Maintenance for Single Filter Operation Maintenance for Dual Filter Operation Testing the Differential Pressure Gauge Troubleshooting APPENDIX A: Referenced or Attached Documents IOM-174 MODEL: CLEANFLOW F-31 REV: C 13839 West Bellfort Street, Sugar Land, TX 77498 welker.com Service Department: 281.491.2331...
Warning messages appear before procedures that could result in personal injury if not observed. This manual is intended to be used as a basic installation and operation guide for the Welker® CleanFlow F-31. For comprehensive instructions, please refer to the IOM Manuals for each individual component.
If you have any questions, please call Welker® at 1.281.491.2331. *The following procedures have been written for use with standard Welker® parts and equipment. Assemblies that have been modified may have additional requirements and specifications that are not listed in this manual.
1.3 Specifications The specifications listed in this section are generalized for this equipment. Welker® can modify the equipment according to your company's needs. Please note that the specifications may vary depending on the customization of your equipment. Table 1: CleanFlow F-31 Specifications...
Connect the outlet of the CleanFlow F-31 to the instrument to be supplied with the conditioned natural gas or instrument air (Figure 1 or Figure 2). If the CleanFlow F-31 is equipped with the optional outlet relief valve, connect from the relief to a safe vent if required (Figure 2).
Page 11
H simultaneously (Figure 4). If a valve is installed between the CleanFlow F-31 and the instrument to be supplied with the conditioned natural gas or instrument air, open that valve to allow the pneumatic supply to reach the instrument.
All maintenance and cleaning of the unit should be performed on a smooth, clean surface. Welker® recommends having the following tools available for maintenance. Please note that the exact tools required may vary by model. 12" Wrench b.
(Figure 4). If the CleanFlow F-31 is equipped with the optional differential pressure gauge, close inlet pressure valve G and outlet pressure valve H prior to performing maintenance to protect the gauge from damage (Figure 4). If applicable, ensure that differential pressure gauge test valve 1 I and differential pressure gauge test valve 2 J are closed (Figure 4).
Page 14
Close backup filter inlet valve B and backup filter outlet valve D to resume single filter operation (Figure 4). Maintenance may now be performed on the backup filter. IOM-174 MODEL: CLEANFLOW F-31 REV: C 13839 West Bellfort Street, Sugar Land, TX 77498 welker.com...
Page 15
To maintain supply to the instrument while performing maintenance on the backup filter, the primary filter must be put into service. If the CleanFlow F-31 is equipped with an optional differential pressure gauge, ensure that inlet pressure valve G and outlet pressure valve H are closed (Figure 4).
Halt all operations of the CleanFlow F-31. If the CleanFlow F-31 is equipped with the optional differential pressure gauge, close inlet pressure valve G and outlet pressure valve H prior to performing maintenance to protect the gauge from damage (Figure 4). If applicable, ensure that differential pressure gauge test valve 1 I and differential pressure gauge test valve 2 J are closed (Figure 4).
Page 17
Slowly open primary filter outlet valve C and backup filter outlet valve D (Figure 4). Check for leaks and repair as necessary. If the CleanFlow F-31 is equipped with the optional differential pressure gauge, open inlet pressure valve G and outlet pressure valve H simultaneously (Figure 4). Dual filter operation will now resume.
3.4 Testing the Differential Pressure Gauge Prior to testing the differential pressure gauge, ensure that the CleanFlow F-31 is in operation (Table 2 and Figure 4). Table 2: Valve Configuration for Operation Single Filter Operation: Single Filter Operation: Valve Dual Filter Operation...
3.5 Troubleshooting Guidelines Table 3: CleanFlow F-31 Troubleshooting Guidelines Issues Possible Causes Solutions The inlet and outlet valves of the CleanFlow For single filter operation, fully open F-31 are not open or are not fully open. primary filter inlet valve A and primary filter outlet valve C (Figure 4).
