PowerVision PowerRay User Manual page 14

Supported mobile device iPad installation illustration
1.Pull out the screw on the supported mobile device.
2.Remove the middle splint from the front of the supported mobile device.
3.Install the lower end of the mobile device into the remote controller mobile device socket.
4.Clip the iPad on the front of the mobile device and make sure it is clamped.
Control and operation
In order to prevent accidental joystick control damage to people or equipment, the
PowerRay first needs unlock operation to control the propeller through the joystick. After
locking, the propeller is not controllable.
Unlocking: first dial the left thumbwheel to
the very left, then press the camera/Fish Finder
interface switch button until 1 second later,
there's vibration to unlock. After unlocking,
the joystick can control the propeller rotation.
battery level.
Locking: first dial the left thumbwheel to the
very right, then press the camera/Fish Finder
interface switch button until 1 second later,
there's vibration to lock. After locking, if
controlling the joystick, the propeller will not be
responding.
H
M
L
H
M
E
H
M
E
11
