Mircom DACT-100A Installation And Operation Manual page 11

Items accessible to Level II only
ITEM Access
Number Level
30 II
31 II
32 II
33 II
40 II
41 II
42 II
43 II
50 II
51 II
52 II
53 II
55 II
60 II
61 II
62 II
63 II
64 ll
NOTE: All configurable items have default values assigned by the "Restore-to-Default" operation. All items must have a (non-zero) value
assigned unless specifically identified as OPTIONAL within the table(s) above.
Menu Category Menu Label
Account (#1) Account ID #1
Account (#1) Dial-Prefix #1
Account (#1) Local Number #1
Account (#1) Report Format #1
Default Contact ID
Account (#2) Account ID #2
Account (#2) Dial-Prefix #2
Account (#2) Local Number #2
Account (#2) Report Format #2
Default Contact ID
Report Priority ALARM Events
Default is
Account 1
Report Priority TROUBLE Events
Default is
Account 1
Report Priority SUPERVISORY
Events
Default is
Account 1
Event Logging Ignore <SUPVSRY>
Events,
Default will Report
Supervisory
Report Priority Max. Attempts
Range is 5 to 10,
Default is 6
Attempts
Phone Line (1/2) Dial-type Line 1
Phone Line (1/2) Dial-type Line 2
Configuration Reboot DACT
Phone Line(1&2) Deaf Dialling
Default dial tone(1)
Phone Line 2 Set Testing Date
Description
Assign 4-6 numeric Account ID to be identified with Account #1
monitoring station receiver.
(OPTIONAL) Set up-to-8-digits to be first dialed by DACT when
attempting to call Account #1 monitoring station receiver.
Set up-to-8-digits to be dialed (after Dial-Prefix #1 digits) by DACT
when attempting to call Account #1 monitoring station receiver.
Choose report format (Contact ID or SIA) to be generated by DACT
when reporting with Account #1 monitoring station receiver.
Assign 4-6 numeric Account ID to be identified with Account #1
monitoring station receiver
(OPTIONAL) Set up-to-8-digits to be first dialed by DACT when
attempting to call Account #2 monitoring station receiver.
Set up-to-8-digits to be dialed (after Dial-Prefix #2 digits) by DACT
when attempting to call Account #2 monitoring station receiver.
Choose report format (Contact ID or SIA) to be generated by DACT
when reporting with Account #2 monitoring station receiver.
Choose which Account # (1 or 2) will be the first to be attempted to be
reached by the DACT, when an ALARM event is to be reported. This
is designated as the "primary" account and the other will become the
"secondary". If the DACT cannot report to the primary, it will then
attempt to report to the secondary. This cycle will normally continue
until the event is eventually or the <MAXIMUM Attempts> has been
achieved.
Choose which Account # (1 or 2) will be the first to be attempted to be
reached by the DACT, when a TROUBLE event is to be reported.
(See ITEM 50 for a description of the DACT report-attempt
operation).
Choose which Account # (1 or 2) will be the first to be attempted to be
reached by the DACT, when a SUPERVISORY event is to be
reported. (See ITEM 50 for a description of the DACT report-attempt
operation).
This selection allows the overriding of the "normal' reporting of the
supervisory events when set to 1. The DACT will report supervisory
events when set to 2.
Set the "normal" upper limit for DACT attempts (call-attempt pairs) to
report to monitoring station receivers.(See ITEM 50 for a description
of the DACT report-attempt operation). After this count has been
exceed, the DACT will assert the TROUBLE-SEND signal (and
BUZZER) to the connected Fire-Panel.
Configure Line 1 for DTMF (Tone) or Rotary (Pulse) Dialling.
Configure Line 2 for DTMF (Tone) or Rotary (Pulse) Dialling.
Test watchdog circuit by (1) halting program execution and (2) waiting
for watchdog to reset DACT.
To wait and listen for dial tone select 1 (default) or Ignore Dial Tone
for use with "Cellular Telephone" select 2
Default testing date for Phone Line 2 is the 1
Selection can be made from 1
Line 2 is used for a cellular phone, then the Deaf Dialling should be
set to 2 (63 set to Ignore Dial Tone).
Page 9
st
day of the month.
st th
to 28 day of the month. Whenever
