed in U.S.A.
1-Way Cassette Indoor Unit for
Variable Refrigerant Flow (VRF) Systems
Recognize safety information. This is the safety-alert
symbol (
Page
instructions or manuals, be alert to the potential for personal
injury. Installing, starting up, and servicing equipment can be
hazardous due to system pressure, electrical components, and
equipment location.
Electrical shock can cause personal injury and death. Shut
off all power to this equipment during installation. There
may be more than one disconnect switch. Tag all
disconnect locations to alert others not to restore power
until work is completed.
When installing the equipment in a small space, provide
adequate measures to avoid refrigerant concentration
exceeding safety limits due to refrigerant leak. In case of
refrigerant leak during installation, ventilate the space
immediately. Failure to follow this procedure may lead to
personal injury.
DO NOT USE TORCH to remove any component. System
contains oil and refrigerant under pressure.
service,
To remove a component, wear protective gloves and
goggles and proceed as follows:
a. Shut off electrical power to unit.
b. Recover refrigerant to relieve all pressure from
system using both high and low-pressure ports.
c. Traces of vapor should be displaced with nitrogen
and work area should be well ventilated. Refrigerant
in contact with an open flame produces toxic gases.
d. Cut component connection tubing with tubing cutter
and remove component from unit. Use a pan to catch
any oil that may come out of the lines and as a gage
for how much oil to add to the system.
e. Carefully unsweat remaining tubing stubs when
necessary. Oil can ignite when exposed to torch
flame.
, and
Failure to follow these procedures may result in personal
injury or death.
Form 40VMI-2SI
40VMI005-024
). When this symbol is displayed on the unit and in
WARNING
WARNING
WARNING
Pg 1
2-20
Replaces: 40VMI-1SI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 40VMI Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Carrier 40VMI Series

  • Page 1: Table Of Contents

    40VMI005-024 1-Way Cassette Indoor Unit for Variable Refrigerant Flow (VRF) Systems Installation and Maintenance Instructions CONTENTS Recognize safety information. This is the safety-alert symbol ( ). When this symbol is displayed on the unit and in Page instructions or manuals, be alert to the potential for personal SAFETY CONSIDERATIONS .
  • Page 2: General

    GENERAL CAUTION The 40VMI 1-way ceiling cassette effectively makes each area served an independently controlled temperature zone. Through DO NOT re-use compressor oil or any oil that has been thermostatic control of operations, conditions can be varied to exposed to the atmosphere. Dispose of oil per local codes suit diverse requirements and activities.
  • Page 3 Table 1 — 40VMI Physical Data UNIT 40VMI POWER SUPPLY (V-Ph-Hz) 208/230-1-60 TOTAL COOLING CAPACITY (Btuh) 5,070 7,100 9,130 12,170 15,210 18,250 24,340 TOTAL HEATING CAPACITY (Btuh) 6,000 8,000 10,000 13,500 17,000 21,000 27,000 INDOOR FAN MOTOR Type Input (W) INDOOR AIRFLOW (cfm) Medium High...
  • Page 4 Table 2 —Components Shipped With Unit NAME APPEARANCE QUANTITY PURPOSE Template For drop ceiling cutout Insulation For piping connections Rope Tie For fastening and tightening Condensate Connection For drain connection Clamp For connecting the drain Washer To secure suspended unit To secure suspended unit Screw For securing panel / grille...
  • Page 5: Dimensions

    DIMENSIONS 46-1/2 34-3/4 2-3/4 Ø 2-3/4 2 2-3/4 Ø NOTE: All dimensions are shown in inches. Fig. 2 —40VMI005-012...
  • Page 6 7-1/2 41-1/2 2-1/4 1-1/4 41-3/4 2-3/4 2 51-1/2 1-1/4 2-3/4 48-1/2 11-3/4 NOTE: All dimensions are shown in inches. Fig. 3 —40VMI015-024...
  • Page 7: Installation

    INSTALLATION Step 2 — Position the Unit — Unpack and Inspect the Units — DANGER Step 1 — Unpack and Inspect Units — Units are Units must not be installed where they may be exposed to packaged for shipment to avoid damage during normal transit potentially explosive or flammable atmosphere.
  • Page 8: Step 3 - Mount The Unit

    Ceiling Return Screws for panel installation: M4X22 (6) Air Inlet Floor Angular Range for Airflow Fig. 7 —Secure Plate NOTE: Dimensions are in inches. CAUTION Fig. 5 —Distance from Wall of Obstruction • Do not position the unit where the discharge air could Remove all buffers between the fan and the flared mouth before installing the indoor unit.
  • Page 9 4. See Fig. 14 for “Removing Panel from Unit” instructions for 2 clips on the panel assembly. Hanger bolt NOTE: Be aware that the louver and display wires are Nut 1 connected so be careful when removing the panel. Washer 1 a.
  • Page 10 4. See Fig. 18 for “Installing Panel to Unit” instructions for PANEL INSTALLATION — 2 clips on the panel assembly. Be sure to keep louver and 1. There are two buckle structures on the panel assembly for display wires accessible through filter opening. the installation of the auxiliary panel.
  • Page 11: Step 4 - Connect Piping

    REFRIGERANT PIPING CAUTION When connecting from an indoor unit to an outdoor unit, the isolation valve at outdoor unit should be in the closed position throughout the refrigerant piping process. Failure to follow this procedure may result in equipment damage. Room temp.
  • Page 12 Table 4 — 40VMF Electrical Data WARNING POWER SUPPLY 40VMF UNIT SIZE All units must be wired strictly in accordance with the MOPD wiring diagram furnished with the unit. Any wiring 0.29 different from the wiring diagram could result in personal 0.29 injury and property damage.
  • Page 13 BLUE WHITE Blue GRAY YELLOW BLUE WHITE Fig. 27 — 40VMI005-024 Typical Wiring Diagram...
  • Page 14: Step 6 - Position And Connect Controller

    Step 6 — Position and Connect Controller — 3. Use a suitable screwdriver to fix the communication wire on the outdoor unit communication terminal (Fig. 31). Wired controllers should be installed in a position that maintains good temperature control: • Position the thermostat approximately 48 inches above floor level.
  • Page 15 Maximum wiring length Fig. 33 — Typical Heat Recovery Communication Wiring Diagram...
  • Page 16 wired controller outdoor unit Centralized controller Indoor unit 1# Indoor unit 2# Indoor unit 3# Indoor unit 4# wired controller Indoor unit 5# Matched resistance (network matchded wire group) Maximum wiring length Indoor unit 6# Fig. 34 —Typical Heat Pump Communication Wiring Diagram...
  • Page 17: Acb Interface

    ACB Interface — System Operation Check — The ACB interface is a dry contact Once the installation board that can output up to four signals controlling devices. and pre-start checks are completed, follow these steps: Refer to Fig. 35 for connecting devices to ACB interface board. 1.
  • Page 18: Indoor Unit Addressing

    INDOOR UNIT ADDRESSING Non-Programmable Controller (40VM900002) When setting an address, connect only one wired controller to For proper system operation, each indoor unit must have a an indoor unit. unique address set from 0 to 63. When setting an address by Press ROOM TEMP and SWING simultaneously for three remote controller, the outdoor units, indoor units, and MDC seconds.
  • Page 19: Programmable Controller (40Vm900003)

    Programmable Controller (40VM900003) — 3. Press TEMP. UP or TEMP. DOWN to choose the address you want to set. See Fig. 41. Press MENU/OK to When setting an address, connect only one wired controller to send this address to the IDU. an indoor unit.
  • Page 20: Troubleshooting

    TROUBLESHOOTING Fig. 42 shows the LED display panel on the indoor unit. See Table 5 for a summary of display indicators. Table 6 lists problems, possible causes, and possible solutions. A40-1716 OPERATION TIMER DEF./FAN ALARM a40-1842 Fig. 42 —LED Display Panel Table 5 —...
  • Page 21: Replacement Parts

    POWER SUPPLY 208/230V-1Ph-60Hz MINIMUM CIRCUIT AMPACITY 0.29A MAX FUSE OR HACR BREAKER 15 A 0.23 A FAN MOTOR 20W (1/30HP) OUTPUT REFRIGERANT R410A HIGH 650 PSIG DESIGN PRESSURE 250 PSIG SERIAL NO. Carrier Corporation Fig. 43 — Unit Serial Plate (Example)
  • Page 22: Appendix A - Dip Switch Settings

    — Mode Priority Indoor Unit (HP Only) (IDU address must be 63) Fig. A — SW1 SETTINGS © Carrier Corporation 2020 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations. Catalog No. 20-40VMI002-01 Printed in U.S.A.
