Pacific Casual 143-0347D-B1 Assembly Instructions

Rushreed 7 piece woven dining set (dining table)

P C

Paciﬁc

Casual

Before you start

Please take out the table parts, and carefully remove wrapping

materials. Be careful not to break the glass or damage the weaves.

Check the part list and make sure you have all of the parts before

starting to assemble the products.

A rubber mallet is needed during the assembly of the table.

Keep the assembly instructions for future reference.

Assembly Instructions

LLC

Rushreed 7 Piece Woven Dining Set

(Dining Table）

Item#: 143-0347D-B1

Page 1 of 4

Table of Contents

Do you have a question about the 143-0347D-B1 and is the answer not in the manual?

Page 1 Casual Assembly Instructions Rushreed 7 Piece Woven Dining Set (Dining Table） Item#: 143-0347D-B1 Before you start Please take out the table parts, and carefully remove wrapping materials. Be careful not to break the glass or damage the weaves. Check the part list and make sure you have all of the parts before starting to assemble the products.
Page 2 Part List Q'ty Illustration Part Name Table rim Table leg Long bolt Plug Nut, M10 Lock washer Steel washer Wrench Glass Page 2 of 4...
Page 3 Step 1 : Set glass (I) aside. On a flat smooth surface place the table rim (A) upside down. COMPLETELY screw four long bolts (C) into table rim (A). Step 2 : Cover each bolt with one table leg (B). Secure each bolt to table leg with one washer (G), one locker washer (F) and one screw nut (E) using wrench (H).
Page 4 Turn the table upright. Place the glass (I) into the table rim (A). Customer Service: Call between 7:30am to 4:30pm P.S.T (Monday to Friday ) Pacific Casual LLC 1060 Avenida Acaso, Camarillo, Ca 93012 Toll Free Number: (888) 445-7757 CustomerService@PacificCasual.com...
