5538117-UIM-B-0319
TABLE 2: Weights and Dimensions
Model Weight (lbs.)
Shipping
PCE4A36 387
PCE4B48 460
PCE4B60 477
FIGURE 2: Unit 4 Point Load Weight
TABLE 3: Unit Dimensions
Model
PCE4A36
PCE4B48
PCE4B60
HIGH VOLTAGE
CONNECTION 7/8"
HIGH VOLTAGE
CONNECTION 1-3/32"
COMPRESSOR
ACCESS PANEL
CONDENSATE
DRAIN
BLOWER
ACCESS
PANEL
FIGURE 3: Unit Dimensions
4
Center of Gravity
Operating X
382 30
455 30
472 30
COMPRESSOR
"A"
FRONT
OF UNIT
X
A
51-1/4
51-1/4
51-1/4
A
CONTROL ACCESS
PANEL
4 Point Load Location (lbs.)
Y A
15 112
19 158
20 157
"D"
CENTER OF
GRAVITY
"C"
"B" Y
A0295-001
Dimensions
B
35-3/4
45-3/4
45-3/4
C
B
LOW VOLTAGE CONNECTION
B C
123 120
125 130
134 140
C
47
49
51
COIL GUARD
HEAT SECTION
ACCESS PANEL
Johnson Controls Ducted Systems
D
45
75
74
A0379-001
