DACT-100A MAIN BOARD TERMINAL CONNECTIONS:
Wire the two telephone lines devices to terminals as shown.
Line 1 Input (Tip/Ring):
Line 1 Output (Tip/Ring):
Line 2 Input (Tip/Ring):
Line 3 Output (Tip/Ring):
Note that most AHJ's do not allow the connection of Premise Telephones. See wiring tables and specifications for more information.
NOTE: the terminal blocks are "depluggable" for ease of wiring.

FIELD WIRING

To the first Telephone Line via the required RJ31X Connector.
To an optional Premise Telephone on the first Telephone Line via the required RJ31X Connector.
To the second Telephone Line via the required RJ31X Connector.
To an optional Premise Telephone on the second Telephone Line via the required RJ31X Connector.
