3.3 Troubleshooting

Issues
The inLoop™ ACE is not actuating
properly.
The sample container is not filling.
28
IOM-224 MODEL: INLOOP™ ACE
Table 7: inLoop™ ACE Troubleshooting
Possible Causes
The hydraulic supply may be too low or
not operating.
The pneumatic supply may be too high,
too low, or not operating.
The solenoid may not be operating
properly.
The inlet valve on the sample container
may be closed.
The outlet on the sample container may
be open.
The inLoop™ ACE is not collecting the
correct sample volume.
The inLoop™ ACE may be set at a slower
sampling frequency than desired.
REV: A 13839 West Bellfort Street, Sugar Land, TX 77498
Solutions
Refer to Figure 8 to determine the
appropriate setting for the supply. Inspect
the electro-hydraulic unit (EHUC). Add
hydraulic oil as necessary. If the EHUC is
not operating, refer to the Installation,
Operation, and Maintenance (IOM)
Manual for the EHUC.
Inspect the pneumatic supply and
regulator to ensure that air is supplied at
the appropriate pressure (Figure 8).
Use the manual override button on the
solenoid and ensure proper operation. If
the solenoid is operating improperly, refer
to the Installation, Operation, and
Maintenance (IOM) Manual for the
solenoid.
Ensure that the sample inlet valve on the
sample container is open during
sampling.
Ensure that the sample outlet valve on the
sample container is closed during
sampling.
Welker recommends the Welker
Checkpoint™ Sample Bite Verification
Panel for verifying the sample volume of
the inLoop™ ACE. See Section 2.2,
Installing the Unit, for instructions on
adjusting the sample volume.
Adjust the inLoop™ ACE to sample at the
desired rate. Ensure that the calculations
used to determine the sample frequency
are correct (Figure 9).
