Single Point Kit Numbers; Single Point Wiring Kit - Johnson Controls PCE4 Series Installation Manual

TABLE 5: Single Point Kit Numbers
Unit Model
Voltage
Number
PCE4A36 208-3-60
PCE4A36 208-3-60
PCE4B48 208-3-60
PCE4B60 208-3-60
Unit Model
Voltage
Number
PCE4A36 230-3-60
PCE4A36 230-3-60
PCE4B48 230-3-60
PCE4B60 230-3-60
NOTES:
* The 208/230 volt 20kW and 25kW heater kits include circuit breakers.
FIGURE 8: Single Point Wiring Kit
Johnson Controls Ducted Systems
Heater Kit

Single Point Wiring Kit

6HK06501025 S1-2SPWK031
6HK06501525 S1-2SPWK033
6HK06501025 S1-2SPWK032
6HK06501525 S1-2SPWK032
6HK06501025 S1-2SPWK032
6HK06501525 S1-2SPWK034
6HK06501825 S1-2SPWK034
6HK16502025 S1-2SPWK035
6HK06501025 S1-2SPWK032
6HK06501525 S1-2SPWK034
6HK06501825 S1-2SPWK034
6HK16502025 S1-2SPWK035
6HK16502525 S1-2SPWK035
Heater Kit Single Point Wiring Kit
6HK06501025 S1-2SPWK031
6HK06501525 S1-2SPWK033
6HK06501025 S1-2SPWK031
6HK06501525 S1-2SPWK032
6HK06501025 S1-2SPWK032
6HK06501525 S1-2SPWK034
6HK06501825 S1-2SPWK034
6HK16502025 S1-2SPWK035
6HK06501025 S1-2SPWK032
6HK06501525 S1-2SPWK034
6HK06501825 S1-2SPWK034
6HK16502025 S1-2SPWK035
6HK16502525 S1-2SPWK035
5538117-UIM-B-0319
Unit Fuse Size Heater Fuse Size
(Amps) (Amps)
20 25
20 40
25 25
25 40
35 25
35 40
35 50
35 N/A*
40 25
40 40
40 50
40 N/A*
40 N/A*
Unit Fuse Size Heater Fuse Size
(Amps) (Amps)
20 30
20 45
25 30
25 45
35 30
35 45
35 50
35 N/A*
40 30
40 45
40 50
40 N/A*
40 N/A*
7
