- Page 1 DP2502-07-CM GEO S12 – LS18 GEO S1210 & GEO S1230 Tangent Array Modules LS18 Subwoofer System manual System Manual GEOS12 LS18...
-
Page 2: Table Of Contents
2.1.3 Configuring GEO S12 for passive or active mode ....................9 ................................... 10 ABLING GEO S12 & LS18 ..................10 RECOMMENDED AMPLIFICATION GEO S12 & LS18 NEXO TD C ................10 SETUPS ON ONTROLLERS CONNECTION DIAGRAMS ........................11 GEO S12 ( ) / NXAMP4 2 (B ) .............. - Page 3 CONTENTS 6.4.6 Two GEO S12 vertically ..............................47 6.4.7 Two or more GEO S12 flown horizontally ......................48 6.4.8 LS18 and three or more GEO S12 flown vertically ..................... 51 6.4.9 Ground stacked LS18 and GEO S12 ........................... 55 ....................60 ESTING AND AINTENANCE OF THE SYSTEM SYSTEM CHECK ALIGNMENT GUIDELINES ..................
- Page 4 A comprehensive understanding of GEO theory, tangent arrays, and specific features of the GEO S Series will help you to operate your system at its full potential.
-
Page 5: Please Read Carefully Before Proceeding
User Manual. Failure to do this exposes people to potential injury or death. Please check the web site nexo-sa.com for the latest update. Always consult qualified NEXO personnel if the device installation requires construction work and make sure to observe the following precautions: Mounting precautions choose mounting hardware and an installation location that can support 4 times the weight of the speaker system;... - Page 6 PLEASE READ CAREFULLY BEFORE PROCEEDING HIGH SOUND PRESSURE LEVELS Exposure to extremely high noise levels may cause permanent hearing loss. Individuals vary considerably in susceptibility to noise-induced hearing loss but nearly everyone will lose some hearing if exposed to sufficiently intense noise for a sufficient period of time. The U.S. Government’s Occupational and Health Administration (OSHA) has specified the following permissible noise level exposures: Sound Duration Per Day In Hours Sound Level dBA, Slow Response...
-
Page 7: Introduction
INTRODUCTION NTRODUCTION Thank you for selecting a NEXO GEO S12 Series Tangent Array System. This manual is intended to provide you with necessary and useful information about your GEO S12 & LS18 System, which includes the following products: • GEO S1210 is a 10° Tangent Array Module. It comprises 1x12” (30cm) 16 ohms Neodymium LF/MF driver loaded by a Phase Directivity Device ) and 1x1.4”... -
Page 8: Geo S12 General Set-Up Instructions
GEO S12 GENERAL SET-UP INSTRUCTIONS GEO S12 G ENERAL NSTRUCTIONS GEO S12 and LS18 connections GEO S12 and LS18 are connected with Speakon NL4FC plugs (not supplied). A wiring diagram is printed on the connection panel located on the back of each cabinet. The 4 pins of the Speakon sockets identified in / out are connected in parallel within the enclosure. -
Page 9: Configuring Geo S12 For Passive Or Active Mode
GEO S12 GENERAL SET-UP INSTRUCTIONS 2.1.3 Configuring GEO S12 for passive or active mode Remove the six TORX screws that hold the connector panel. Remove the connector panel so that filter WAGO connectors become accessible. GEOS12 connector panel GEOS12 WAGO connectors In Passive Mode, connector A (from filter) should be inserted in connector B (PCB “Passive In”), and connector D (“Passive Out”) should be connected to speakers via connector C. -
Page 10: Cabling
GEO S12 GENERAL SET-UP INSTRUCTIONS Cabling NEXO recommends the exclusive use of multi-conductor cables to connect the system: the cable kit is compatible with all the cabinets, and there is no possible confusion between LF, MF and HF sections. Cable choice consists mainly of selecting cables of the correct sectional dimension (size) in relation to the load resistance and the cable length. -
Page 11: Connection Diagrams
CONNECTION DIAGRAMS ONNECTION DIAGRAMS GEO S12 (passive mode) / NXAMP4x1mk2 (Bridge Stereo) LS18 / NXAMP4x1mk2 (Bridge Stereo) Page 11 / 95 System Manual GEOS12 LS18... -
Page 12: Mk 2 (4 Channels Mode )
CONNECTION DIAGRAMS GEO S12 (passive mode) and LS18 / NXAMP4x1mk2 (Bridge Stereo) GEO S12 (passive mode) / NXAMP4x2mk2 (4 channels mode) Page 12 / 95 System Manual GEOS12 LS18... -
Page 13: Channels Mode )
CONNECTION DIAGRAMS LS18 / NXAMP4x2mk2 (4 channels mode) GEO S12 (passive mode) and LS18 / NXAMP4x2mk2 (4 channels mode) Page 13 / 95 System Manual GEOS12 LS18... -
Page 14: Mk 2 (4 Channels Mode )
CONNECTION DIAGRAMS GEO S12 (passive mode) / NXAMP4x4mk2 (4 channels mode) Page 14 / 95 System Manual GEOS12 LS18... - Page 15 CONNECTION DIAGRAMS GEO S12 (active mode) / NXAMP4x4mk2 (4 channels mode) Page 15 / 95 System Manual GEOS12 LS18...
- Page 16 CONNECTION DIAGRAMS LS18 Omni Mode / NXAMP4x4mk2 (4 channels mode) Page 16 / 95 System Manual GEOS12 LS18...
- Page 17 CONNECTION DIAGRAMS 3.10 LS18 Cardio Mode / NXAMP4x4mk2 (4 channels mode) Page 17 / 95 System Manual GEOS12 LS18...
-
Page 18: Mk 2 (4 Channels Mode )
CONNECTION DIAGRAMS 3.11 GEO S12 (passive mode) and LS18 / NXAMP4x4mk2 (4 channels mode) Page 18 / 95 System Manual GEOS12 LS18... -
Page 19: Simulation Software
GEO S12 and LS18 Structural Analysis Report is currently being certified by German Certification Organization RWTUV systems GmbH. NS-1 installation package includes all NEXO User Manuals, Structural Analysis Reports and Certificates PDF files. NS-1 is a freeware available on nexo-sa.com... -
Page 20: Configurable Directivity Device
CONFIGURABLE DIRECTIVITY DEVICE ONFIGURABLE IRECTIVITY EVICE The GEO Wavesource controls dispersion of acoustic energy using a hyperboloid acoustical reflector in the “coupling plane” (the vertical plane of a curved vertical tangent array) and a diffraction slot in the “non-coupling plane” (the horizontal plane of a curved vertical tangent array). -
Page 21: When & Where To Use Configurable Directivity Flanges
CONFIGURABLE DIRECTIVITY DEVICE When & where to use Configurable Directivity flanges The diagrams show audience area coverage for a stereo system. While the GEO cluster will deliver even SPL from the front to the rear of this audience area, there are “holes” near the front in the centre and at the outside edges. We cannot fill the outside coverage gaps without enlarging the centre gap, and vice versa (left figure below). -
Page 22: Geo S12 Hardware Setup Procedure
Safety first GEO S12 & LS18 Rigging System structural computations and related documents are available in NS-1 or at NEXO (info@nexo.fr) upon request. We include this section to remind you of safe practice when flying the GEO S12 & LS18 system. Please read it carefully. -
Page 23: Ground Stacking Safety
For fixed installations, wind loading has to be taken into account in accordance to the national standards. The GEO S12 & LS18 Rigging System requires regular inspection and testing by a competent test centre. NEXO recommend that the system is load tested and certified annually or more frequently if local regulations require. -
Page 24: General Description
- “Right” means HF waveguide is right as seen from front GEO S12 can be connected to bumpers “Left” or “Right” by simply flipping the cabinets. Whenever possible, NEXO recommends symmetrical designs (preferably HF waveguide inwards in stereo configurations) GEO S12 “Left”... -
Page 25: Ls18
GEO S12 HARDWARE SETUP PROCEDURE 6.2.3 LS18 LS18 incorporate two connecting plates (one per side) on which a comprehensive range of accessories can be mounted. LS18 connecting plates Angle splay setting sequences are as follow: LS18 to LS18: 0.2° LS18 to GEO S1210: -5° / -2.5° / -1.25° / 0.2° / 0.31° / 0.5° / 0.8° / 1.25° / 2° / 3.15° / 5° LS18 à... -
Page 26: Accessories
GEO S12 HARDWARE SETUP PROCEDURE 6.2.4 Accessories GEO S12 & LS18 accessories are: GPI-BUMPER VNI-UBRK12 VNI-LBRK VNI-ABRK GPI-ANPL1 GPI-ANPL2 GPI-ANPL3 LSI-CPLA VNI-IPCOV15 GPT- BUMPER GPT-XBOW LST-XBOW18 GPT-TLB VNT-XHBRK VNT- TTC GPT-SSBRK GPT-PSBRK VNT- TCBRK GPT-GSTK GPT-FLG VXT-BL820 Page 26 / 95 System Manual GEOS12 LS18... -
Page 27: Warnings On Geo S12 & Ls18 Accessories
Never use other accessories – including push-pins - when assembling GEO S12 and/or LS18 cabinets than the ones provided by NEXO: NEXO will decline responsibility over the entire GEO S12 and LS18 accessory range if any component is purchased from different supplier. -
Page 28: Installation Applications
LOCTITE 243 or equivalent for all screws used with GEO S12 & LS18 fixed installation accessories. LOCTITE 243 is available at NEXO or at your local distributor upon request. Page 28 / 95 System Manual GEOS12 LS18... -
Page 29: Single Geo S12 Rigidly Mounted On A Wall Or A Ceiling (Vertical Or Horizontal)
GEO S12 HARDWARE SETUP PROCEDURE 6.3.2 Single GEO S12 rigidly mounted on a wall or a ceiling (vertical or horizontal) Required items 1 x VNI-UBRK12 (allows all angles to be implemented) 4 x 12mm diameter screws (not provided) IMPORTANT Ensure that the surface – wall or ceiling – is strong enough to hold 4 times GEO S12 weight and that the four screws 12mm diameter and corresponding plugs required to fix the “U”... -
Page 30: Single Geo S12 Cable Mounted On A Ceiling (Vertical Or Horizontal)
GEO S12 HARDWARE SETUP PROCEDURE 6.3.3 Single GEO S12 cable mounted on a ceiling (vertical or horizontal) Required items 1 or 2 x VNI-LBRK (allows cable suspension, holes for cable suspension are 10mm diameter) 2 or 4 slings and corresponding shackles (not provided) IMPORTANT Ensure that the ceiling is strong enough to hold 4 times GEO S12 weight and that the cable suspension system required to install the cabinet under the ceiling is properly dimensioned. -
Page 31: Geo S12 Vertical Array Rigidly Mounted On A Ceiling
GEO S12 HARDWARE SETUP PROCEDURE 6.3.4 GEO S12 vertical array rigidly mounted on a ceiling Required items 1 x GPI-BUMPER (allows +/-5° bumper tilt when installed below a flat surface; if higher bumper tilt is required, surface will have to be defined accordingly) (N-1) x GPI-ANPL for a N x GEO S12 array (ANPL1 ranges from 0.2°... - Page 32 GEO S12 HARDWARE SETUP PROCEDURE Use thread lock coated screws (or if not apply Loctite 243 or equivalent to four shoulder screws) from the last GPI-ANPL Position the GPI-BUMPER bumper to required angle position and use the four shoulder screws to connect it the bumper to the top cabinet Flip GEO S12 cluster by 90°...
-
Page 33: Ls18 And Geo S12 Vertical Array Rigidly Mounted On A Ceiling
GEO S12 HARDWARE SETUP PROCEDURE 6.3.5 LS18 and GEO S12 vertical array rigidly mounted on a ceiling Required items 1 x GPI-BUMPER (allows +/-5° bumper tilt when installed below a flat surface; if higher bumper tilt is required, surface will have to be defined accordingly) (M-1) x GPI-ANPL1 for M x LS18 M x LSI-CPLA counter-plates for M x LS18... - Page 34 GEO S12 HARDWARE SETUP PROCEDURE Position angle plates and top counter-plates from GPI-ANPL to required GEO S12 inter-cabinet angle value between GEO S12 upper sides according to figure below right Use thread lock coated screws (if not apply Loctite 243 or equivalent to shoulder screws) from LSI-CPLA and GPI-ANPL kits Screw all shoulder screws so that all plates and cabinets are tightened together Flip the cluster upside down to access connector plates located on the down side...
-
Page 35: Ls18 And Geo S12 Vertical Array Cable Mounted On A Ceiling
GEO S12 HARDWARE SETUP PROCEDURE 6.3.6 LS18 and GEO S12 vertical array cable mounted on a ceiling Required items As in 2 sections above, plus 2 x VNI-LBRK (allows cable suspension for bumper, holes for cable suspension are 10mm diameter) 4 x slings and shackles (not provided) IMPORTANT Ensure that the ceiling is strong enough to hold 4 times LS18 and GEO S12 cluster weight and that the... -
Page 36: Geo S12 Horizontal Array Rigidly Mounted On A Ceiling
GEO S12 HARDWARE SETUP PROCEDURE 6.3.7 GEO S12 horizontal array rigidly mounted on a ceiling Required items 2 x VNI-ABRK (allows rigid ceiling suspension for horizontal arrays) (N-1) x GPI-ANPL for a N x GEO S12 array (ANPL1 ranges from 0.2° to 3.15°, ANPL2 ranges from 5° to 10°, ANPL3 ranges from 16°... - Page 37 GEO S12 HARDWARE SETUP PROCEDURE Position the two “U” brackets from VNI-ABRK kits on the outer cabinets next the angle plates, and tight them to the cabinets using the shoulder screws provided with these kits (using Loctite 243 or equivalent) Four screws 12mm diameter (not provided) are required to secure the “U”...
-
Page 38: Geo S12 Horizontal Array Cable Mounted On A Ceiling
GEO S12 HARDWARE SETUP PROCEDURE 6.3.8 GEO S12 horizontal array cable mounted on a ceiling Required items 2 x VNI-ABRK (allows cable suspension for horizontal arrays, holes for cable suspension are 10mm diameter) (N-1) x GPI-ANPL for a N x GEO S12 array (ANPL1 ranges from 0.2° to 3.15°, ANPL2 ranges from 5° to 10°, ANPL3 ranges from 16°... -
Page 39: Touring Applications
GEO S12 HARDWARE SETUP PROCEDURE Touring applications 6.4.1 Described configurations SECTION 6.4.2 SECTION 6.4.4 SECTION 6.4.3 SECTION 6.4.5 SECTION 6.4.6 SECTION 6.4.8 SECTION 6.4.9 SECTION 6.4.7 Page 39 / 95 System Manual GEOS12 LS18... -
Page 40: Single Geo S12 On Speaker Stand Or On Ls18 Horizontally
Ensure that public is not allowed within a safety area which radius is equal or higher than assembly height. IMPORTANT NEXO PLSTD pole stand only should be used for mounting on top of NEXO LS18 LS18 must always be installed on a horizontal surface... - Page 41 GEO S12 HARDWARE SETUP PROCEDURE Lift assembly on speaker stand or on LS18 with VXT-PLSTD pole stand Page 41 / 95 System Manual GEOS12 LS18...
-
Page 42: Single Geo S12 Flown Vertically
GEO S12 HARDWARE SETUP PROCEDURE 6.4.3 Single GEO S12 flown vertically Required items 1 x Flying Bar for single vertical GEO S12 (VNT-TTC) 1 x Lifting Ring (VNT-XHBRK) Or 1 x Truss hook (VNT-TCBRK) IMPORTANT Ensure that truss suspension point is strong enough to hold GEO S12 weight. Procedure Slide flying bar VNT-TTC into GEO S12 connecting plate oblong holes Lock safety pin into GEO S12 connecting plate... -
Page 43: Single Geo S12 Flown Horizontally
GEO S12 HARDWARE SETUP PROCEDURE 6.4.4 Single GEO S12 flown horizontally Required items 1 x “U” Bracket for single horizontal GEO S12 (GPT-SSBRK) 1 x Lifting Ring (VNT-XHBRK) Or 1 x Truss hook (VNT-TCBRK) IMPORTANT Ensure that suspension point is strong enough to hold GEO S12 weight Procedure Slide GPT-SSBRK side plates into GEO S12 connecting plate oblong holes Lock safety pins into GEO S12 connecting plate... -
Page 44: Two Geo S12 On Wind-Up Stand
GEO S12 HARDWARE SETUP PROCEDURE 6.4.5 Two GEO S12 on wind-up stand Required items 1 x “U” Bracket for two GEO S12 (GPT-PSBRK) Wind Up stand diameter 35mm (Eurotruss ES160 or equivalent) IMPORTANT Wind Up stand must be rated for assembly weight (80kg rated load min). Wind Up stand must always be installed on a horizontal surface. - Page 45 GEO S12 HARDWARE SETUP PROCEDURE Alternative Procedure (“Walder” procedure) Below described procedure required 2 additional 8x20 quick release pins (VXT-BL820) Split the GPT-PSBRK side plates by removing screws and bolt Slide GPT-PSBRK lower half-plates into lower GEO S12 connecting plate oblong holes Lock safety pins into lower GEO S12 connecting plate Position “U”...
- Page 46 GEO S12 HARDWARE SETUP PROCEDURE Page 46 / 95 System Manual GEOS12 LS18...
-
Page 47: Two Geo S12 Vertically
GEO S12 HARDWARE SETUP PROCEDURE 6.4.6 Two GEO S12 vertically Required items 1 x “U” Bracket for two GEO S12s (GPT-PSBRK) 1 x Lifting Ring (VNT-XHBRK) Or 1 x Truss hook (VNT-TCBRK) IMPORTANT Ensure that suspension point is strong enough to hold two GEO S12s weight. Procedure Slide GPT-PSBRK side plates into GEO S12s connecting plate oblong holes Lock safety pins into GEO S12s connecting plate... -
Page 48: Two Or More Geo S12 Flown Horizontally
- “Down” means NEXO logo on front grid is at the bottom GEO S12 can be connected “Up” or “Down” by simply flipping the cabinets. Whenever possible, NEXO recommends symmetrical designs (ie NEXO logo in the same position on Left and Right clusters for stereo designs) - Page 49 GEO S12 HARDWARE SETUP PROCEDURE Connect second GEO S12 with X-Bow front articulation holes and rear link bars and ensure quick release pins are properly locked Repeat above steps for subsequent GEO S12’s IMPORTANT Ensure angle settings are identical on upper and lower side of the cabinets Ensure that safety pins are properly locked into GEO S12s connecting panels.
- Page 50 GEO S12 HARDWARE SETUP PROCEDURE Lift and position assembly, connect lifting rings to suspension points with sling and shackle Secure assembly with secondary safety steel IMPORTANT The requirements for secondary safety systems vary with territories. However, the secondary safety steel MUST have a SWL equivalent or greater than that of the rigging system.
-
Page 51: Ls18 And Three Or More Geo S12 Flown Vertically
GEO S12 HARDWARE SETUP PROCEDURE 6.4.8 LS18 and three or more GEO S12 flown vertically Required items 1 x Bumper (GPT-BUMPER) M x pairs of LS rigging plates (LST-XBOW) for M x LS18 cabinets N x Pair of Rigging Plates (GPT-XBOW) for N GEO S12 cabinets 4 x (N+M) Quick release pins (VXT-BL820) for (N+M) cabinets 1 hoist (not provided) IMPORTANT... - Page 52 GEO S12 HARDWARE SETUP PROCEDURE Insert GPT-XBOW into connecting plates of both sides of GEO S12s GEO S12 XBOW ANGLE SETTINGS PLATE Lock safety pins into LS18 and GEO S12s connecting plate IMPORTANT Ensure that safety pins are properly locked into LS18s and GEO S12s connecting panels. Connect bumper to first LS18 or GEO S12 using “lift”...
- Page 53 GEO S12 HARDWARE SETUP PROCEDURE Repeat above steps for subsequent cabinets IMPORTANT Ensure angle settings are identical on both sides of the cabinets. Ensure that safety pins are properly locked into LS18s and GEO S12s connecting panels. Ensure that all quick release pins are properly locked into their position. Lift cluster to NS-1 defined rigging height, secure cluster horizontally to prevent it from rotating Secure bumper with secondary safety steel IMPORTANT...
- Page 54 GEO S12 HARDWARE SETUP PROCEDURE Optional GPT-TLB link bar for GPT- XBOW GPT-XBOWs are delivered with standard link bars which allow both stacked and flown setups. However, these link bars require perfect alignment of angle setting holes when adding cabinets. GPT-XBOW standard link bar To facilitate flying operation, an optional link bar with oblong holes (GPT-TLB, pair of link bars provided with two 8x20 quick release pin) is available in the GEO S12 accessory range.
-
Page 55: Ground Stacked Ls18 And Geo S12
GEO S12 HARDWARE SETUP PROCEDURE 6.4.9 Ground stacked LS18 and GEO S12 Required items M x pairs of LS rigging plates (LST-XBOW) for M x LS18 cabinets N x Pair of Rigging Plates (GPT-XBOW) for N GEO S12 cabinets 1 x ground stack device (GPT-GSTK) 4 x N Quick release pins (VXT-BL820) for N cabinets IMPORTANT Ground stack device GPT-GSTK is rated for a maximum of:... - Page 56 GEO S12 HARDWARE SETUP PROCEDURE Connect the reinforcement bar to the supporting beams according to required tilt angle configuration using 2 axis per side; secure the axis with provided “R” clips Insert GPT-XBOW into connecting plates of both sides GEO S12s Insert LST-XBOW into connecting plates of LS18s Lock safety pins into LS18s and GEO S12s connecting plate IMPORTANT...
- Page 57 GEO S12 HARDWARE SETUP PROCEDURE Connect bottom LS18 or GEO S12 to GPT-GSTK Ground stacking device with 4 VXT-BL820 quick release pins Connect second LS18 or Geo S12 with X-Bow front articulation holes and rear link bars and ensure quick release pins are properly locked Repeat above steps for subsequent cabinets Once the assembly is completed, rotate rear or front GEO S12 ground stack device adjustable legs to definitive tilt angle,...
- Page 58 GEO S12 HARDWARE SETUP PROCEDURE Page 58 / 95 System Manual GEOS12 LS18...
- Page 59 GEO S12 HARDWARE SETUP PROCEDURE Optional GPT-TLB link bar for GPT- XBOW GPT-XBOWs are delivered with standard link bars which allow both stacked and flown setups. However, these link bars require perfect alignment of angle setting holes when adding cabinets. GPT-XBOW standard link bar To facilitate stacking operation, an optional link bar with oblong holes (GPT-TLB, pair of link bars provided with two 8x20 quick release pin) is available in the GEO S12 accessory range.
-
Page 60: Testing And Maintenance Of The System
After cleaning, the rigging system must be treated with a suitable lubricant to prevent rusting. NEXO recommends the use of Scottoil FS365 which is a water-based lubricant with a mixture of machine oil, surfactant and anti-rust treatment. -
Page 61: System Check Alignment Guidelines
SYSTEM CHECK ALIGNMENT GUIDELINES The NEXO TD Controllers factory delay presets are optimised to provide the best possible crossover between the GEO S12 and LS18 systems. The reference point for this adjustment is the front of each cabinet. (This means that the internal delays needed to achieve a correct time alignment are set for cabinets standing next to each other with both fronts aligned). -
Page 62: Driving The Ls18S From The Aux Send
By doing so, drivers are working perfectly together and providing the best efficiency possible. It is then up to the user to adjust the delay on the NEXO TD Controllers to match the physical path difference of the different systems. It is thus possible to get a well-adjusted system, even without measuring instruments. -
Page 63: Geo S12 - Ls18 System Check List
SYSTEM CHECK ALIGNMENT GUIDELINES GEO S12 – LS18 System Check List It is essential to execute all these check steps prior to perform a sound check on the “front end” to the system. Following this checklist step by step will prevent many troubles and will save time in the end. Are the speakers properly connected and angled? Attach the first series of modules to the bumper. -
Page 64: Technical Specifications
TECHNICAL SPECIFICATIONS ECHNICAL PECIFICATIONS LS18 and LS18-E Subwoofers 8.1.1 System specifications LS18 WITH NEXO TDCONTROLLER SETUP Frequency Response @-6 dB 32 Hz to 130 Hz Sensitivity 1W@1m 107 dB SPL Nominal Peak SPL@1m 137 to 140 dB Available Crossover Frequencies... -
Page 65: Dimensions (Mm/Inches)
TECHNICAL SPECIFICATIONS 8.1.2 Dimensions (mm/inches) Page 65 / 95 System Manual GEOS12 LS18... -
Page 66: Geo S1210
TECHNICAL SPECIFICATIONS GEO S1210 8.2.1 System specifications GEO S1210 (with CDD GEO S1210 (without CDD GEO S1210 WITH NEXO TDCONTROLLER SETUP Frequency Response @-6 dB 50 Hz to 20 kHz Sensitivity 1W@1m 103 dB SPL Nominal Peak SPL@1m 131 to 133 dB Vertical Dispersion 10°... -
Page 67: Dimensions (Mm/Inches)
TECHNICAL SPECIFICATIONS 8.2.2 Dimensions (mm/inches) Page 67 / 95 System Manual GEOS12 LS18... -
Page 68: Geo S1230
TECHNICAL SPECIFICATIONS GEO S1230 8.3.1 System specifications GEO S1230 (with CDD GEO S1230 (without CDD GEO S1230 WITH NEXO TDCONTROLLER SETUP Frequency Response @-6 dB 50 Hz to 20 kHz Sensitivity 1W@1m 103 dB SPL Nominal Peak SPL@1m 131 to 133 dB Vertical Dispersion 28.5°... -
Page 69: Dimensions (Mm/Inches)
TECHNICAL SPECIFICATIONS 8.3.2 Dimensions (mm/inches) Page 69 / 95 System Manual GEOS12 LS18... -
Page 70: Geo S12 And Ls18 Accessories
TECHNICAL SPECIFICATIONS GEO S12 and LS18 accessories 8.4.1 GPI-BUMPER Parts X8 (D8x20 M6) Dimensions 27,2 Weight: 14.5 kg / 32 lb Page 70 / 95 System Manual GEOS12 LS18... -
Page 71: Vni-Ubrk12
TECHNICAL SPECIFICATIONS 8.4.2 VNI-UBRK12 Parts Dimensions Weight: 6 kg / 13 lb Page 71 / 95 System Manual GEOS12 LS18... -
Page 72: Vni-Lbrk
TECHNICAL SPECIFICATIONS 8.4.3 VNI-LBRK Parts X2 (D8x12) X2 (D8x20) X2 (M8) X2 (M6x25) X2 (M6) X2 (M12x35) X4 (M12) X2 (M12) Dimensions 11,9 Weight: 1.6 kg / 3.5 lb Page 72 / 95 System Manual GEOS12 LS18... -
Page 73: Vni-Abrk
TECHNICAL SPECIFICATIONS VNI-ABRK 8.4.4 Parts X2 (D8x12) X2 (D8x20) X2 (M8) X2 (M6x25) X2 (M6) X2 (M12x35) X2 (M12) X2 (M12) Dimensions Weight: 1 kg / 2.2 lb Page 73 / 95 System Manual GEOS12 LS18... -
Page 74: Gpi-Anpl1
TECHNICAL SPECIFICATIONS 8.4.5 GPI-ANPL1 Parts X8 (D8x20 M6) Dimensions 12,3 Weight: 8 kg / 17.6 lb Page 74 / 95 System Manual GEOS12 LS18... -
Page 75: Gpi-Anpl2
TECHNICAL SPECIFICATIONS 8.4.6 GPI-ANPL2 Parts X8 (D8x20 M6) Dimensions 12,2 Weight: 6.5 kg / 14.3 lb Page 75 / 95 System Manual GEOS12 LS18... -
Page 76: Gpi-Anl3
TECHNICAL SPECIFICATIONS 8.4.7 GPI-ANL3 Parts X8 (D8x20 M6) Dimensions 11,5 Weight: 6.6 kg / 14.6 lb Page 76 / 95 System Manual GEOS12 LS18... -
Page 77: Lsi-Cpla
TECHNICAL SPECIFICATIONS 8.4.8 LSI-CPLA Parts X8 (D8x20 M6) Dimensions Weight: 2.5 kg / 5.5 lb Page 77 / 95 System Manual GEOS12 LS18... -
Page 78: Vni-Ipcov15
TECHNICAL SPECIFICATIONS 8.4.9 VNI-IPCOV15 Parts Dimensions Weight: 0.9 kg / 2 lb Page 78 / 95 System Manual GEOS12 LS18... -
Page 79: Gpt-Bumper
TECHNICAL SPECIFICATIONS 8.4.10 GPT-BUMPER Parts Dimensions Weight: 20 kg / 44 lb Page 79 / 95 System Manual GEOS12 LS18... -
Page 80: Gpt-Xbow
TECHNICAL SPECIFICATIONS 8.4.11 GPT-XBOW Parts Dimensions 14,8 Weight (pair): 10.7 kg / 23.6 lb Page 80 / 95 System Manual GEOS12 LS18... -
Page 81: Lst-Xbow18
TECHNICAL SPECIFICATIONS 8.4.12 LST-XBOW18 Parts Dimensions Weight (each): 8 kg / 17.5 lb Page 81 / 95 System Manual GEOS12 LS18... -
Page 82: Gpt-Tlb
TECHNICAL SPECIFICATIONS 8.4.13 GPT-TLB Parts Dimensions Weight: 0.6 kg / 1.3 lb Page 82 / 95 System Manual GEOS12 LS18... -
Page 83: Vnt-Xhbrk
TECHNICAL SPECIFICATIONS 8.4.14 VNT-XHBRK Parts Dimensions Weight: 0.35 kg / 0.8 lb Page 83 / 95 System Manual GEOS12 LS18... -
Page 84: Vnt-Ttc
TECHNICAL SPECIFICATIONS 8.4.15 VNT-TTC Parts Dimensions Weight: 1.8 kg / 4 lb Page 84 / 95 System Manual GEOS12 LS18... -
Page 85: Gpt-Ssbrk
TECHNICAL SPECIFICATIONS GPT-SSBRK 8.4.16 Parts Dimensions Weight: 7.5 kg / 16.5 lb Page 85 / 95 System Manual GEOS12 LS18... -
Page 86: Gpt-Psbrk
TECHNICAL SPECIFICATIONS 8.4.17 GPT-PSBRK Parts Dimensions Weight: 11 kg / 24.25 lb Page 86 / 95 System Manual GEOS12 LS18... -
Page 87: Vnt-Tcbrk
TECHNICAL SPECIFICATIONS 8.4.18 VNT-TCBRK Parts Dimensions Weight: 0.78 kg / 1.8 lb Page 87 / 95 System Manual GEOS12 LS18... -
Page 88: Gpt-Gstk
TECHNICAL SPECIFICATIONS 8.4.19 GPT-GSTK Parts Dimensions Weight: 26.5 kg / 58.4 lb Page 88 / 95 System Manual GEOS12 LS18... -
Page 89: Gpt-Flg
TECHNICAL SPECIFICATIONS 8.4.20 GPT-FLG Parts Dimensions Weight: 0.6 kg / 1.3 lb Page 89 / 95 System Manual GEOS12 LS18... -
Page 90: Vxt-Bl820
GEO S12 & LS18 MODULES & ACCESSORIES LIST 8.4.21 VXT-BL820 Parts Dimensions Weight: 0.04 kg / 0.1 lb Page 90 / 95 System Manual GEOS12 LS18... -
Page 91: Geo S12 & Ls18 Modules & Accessories List
GEO S12 & LS18 MODULES & ACCESSORIES LIST GEO S12 & LS18 M & A ODULES CCESSORIES REFERENCE DRAWING DESCRIPTION 18” Subwoofer LS18 18’’ Subwoofer – E version LS18-E GEO S1210 12” - 10° Tangent Array 12” - 30° Tangent Array GEO S1230 NXAMP4x1mk2 Powered Digital TD Controller 4x1300W... - Page 92 GEO S12 & LS18 MODULES & ACCESSORIES LIST REFERENCE DRAWING DESCRIPTION GPI-BUMPER Installation bumper for GEO S12 and LS18 “U” bracket for GEO S12 VNI-UBRK12 VNI-LBRK Mounting plate for GEO S12 and GPI-BUMPER VNI-ABRK Mounting plate for GEO S12 and GPI-BUMPER GPI-ANPL1 GEO S12 and LS18 Angle plate (0.2°...
- Page 93 GEO S12 & LS18 MODULES & ACCESSORIES LIST “U” bracket for one GEO S12 GPT-SSBRK “U” bracket for two GEO S12 GPT-PSBRK Truss hook adapter for GPT-SSBRK, GPT-PSBRK and VNT- TCBRK VNT-TTC GPT-GSTK Ground stack device for GEO S12 and LS18 GPT-FLG Kit flange 120°...
-
Page 94: User Notes
USER NOTES 10 USER NOTES Page 94 / 95 System Manual GEOS12 LS18... - Page 95 Tel: +33 3 44 99 00 70 NEXO S.A. Fax: +33 3 44 99 00 30 E-mail: info@nexo.fr Parc d’activité de la Dame Jeanne nexo-sa.com F-60128 PLAILLY...
