1.1 Introduction

We appreciate your business and your choice of Welker products. The installation, operation, and maintenance liability for this
equipment becomes that of the purchaser at the time of receipt. Reading the applicable Installation, Operation, and
Maintenance (IOM) Manuals prior to installation and operation of this equipment is required for a full understanding of its
application and performance prior to use.*
If you have any questions, please call Welker at 1-281-491-2331.
*The following procedures have been written for use with standard Welker parts and equipment. Assemblies that have been modified may have additional
requirements and specifications that are not listed in this manual.

1.2 Product Description

The Welker inLoop™ ACE Crude Oil Sampler is a bypass sampler designed to extract a representative sample of liquid product
from the flowing stream. With protection from internal check valves designed for sandy oils, this sampler is capable of sampling
product containing sand.
The inLoop™ ACE was specifically designed to be installed as part of a fast loop, which will provide the sampler with a
continuous supply of product. Sampling may be hydraulically or pneumatically operated but is electronically controlled from a
Programmable Logic Controller (PLC) or other signal control system. Sampling may be timed or proportional to flow.
Designed with ease of use in mind, the external sample volume adjustment simplifies operation of the inLoop™ ACE even
further. The external adjustment allows the operator to adjust the sample volume without having to remove the inLoop™ ACE
from the fast loop.
For this manual, the term "PLC," or Programmable Logic Controller, will be used to refer to the PLC, DCS, or other signal control
system used by the customer to activate and operate the solenoid.
Welker may custom design the inLoop™ ACE to suit the particular application and specifications of each customer.
