Page 2: Table Of Contents
PLANET ..........................19 3.1.3. MERCURY ..........................20 3.1.4. TECHNICAL CHARACTERISTICS....................21 3.1.5. PREPARATION AND PACKAGING ....................22 3.2. INSTALLATION OF THE CERAMIC CLADDING FOR OMEGA-PLANET ..........23 3.3. ELECTRICAL CONNECTION......................23 3.4. 4. OPERATION .............................24 WARNINGS PRIOR TO FIRST LIGHTING ..................24 4.1. CHECK PRIOR TO FIRST LIGHTING....................25 4.2. - Page 3 ELECTRICAL DIAGRAM SATURN - OMEGA - PLAMET................47 7.1. ELECTRICAL DIAGRAM MERCURY ....................48 7.2. Maintenance and/or replacement of the electronic board..............49 7.3. SPARE PARTS COMMON TO SATURN, OMEGA AND PLANET .............50 7.4. SPARE PARTS MERCURY .......................56 7.5. Index Technical service - Rights reserved MCZ S.p.A. –Reproduction prohibited...
-
Page 4: Introduction
Dear Customer, We would like to thank you for the preference which you have decided to bestow on MCZ products, and particularly for choosing one of the MCZ Pellet range. We are convinced that as you use it, you will appreciate the quality of the product, which is the fruit of careful planning and meticulous testing. - Page 5 This indicates a series of buttons to push to access a menu or to make adjustments. VIEW MESSAGES: This symbol tells the user to view the messages shown on the control display. Introduction Technical service - Rights reserved MCZ S.p.A. –Reproduction prohibited...
-
Page 6: Warnings And Guarantee Conditions
– there is a fire hazard. • All responsibility for improper use is taken entirely by the user and such use relieves MCZ of any civil or criminal responsibility. • Any kind of tampering or unauthorised substitution of... -
Page 7: Operating Warnings
• Only fuel recommended by MCZ must be used (for Italy only pellets with a diameter of 6mm, for other European countries with a diameter of 6-8mm) and provided exclusively by the automatic supply system. -
Page 8: Guarantee Conditions
MCZ's specification (see the relevant chapters in this user manual). MCZ refuses to accept any responsibility for any damage which may be caused, directly or indirectly, by persons, animals or things in consequence of the failure to observe all the prescriptions laid down in Warning and guarantee conditions Technical service –... - Page 9 WITH DIRECTIVE 89/336 and 72/23 and SUCCESSIVE AMENDMENTS MCZ refuses to accept any responsibility in the event that the stove or any other accessory have been improperly used or modified without authorisation. For all replacement of parts, only original MCZ spare parts must be used.
-
Page 10: Theoretical Notions On Installation
Pellet fuel In order to guarantee the stated hourly consumption rates and to optimise combustion, for pellet stoves MCZ has prepared a patented method which makes it possible to identify and classify any kind of pellet with a diameter of 6 mm and 8 mm based on its specific weight and piece size. -
Page 11: Principles Of Operation
- SEE SECTION DRAWING ON NEXT PAGE - Theoretical notes for installation Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 12: Section Plane Of An Mcz Pellet Stove
Combustion air intake Ø 50 Primary combustion air Central ash drawer Smoke sensor Smoke discharge Ø 80 Side ash drawer Hot air fan Smoke aspirator Door handle Theoretical notes for installation Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 13: Working Environment
If there is wood flooring, place a floor protection and adhere to national standards currently in effect. Example of installation with Saturn stove Theoretical notes for installation Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 14: Precautions
• be positioned in such a way as to be impossible to obstruct Theoretical notes for installation Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 15: Connection Of The Smoke Discharge Pipe
FOR FLUE PIPE CONNECTION DO NOT USE MORE THAN 2-3 M. OF HORIZONTAL PIPES AND DO NOT USE MORE THAN THREE 90° BENDS Example of installation with Saturn stove Theoretical notes for installation Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 16: Connection To The Flue Pipe
Fig. 7 periodic checking and cleaning, which must be done annually. Make a gas-tight connection to the flue pipe, using pipes and connectors as recommended by us. Theoretical notes for installation Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 17: Operating Abnormalities Due To Flue Draught Problems
Hazardous conditions can only be overcome by suitable setting-up of the stove carried out by qualified MCZ personnel. Theoretical notes for installation Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 18: Installation And Assembly
PELLET STOVE Chapter 3 INSTALLATION AND USE MANUAL page 3. INSTALLATION AND ASSEMBLY DRAWINGS AND TECHNICAL CHARACTERISTICS 3.1. 3.1.1. SATURN Installation and assembly Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 19: Omega
PELLET STOVE Chapter 3 INSTALLATION AND USE MANUAL page 3.1.2. OMEGA Installation and assembly Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 20: Planet
PELLET STOVE Chapter 3 INSTALLATION AND USE MANUAL page 3.1.3. PLANET Installation and assembly Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 21: Mercury
PELLET STOVE Chapter 3 INSTALLATION AND USE MANUAL page 3.1.4. MERCURY Installation and assembly Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 22: Technical Characteristics
230 V - 50 Hz. * Data that may vary depending on the type of pellets used. ** For ITALY use only pellets with a diameter of 6mm Installation and assembly Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 23: Preparation And Packaging
PREPARATION AND PACKAGING 3.2. Saturn, Omega and Planet stoves are delivered in two packages: The first contains the body (Fig. 1) The second contains the ceramic cladding (Fig. 2) Open the packaging, take off the bands, remove the stove unit from the pallet and position it in the chosen location, taking care that its position complies with the above instructions. -
Page 24: Installation Of The Ceramic Cladding For Omega-Planet
The main switch located on the rear of the stove should be switched on only when you want to light the stove. If you do not intend to use the stove, it is advisable to keep it switched off. Installation and assembly Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 25: Operation
Try to get familiar with the commands given form the control panel or remote control. Try to memorize the messages that the stove sends you by means of the display panel. Operation Technical Service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 26: Check Prior To First Lighting
Then pour in the second half. Never remove the protective grille from inside the hopper. When loading pellets, avoid the bag coming into contact with hot surfaces. CONTROL PANEL and REMOTE CONTROL 4.4. Operation Technical Service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 27: Remote Control And Battery Replacement
4.5.1. Setting current time Press the MENÙ key twice. The display will show the message SET DAY and it is possible to set the day of the week using the buttons Operation Technical Service – Rights reserved MCZ S.p.A. – Reproduction prohibited HOUR... -
Page 28: Selection Of Recipe
SELECTION OF RECIPE 4.6. DEUTSCH This is an exclusive MCZ evaluation criteria which allows the user to identify the type of pellet he has at his disposal and therefore to set the stove up in the most appropriate manner. This helps to avoid excessive fuel use, ensures the intended heating potential is achieved and protects the integrity of the product. - Page 29 Weigh the total (measure + pellets) and note the weight. Take the measure, empty it and turn it so as identify the graphic data that is used for the choice of the recipe. Fig.21 Operation Technical Service – Rights reserved MCZ S.p.A. – Reproduction prohibited...
-
Page 30: First Lighting
Omega-Planet and Saturn make available to you (see paragraph 4.9) 4.7.1. -
Page 31: Lighting From Remote Control
The display (8) will show the message "OFF". The stove will now automatically start the shutdown phase, during which it will interrupt the flow of fuel and the flame will be extinguished. Ventilation will Operation Technical Service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 32: The Shape
Lively or feeble, this is closely connected to the shape of the flame. Figure 2 ABNORMAL COMBUSTION Shape: enlarged irregular compact Character: Tenuous - feeble Colour: Orange - yellow Operation Technical Service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 33: Manual And Automatic
INSTALLATION AND USE MANUAL page OPERATING MODES 4.9. The SATURN and OMEGA-PLANET stoves basically have three operating modes. 4.9.1. Manual and automatic The stove can operate in one of these two different operating modes. MANUAL mode allows only adjustment of the flame from power 1 to power 5, ignoring any ambient temperature measurement. -
Page 34: Automatic Mode
In must be placed in a median location in the room of installation, so as to better monitor the room temperature. The procedure to follow for the connection of the external thermostat is the following: Operation Technical Service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 35: Automatic Mode With Eco-Stop
Connect the two wires of the cable from the thermostat to the Wiring from connector terminal of the MCZ connector (not included with the stove). external thermostat Insert the connector in the appropriate serial socket located on the back of the stove. -
Page 36: Eco-Stop Mode Activation
To continue scrolling the various programmes for turning the timer on/off, just press the key To exit the timer menu at any time, press the button Operation Technical Service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 37: Programme
To exit press . Programme 4.9.5.3. The Saturn and Omega-Planet stoves can be set with up to 4 operating programmes divided over the course of the entire day or entire week. Each programme is characterized by three basic steps: •... - Page 38 Keep this in mind in order to obtain substantial fuel savings. Operation Technical Service – Rights reserved MCZ S.p.A. – Reproduction prohibited...
-
Page 39: Safeties
To understand what sort of problem has arisen, refer to paragraph 4.11.1 of this manual which explains what to do based on the kind of alarm message the stove is showing. Operation Technical Service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 40: Alarm Indications
Occurs when the stove goes out and when the Derives from a failure to light. See above. ALARM temperature of the smoke sensor is below the NO FIRE preset threshold. Operation Technical Service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 41: Other Alarm Signals
If the message "Alarm Press" appears, you need to check if ALL of the smoke duct, including the combustion chamber, is clean and free of obstructions. (it is advisable to have this done by a specialized MCZ technician) Only after the cause of the blockage has been permanently eliminated can a fresh attempt to relight the stove be made. -
Page 42: Shutting Down The Stove
This occurs to allow the combustion fumes to be ducted into the flue pipe by means of the extractor. It also means that there is total recovery of the heat yielded by combustion to the structure of the stove. Operation Technical Service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 43: Maintenance And Cleaning
Fig.28 ATTENTION ! Do not spray the product on the painted parts or on the door seals (ceramic fibre cord). Fig. 28 – Glass cleaning Maintenance and cleaning Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 44: Cleaning To Be Done By A Specialized Technician
ATTENTION ! Disconnect the electricity supply cable. Fig. 31 – Lower plug Maintenance and cleaning Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 45: Check Of Internal Components
(3.15 AT delayed type). Fig.37 Fuse Vano Push the electric plug back in, and press the main switch. compartment If the problem persists or the fuse blows again, contact an MCZ retailer. fusibili CHECK OF INTERNAL COMPONENTS 5.3. ATTENTION ! -
Page 46: Problems / Causes / Solutions
Check the state of the door gaskets. 21. Damp or unsuitable pellet. 21. Change the type of pellet. 22. Aspiration motor faulty. 22. Check the motor and replace if necessary. Problems/Causes/Solutions Technical serivce – Rights reserved MCZ S.p.A. – Reproduction prohibited... - Page 47 ATTENTION ! The operations marked in bold type must be carried out by specialised MCZ personnel. The manufacturer refuses accept responsibility guarantee lapses if this condition is not respected. Problems/Causes/Solutions Technical serivce – Rights reserved MCZ S.p.A. – Reproduction prohibited...
-
Page 48: Electrical Diagrams And Spare Parts
PELLET STOVES Chapter 7 INSTALLATION AND USE MANUAL page 7. ELECTRICAL DIAGRAMS and SPARE PARTS ELECTRICAL DIAGRAM SATURN - OMEGA - PLAMET 7.1. Problems/Causes/Solutions Technical serivce – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 49: Electrical Diagram Mercury
PELLET STOVES Chapter 7 INSTALLATION AND USE MANUAL page ELECTRICAL DIAGRAM MERCURY 7.2. Problems/Causes/Solutions Technical serivce – Rights reserved MCZ S.p.A. – Reproduction prohibited... -
Page 50: Maintenance And/Or Replacement Of The Electronic Board
LIVE ELECTRICAL WIRES If you think that the electronic board may be defective or requires DISCONNECT THE maintenance, contact an authorized MCZ technical service centre to do POWER CABLE BEFORE the work PERFORMING ANY OPERATION ON THE ELECTRONIC BOARDS Send the defective or damaged board to MCZ Spa. -
Page 51: Spare Parts Common To Saturn, Omega And Planet
PELLET STOVES Chapter 7 INSTALLATION AND USE MANUAL page SPARE PARTS COMMON TO SATURN, OMEGA AND PLANET 7.4. Spare parts Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... - Page 52 PELLET STOVES Chapter 7 INSTALLATION AND USE MANUAL page Spare parts Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited...
- Page 53 PELLET STOVES Chapter 7 INSTALLATION AND USE MANUAL page Spare parts Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited...
- Page 54 PELLET STOVES Chapter 7 INSTALLATION AND USE MANUAL page PARTS EXCLUSIVELY FOR SATURN Spare parts Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited...
- Page 55 PELLET STOVES Chapter 7 INSTALLATION AND USE MANUAL page PARTS EXCLUSIVELY FOR OMEGA Spare parts Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited...
- Page 56 PELLET STOVES Chapter 7 INSTALLATION AND USE MANUAL page PARTS EXCLUSIVELY FOR PLANET Spare parts Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited...
-
Page 57: Spare Parts Mercury
PELLET STOVES Chapter 7 INSTALLATION AND USE MANUAL page SPARE PARTS MERCURY 7.5. Spare parts Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited... - Page 58 PELLET STOVES Chapter 7 INSTALLATION AND USE MANUAL page Spare parts Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited...
- Page 59 PELLET STOVES Chapter 7 INSTALLATION AND USE MANUAL page Spare parts Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited...
- Page 60 PELLET STOVES Chapter 7 INSTALLATION AND USE MANUAL page Spare parts Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited...
- Page 61 66. SCREW 31. SCREW 67. SCREW 32. AIR FAN 68. REAR HOOK 33. FAN GRILLE 69. PIN FOR TILE 34. MANUAL RESET THERMOSTAT 70. TILE 35. SCREW 36. SCREW Spare parts Technical service – Rights reserved MCZ S.p.A. – Reproduction prohibited...
- Page 62 MCZ S.p.A. Via Guglielmo Oberdan n°86 33070 Vigonovo di Fontanafredda (PN) – ITALY Telephe: +39 0434 599599 Fax: +39 0434 599598 Internet: www.mcz.it e-mail: mcz@mcz.it Document code: 89040258 Rev.4 Edition: 10/2006...
