  • Page 1 PowerEgg User Manual PEGF-E1.3 PowerVision...

  • Page 2: Table Of Contents

    Contents ........................1 Product Overview Introduction..........................1 Feature Highlights........................1 Components of the Aircraft.......................2 Components of Remote Controller..................3 Preparation of the Aircraft......................6 Preparation of Remote Controller and Base Station.............8 ..............................9 Aircraft Overview of the Aircraft......................9 Flight Modes..........................9 Accessibility..........................10 Aircraft Status Indicator......................14 Description of Aircraft Status Indicator.................15 Visual Positioning System......................16 Propellers...........................18 Intelligent Battery........................18...
  • Page 3 Maestro Operation......................28 ™ Maestro Turn On/Off....................29 ™ Maestro Charge......................29 ™ Maestro Control......................30 ™ Maestro Indicator......................32 ™ Base Station ..........................33 Overview of Base Station.....................33 Operation of Base Station....................33 Turn On/Off........................33 Charge..........................34 Indicator ........................34 Connection........................35 Frequency Match of Base Station................35 Gimbal Camera ........................36 Overview of Gimbal Camera....................36 Gimbal Usage........................36...
  • Page 4 Map Direction Lock......................43 Image Transmission......................43 Taking Photos/Shooting....................43 Settings..........................43 Media .............................46 Service ............................46 Flight ..............................47 Flight Restrictions and Special Area Limited Flight............47 Flight Environment Requirements..................47 Connection of Aircraft, Remote Controller and Vision+.............49 Compass Calibration......................51 Start/Stop The Motor......................53 Emergency Stop........................54 Basic Flight..........................55...

  • Page 5: Product Overview

    Product Overview Introduction PowerEgg is a ight system which consists of an aircraft, a gimbal camera, a standard remote controller, a gesture-based remote controller, a base station and Vision+, the ight app for iOS or Android. The user may perform ight over the aircraft by connecting the standard or gesture-based remote controller to the base station.
  • Page 6 Aircraft 1.4K UHD camera on 3-axis gimbal 2.Micro SD card slot 3.Optical positioning sensors and ultr- asonic positioning system 4.Aircraft front LED indicator 5.Aircraft Status LED indicator 6.Brushless, low friction motor pods 7.Propellers 8.Power switch/Landing gear control/ Frequency button 9.Battery compartment access button...
  • Page 7 Standard Controller 1.Mode switch 2.Left joystick 3.Right joystick 4.landing gear button 5.Take off/land/stop landing 6.Status/battery indicator 7.Return-to-home/Cancel 8.Top right button: take photos/videos 13.Left top button: gimbal back to position 9.Right nger wheel: gimbal yaw with short press/sel e with double press/ 10.Micro USB charging port gimbal face downward with long press 11.Port: connect to base station...
  • Page 8 Maestro Gesture-based Controller ™ 1.StatusBattery indicator 2.Joystick: gimbal control 3.Custom button 4.Ascend button 5.Descend button 6.Take off/land/stop landing 7.Return-to-home/cancel 8.Take photos/videos 9.Gesture activation 10.Power switch 11.Port: connect to base station 12.Micro USB charging port...
  • Page 9 Base Station 1.Battery indicator 2.Image transmitting signal indicator 3.Power switch 4.Cell phone connection bracket 5.Tablet connection bracket 6.USB port 7.Port: connect to the controller 8.Micro USB charging port How to use bracket is presented in the graph.

  • Page 10: Preparation Of The Aircraft

    Preparation of the Aircraft 1.Spread the four arms one by one as shown. You’ll hear a clicking sound when the arms are properly positioned and self-locked. 2.Press the upper cover switch and open the top battery cover. Hold the arms and insert the battery into the chamber.
  • Page 11 4.First short press and then long press the power button to power on the device. To deploy the landing gear, quickly press the power switch three times when the blue status indicator of the aircraft is on. 5.Spread the propellers of the aircraft with both hands. 6.Place the aircraft on the ground surface at least 10m from the pilot, with the head of the aircraft (indicated by the red lights on the arms) facing the ying direction and pilot facing the tail (the power button also indicates the front of the aircraft).
  • Page 12 Preparation of Remote Controllers If the gesture-based remote controller is used for ight control, rst connect the base station and the gesture-based remote controller with a data cable. Connect the data cable to this port Connect the data cable to this port If the standard remote controller is used for ight control, connect the base station to the bracket of the standard remote controller and connect them through cable.

  • Page 13: Aircraft

    Aircraft Flight Modes PowerEgg has three different ight modes: P Mode (Professional): professional ight mode In this mode, sonar is used instead of GPS and the visual positioning system. The aircraft is essentially on full manual control. N Mode (Normal): Normal ight mode In this mode, the aircraft uses GPS or the visual positioning system, depending on their signal strength.

  • Page 14: Accessibility

    regardless of aircraft’s true orientation. There also will be a 10m-radius safe zone located around the operator. The aircraft cannot enter the safe zone and the control of the aircraft within the safe zone is disabled. Accessibility Automatic take-off Unlock the aircraft and ensure ight conditions for either via GPS signals or the visual positioning system meet minimum requirements.
  • Page 15 Smart return-to-home behavior The return-to-home behavior depends on the location of the aircraft when it is switched to return-to-home mode. 1.When the aircraft is located within 10m horizontally from the return-to-home point, it deploys the landing gear and automatically lands on the spot. Return point Less than 10m 2.If the aircraft ies higher than the return altitude (default value: 20m) beyond 10m, it rst...
  • Page 16 If the aircraft ies lower than the return altitude beyond10m, it rst vertically climbs to the return altitude, then turns the head to the operator and returns to the point above the return point. Then, the aircraft turns the tail towards the operator, deploys the landing gear and vertically lands on the ground.
  • Page 17 Smart return-to-home can be realized in three patterns: lost control return, one-click return and low power return 1.Lost control return In the case of loss of signal, the aircraft rst hovers in the air and then triggers lost control return in 10 seconds. After gaining signal of the remote controller again, the aircraft switches to the mode used prior to the loss of signal and continues to y.

  • Page 18: Aircraft Status Indicator

    Aircraft Status Indicator Each arm of PowerEgg has a head indicator (head lamp) and an aircraft status indicator (tail lamp).The following gure indicates the speci c locations of the indicators. Head indicator...

  • Page 19: Description Of Aircraft Status Indicator

    The head indicator is used to identify the head direction. When the power of the aircraft is turned on, the indicator is normally on and lights in red. The tail indicator gives information about status of the aircraft, with different ashing modes indicating different statuses. Description of Aircraft Status Indicator The head indicator is red when the aircraft is powered and the system is operating normally.

  • Page 20: Visual Positioning System

    Quick ashing in white Shutdown process Code matching of remote controller Slow ashing in blue Alarm of low battery or loss of signal of remo- Slow ashing in red te controller Successful mode switching; successful task Flashing in green execution; successful sensor calibration Slow ashing in red In a no- y zone where take-off is forbidden Visual-aided Positioning System...
  • Page 21 Optical ow positioning system The optical ow positioning system applies to any environment having a height not greater than 3m and with weak or no GPS signals, particularly for indoor ight. See the gure below. Less than 3m Using steps of the optical ow positioning system 1.Switch the remote controller to N Mode: normal ight mode.

  • Page 22: Propellers

    PowerEgg uses customized high-performance 10.5-inch folding propellers. Intelligent Battery PowerEgg is equipped with a specially designed smart ight battery which has a capacity of 6,400 mAh, operates at a voltage of 14.8V and has charging-discharging management capabi- lites. The battery consists of high-energy cells and an advanced battery management system to guarantee adequate power supply to the aircraft.
  • Page 23 Make sure the intelligent battery is fully charged before its rst use. Please refer to “Battery charging” for details. Functions of the intelligent battery The intelligent battery has the following functions: 1.Battery status display: the battery has a status indicator to indicate current status of the battery.
  • Page 24 Please carefully read and abide by the requirements of PowerEgg provided in this manual, the disclaimer and the tag on the battery before use. The user shall assume the consequences for not using the battery as instructed.
  • Page 25 2.It’s not recommended to use the battery at ambient temperature lower than -10℃. 3.It is suggested to end the ight when a low-voltage warning is sent from the PowerEgg Ground Station in a cold environment. 4.It is suggested that the battery be preheated to over 5℃ at the minimum, or over 20℃...
  • Page 26 Do not insert or remove the battery when it is turned on. The smart battery must be charged using the special charger supplied by PowerVision. PowerVision will take no responsibility for the consequences of not using the chargers provided by PowerVision.

  • Page 27: Remote Controller

    3-axis gimbal. The built-in rechargeable battery in PowerEgg stan- dard remote controller has a capacity of 3,000mAh and can continuously work for 20 hours.

  • Page 28: Operation Of Standard Controller

    Operation of Standard Remote Controller Startup and shutdown of standard remote controller The remote controller may be started by sliding the power switch from the left to the right. The connection status of the remote controller may be distinguished according to the noti cation tone of the remote controller.

  • Page 29: Standard Remote Controller Indicator

    The battery of the remote controller should be charged with the special charger of cially designated by PowerVision, which will not be liable for any consequences caused by charging the battery with the charger not of cially provided by PowerVision.
  • Page 30 Mode 2: The left joystick of the remote controller controls the up/down of the aircraft. Mode 1: The right joystick of the remote controller controls the up/down of the aircraft. Left joystick Right joystick Up/down Turn left / turn right Forward/backward Left/right Start of motors: Position both joysticks towards the bottom center like a “V”...
  • Page 31 Left nger wheel:for the control of the gimbal pitch. Right nger wheel:for the control of gimbal yaw. Left top button:The gimbal back to position by short pressing the key; press the key until there is a vibration, and the gimbal faces downward; short press the key for 2 times, sel e mode is triggered.
  • Page 32 3-axis gimbal pitch, taking photos and video shooting. Users can easily complete various operations of the aircraft with the assistance of the remote controller. The built-in rechargeable battery in PowerEgg gesture-based remote controller has a capac- ity of 1,500mAh and can continuously work for 10 hours. The current battery level may be checked via the battery level indicator.
  • Page 33 Start-up and shutdown of gesture-based remote controller The remote controller may be started by sliding the power switch from the left to the right. The connection status of the remote controller may be distinguished according to the noti - cation tone of the remote controller. When the remote controller plays music for 1 second, it indicates that the communication connection between the remote controller and the aircraft is successful.
  • Page 34 The battery of gesture-based remote controller should be charged with the special charger of cially designated by PowerVision, which will not be liable for any consequences caused by charging the battery with the charger not of cially provided by PowerVision.
  • Page 35 Under normal circumstances, the motor may be automatically stopped when the aircraft lands. One-click takeoff/landing button： When the aircraft has not taken off, press and hold the key until there is a vibration, and the aircraft begins to take off; when the aircraft takes off, press the key again until there is another vibration, and the aircraft begins to land;...
  • Page 36 Indicator for gesture-based remote controller The gesture-based remote controller has a three-color battery level indicator. The indicator shows the battery level of the battery when the remote controller is on (whether charging or not): In case of charging when the remote controller is off, the indicator is red, indicating charging; when the remote controller is fully charged, the indicator is green, indicating full charging;...

  • Page 37: Base Station

    Overview of Base station This section describes PowerEgg base station, including its usage and precautions. The working frequency band of PowerEgg base station is 2.4Ghz. The base station integrates advanced 4K/HD image transmission system, can directly output HD aerial image to mobile device, and can support mobile phones, tablet computers, and other mobile smart devices with different speci cations.

  • Page 38: Indicator

    Charging of base station The base station should be charged with the special charger supplied by PowerEgg for 5h. The red Micro USB port should be used for charging. Base Station The module will be fully charged in 5h. Indicator of base station The built-in rechargeable battery of the wireless base station has a capacity of 6,000mAh.

  • Page 39: Connection

    2) Open Vision+ APP and connect the mobile device to the base station. 3) Go the PowerEgg product page on the APP and press on the logo on the upper left corner shown in right screen shot.
  • Page 40 If the linking between aircraft and base station is not successful, it will be required to reset the base station and the aircraft before linking. Please follow the below steps: 1. Reset the aircraft: a. Power on the aircraft and wait the aircraft to complete the starting sequence. b.

  • Page 41: Gimbal Camera

    4K UHD Gimbal Camera Overview of 4K UHD Gimbal Camera This section describes the technical parameters of the camera, and the range of motion and work mode of 4K UHD gimbal camera. Three-axis stabilized gimbal helps the camera isolate the gesture and high-frequency vibration of the aircraft. The control accuracy is up to 0.05° to help the camera take stable and smooth pictures and conduct video shooting.

  • Page 42: Introduction To Vision

    Introduction to Vision+ Overview of Vision+ PV ground control system is the UAV software of PowerEgg. Users can obtain the status information of PowerEgg and can control UAV, 3-axis gimbal and camera module via Vision+. Download APP and other resuoces Please scan QD code to download Vision + APP, PC Suite, User Manual, Speci cation and watch video tutorials.
  • Page 43 Systems-Check of the aircraft When the equipment is connected, click the “Start Flying”. A systems check will com- mence. Flying is only possible after the aircraft passes the systems-check. If something fails the systems-check, it must be resolved prior to ight.

  • Page 44: Display Of Relevant Parameters

    Display of relevant parameters Aircraft altitude: it displays N/A if there is no value, and displays the current altitude of the aircraft if there is a value. Man-machine distance: the distance between the aircraft and the operator. Vertical velocity: velocity of vertical rise and fall of the aircraft. Horizontal velocity:the ight velocity of the aircraft at current level.

  • Page 45: One-Click Return Home

    One-click return-to-home One-click return-to-home: the aircraft return-to-homes automatically; if “return-to-home point setting” is set, it return-to-homes to the user assigned location; if “return-to-home point setting” is not set, it return-to-homes to the takeoff point. See the “Smart return-to-home” section for details. Route planning Click “waypoint planning”...

  • Page 46: Flight Modes

    Flight Mode Flight modes include circling mode, sel e mode and follow mode. Orbit mode:The aircraft will orbit a point set by the user in the Vision+ software. Following mode: when the following mode is started, the aircraft will follow the position of the remote controller at certain distance.

  • Page 47: Positioning

    Electronic fence Click “safe zone” to select a safe zone on the map. The aircraft will y within the safe fence in the selected zone. When the aircraft ies outside the electronic fence, it will return-to-home and may stop return-to-home when it enters the electronic fence and keep ying in the original mode. Positioning Positioning: human positioning and aircraft positioning.

  • Page 48: Settings

    Locking of map orientation Locking of map orientation:the map orientation is locked by default. Map locked:the map orientation will not change by rotating the phone left and right. Map unlocked:the map orientation will change by rotating the phone left and right. Back transmission of images The UAV has a camera image transmission device, which transmits images via RF, data transfer radio or satellite to the base station.
  • Page 49 Flight control setting Aircraft attitude and compass calibration:when the magnetometer of the aircraft is abnormal, magnetic calibration should be performed manually according to the prompt. Aircraft landing threshold:users may self-de ne a minimum battery level for forced land- ing of the aircraft. No- y zone restriction:when no- y zone restriction is switched on, the aircraft cannot y in the zone in an unlocked manner.
  • Page 50 Link setting Channel selection: users can select a self-de ned channel according to the interference conditions to realize the optimum ight experience. Automatic setting of the channel: when started, it will automatically select the channel for you without manual setting. Video code rate setting: users can set the code rate for image transmission according to their own needs.

  • Page 51: Media

    Media Library It is used to manage photos and videos taken by the aircraft. Here you can upload, down- load, share, edit and delete pictures and videos. Service The Service module includes four sub-modules: Flight Academy, Flight Peripherals, Technical Support, and Repair Application. If you click to enter the corresponding module, it will directly skip to the secondary function page.

  • Page 52: Flight

    Flight Flight Restrictions and Special Restricted Areas In view of the management system for UAV and airspace control of each country’s civil avia- tion authority, the UAV should not y in certain speci c airspaces to ensure safety. Vision + will prompt the user when the aircraft enters these restricted areas from unrestricted areas, and the user can choose whether to continue the ight.
  • Page 53 sea level) due to environmental factors resulting in performance degradation of the battery and power system of the aircraft. 4.GPS mode cannot be used in Antarctic Circle or Arctic Circle, where attitude mode and visual positioning system can be used. <120m Fly in an open and Keep your...
  • Page 54 Connect the Aircraft, Remote Controller and Vision+ 1.Start the standard remote controller / gesture-based remote controller and the base station. 2.Turn on your phone and connect WIFI: Power _ Groundxxx with the password: 1234567890. Enter Password WIFI Password 1234567890 WIFI √...
  • Page 55 4.For outdoor ight under the mode of P/N/E, wait until aircraft status indicator becomes green, and the status indicator of standard controller or Maestro turns green. This indicates ™ the aircraft is prepared for unlocking and ight. *Base station uses a 5GHz Wi connection. Only Mobile devices with a 5G WiFi can be used to connect to the Base station.

  • Page 56: Compass Calibration

    Compass Calibration Precautions The compass must sometimes be calibrated before ight. As the compass is susceptible to the complex environment outside, when calibrating the compass, attention should be paid to the following matters in order to ensure the accuracy of the compass. This is to ensure an ideal condition of the aircraft.
  • Page 57 Power button facing forward Power button facing upward 3.When the three setting positions in the interface are all green, the calibration is complete. Conditions requiring recalibration 1.The ight site is far from the site of last calibration; 2.It spins in ight or cannot y in a straight line.
  • Page 58 Start-up/Shutdown of the Motor Start the motor Connect the remote controller, and pull the sticks down and in to start the motor. For the standard remote controller, pull both joysticks inward and downward to start the motor. After the motor is started, release the joysticks quickly. For the gesture-based remote controller, press the Ascend key, then press and hold the Descend key to start the motor.
  • Page 59 In-air motor shutdown method The in-air motor shutdown method can only be used to shut the motor down in case of special conditions (such as when an aircraft is crashing into a crowd) where emergency shutdown is needed to minimize personnel injury. Note: The aircraft will fall to the ground and most likely be destroyed.

  • Page 60: Basic Flight

    Basic Flight 1.Take out the aircraft, the battery, the base and the remote controller/ base station from the package, and place the aircraft on the base. 2.Release the buckles at the end of the arms to open the four arms in turn. 3.Open the aircraft’s top cover to place the battery into the body and fasten the cover.
  • Page 61 14.You can also use the remote controller by slowly pushing the Ascend/Descend joystick, to take-off. 15.If descending is needed, slowly pull down the Ascend/Descend joystick, so that the aircraft slowly and steadily lands on the ground. 16.After landing, pull the Ascend/Descend joystick to its lowest position and hold for more than two seconds until the motor is shut down.
  • Page 62 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 63 70100026-00 PowerVision Get it on Copyright 2017 ©Powervision Robot Inc. All rights reserved.
