BASKETBALL PROBASE PROBASE Installation Manual page 3

INSTALLATION GUIDE
COMPONENTS
I
J
L
K
H G H
A
Stake (2 identical components)
B
Main pole holder
C
Pivot
D
Pivot base
E
Removable front cover
F
Pressure plate
G
Tapping block (plastic or wood)
*For assemblies including flange nuts (intergrated washer nuts), you will not have flat washers in your kit.
D C
F E
M
- 3 -
B
H
Tapping block Holder
I
Handle bolts
J
Bolts
K
Nuts
L
Flat washers
M
Self-adhesive rubber pad
(included only with plastic
tapping blocks)
A
*
