- Page 1 DP2537-06-CM GEO M6 GEO M620 & GEOM6B Tangent Array Modules System manual System Manual GEOM6...
-
Page 2: Table Of Contents
GEO M6B connectors ..................................... 8 ......................................9 ABLING GEO M620 GEO M6B .................... 9 RECOMMENDED AMPLIFICATION GEO M6 NEXO TD C ........................9 SETUPS ON ONTROLLERS CONNECTION DIAGRAMS ............................10 GEO M620 & LS18 / DTDC & DTDAMP4 1.3..................10... - Page 3 VNT-TCBRK ......................................54 VXT-BL515 ....................................... 55 GMT-FLG ......................................56 GMI-BNFIX ....................................57 GMI-IPCOV ....................................58 VNI-WS15...................................... 59 GMT-6CASE ....................................60 GEO M6 SERIES MODULES & ACCESSORIES LIST ..................61 10 USER NOTES ................................63 Page 3 / 64 System Manual GEOM6...
- Page 4 “Tried and true” methods will produce entirely unexpected results. HRW technology produces precise and predictable results. The Configurable Directivity Flange. A waveguide that allows the operator to alter its behaviour. An unprecedented NEXO development that is easy to use – once you know how and when.
-
Page 5: Please Read Carefully Before Proceeding
User Manual. Failure to do this exposes people to potential injury or death. Please check the web site nexo-sa.com for the latest update. Always consult qualified NEXO personnel if the device installation requires construction work and make sure to observe the following precautions: Mounting precautions choose mounting hardware and an installation location that can support 4 times the weight of the speaker system;... - Page 6 PLEASE READ CAREFULLY BEFORE PROCEEDING HIGH SOUND PRESSURE LEVELS Exposure to extremely high noise levels may cause permanent hearing loss. Individuals vary considerably in susceptibility to noise-induced hearing loss but nearly everyone will lose some hearing if exposed to sufficiently intense noise for a sufficient period of time. The U.S. Government’s Occupational and Health Administration (OSHA) has specified the following permissible noise level exposures: Sound Duration Per Day In Hours Sound Level dBA, Slow Response...
-
Page 7: Introduction
INTRODUCTION NTRODUCTION Thank you for selecting a NEXO GEO M6 Series Tangent Array System. This manual is intended to provide you with necessary and useful information about your GEO M6 System, which includes the following products: • GEO M620 is a 20° Tangent Array Module. It comprises 1x6.5” (17cm) 8 ohms LF/MF driver and 1x1.5”... -
Page 8: Geo M6 General Set-Up Instructions
GEO M6 GENERAL SET-UP INSTRUCTIONS GEO M6 G ENERAL NSTRUCTIONS GEO M620 and GEO M6B connections GEO M620 and GEO M6B are connected with Speakon NL4FC plugs (not supplied). A wiring diagram is printed on the connection panel located on the back of each cabinet. The 4 pins of the Speakon sockets identified in / out are connected in parallel within the enclosure. -
Page 9: Cabling
GEO M6 GENERAL SET-UP INSTRUCTIONS Cabling NEXO recommends the exclusive use of multi-conductor cables to connect the system: the cable kit is compatible with all the cabinets, and there is no possible confusion between LF, MF and HF sections. Cable choice consists mainly of selecting cables of the correct sectional dimension (size) in relation to the load resistance and the cable length. -
Page 10: Connection Diagrams
CONNECTION DIAGRAMS ONNECTION DIAGRAMS GEO M620 & LS18 / DTDController & DTDAMP4x1.3 Page 10 / 64 System Manual GEOM6... -
Page 11: Geo M620 / Nxamp4 X 1 Mk 2 (4 Channels Mode )
CONNECTION DIAGRAMS GEO M620 / NXAMP4x1mk2 (4 channels mode) Page 11 / 64 System Manual GEOM6... -
Page 12: Geo M620 & Geo M6B / Nxamp4 X 1 Mk 2 (4 Channels Mode )
CONNECTION DIAGRAMS GEO M620 & GEO M6B / NXAMP4x1mk2 (4 channels mode) Page 12 / 64 System Manual GEOM6... -
Page 13: Mk 2
CONNECTION DIAGRAMS GEO M620 & LS18 (mono bridged) / NXAMP4x1mk2 Page 13 / 64 System Manual GEOM6... - Page 14 CONNECTION DIAGRAMS GEO M620 / NXAMP4x2mk2 (4 channels mode) Page 14 / 64 System Manual GEOM6...
-
Page 15: Mk 2 (4 Channels Mode )
CONNECTION DIAGRAMS GEO M620 & GEO M6B / NXAMP4x2mk2 (4 channels mode) Page 15 / 64 System Manual GEOM6... -
Page 16: Channels Mode )
CONNECTION DIAGRAMS GEO M620 & LS18 / NXAMP4x2mk2 (4 channels mode) Page 16 / 64 System Manual GEOM6... -
Page 17: Simulation Software
In addition, it provides mechanical information for all clusters in agreement with Structural Analysis Reports (available in the Help section): dimensions, weight, gravity centre position, forces, moments, working load and safety factor. NS-1 installation package includes all NEXO User Manuals, Structural Analysis Reports and Certificates PDF files. NS-1 is a freeware available on nexo-sa.com... -
Page 18: Configurable Directivity Device
Remove the 2 TORX screws per flange on each side of the GEO Waveguide (drawings below); Install or remove the 120° flanges with the 2 TORX screws Re-install the grid, being careful that the NEXO logo must be on the woofer side. When & where to use Configurable Directivity flanges The diagrams show audience area coverage for a stereo system. -
Page 19: Geo M6 Hardware Setup Procedure
Safety first GEO M6 Rigging System structural computations and related documents are available in NS-1 or at NEXO (info@nexo.fr) upon request. We include this section to remind you of safe practice when flying the GEO M6 system. Please read it carefully. However, user must always apply his or her knowledge, experience and common sense. -
Page 20: Ground Stacking Safety
For fixed installations, wind loading has to be taken into account in accordance to the national standards. The GEO M6 Rigging System requires regular inspection and testing by a competent test centre. NEXO recommend that the system is load tested and certified annually or more frequently if local regulations require. -
Page 21: General Description
- “Right” means HF waveguide is right as seen from front. GEO M6 can be connected to bumpers “Left” or “Right” by simply flipping the cabinets. Whenever possible, NEXO recommends symmetrical designs (preferably NEXO logo outwards and HF waveguide inwards in stereo configurations) GEO M620 “Left”... -
Page 22: Permanent Installation Variant
GEO M6 HARDWARE SETUP PROCEDURE In order to avoid misuse or wrong angle setting by confusing left and right printings on GEO M6, remember that: The cabinet articulation hole around which angle setting bar rotates is always the one with no angle value indication The cabinet angle setting hole along which angle setting bar slides is always next to the “0°”... -
Page 23: Accessories
GEO M6 HARDWARE SETUP PROCEDURE Accessories GEO M6 accessories are: GMT-BUMPER GMT-EXBAR GMT-LBUMP (up to 3xGEO M6 max) (up to 12xGEO M6 max) GMT-BPADPT-2 GMT-LBPADPT VNT-POLE VNT-XHBRK VNT-TCBRK VXT-BL515 GMT-FLG GMI-BNFIX GMI-IPCOV VNI-WS15 GMT-6CASE Page 23 / 64 System Manual GEOM6... -
Page 24: Warnings On Geo M6 Accessories
All GEO M6 accessories are specifically rated in agreement with structural computations. Never use other accessories – including push-pins - when assembling GEO M6 cabinets than the ones provided by NEXO: NEXO will decline responsibility over the entire GEO M6 accessory range if any component is purchased from different supplier. -
Page 25: Installation Applications
In order to prevent screws from getting loose in fixed installations, use blocking liquid LOCTITE 243 or equivalent for all screws used with GEO M6 fixed installation accessories. LOCTITE 243 is available at NEXO or at your local distributor upon request. Page 25 / 64 System Manual GEOM6... -
Page 26: To 3 (Maximum) Geo M6 Wall Mounted
GEO M6 HARDWARE SETUP PROCEDURE 1 to 3 (maximum) GEO M6 wall mounted Required items 1 x VNI-WS15 1 x GMT-LBUMP 1 to 3 GMI-BNFIX 3 x 12mm diameter screws (not provided) IMPORTANT Ensure that the wall is strong enough to hold 4 times GEO M6 cluster weight and that the 12 mm diameter screws and corresponding plugs required to fix the VNI-WS15 on the wall are properly dimensioned. -
Page 27: To 3 (Maximum) Geo M6 Ceiling Mounted
GEO M6 HARDWARE SETUP PROCEDURE 1 to 3 (maximum) GEO M6 ceiling mounted Required items 1 x GMT-LBUMP 1 to 3 x GMI-BNFIX 4 x 8mm diameter screws (not provided) IMPORTANT Ensure that the ceiling is strong enough to hold 4 times GEO M6 cluster weight and that the four screws 8 mm diameter and corresponding plugs required to fix the GMT-LBUMP under the ceiling are properly dimensioned. -
Page 28: To 12 (Maximum) Geo M6 Ceiling Mounted
GEO M6 HARDWARE SETUP PROCEDURE 4 to 12 (maximum) GEO M6 ceiling mounted Required items 1 x GMT-BUMPER 4 to 12 x GMI-BNFIX 4 x 8mm diameter screws (not provided) IMPORTANT Ensure that the ceiling is strong enough to hold 4 times GEO M6 cluster weight and that the four screws 8 mm diameter and corresponding plugs required to fix the bumper under the ceiling are properly dimensioned. -
Page 29: Touring Applications
GEO M6 HARDWARE SETUP PROCEDURE Touring applications Described configurations SECTION 8.3.4 1 to 3 GEO M6 POLE MOUNTED SECTION 8.3.7 4 to 12 GEO M6 FLOWN SECTION 8.3.5 SECTION 8.3.6 1 to 3 GEO M6 TRUSS MOUNTED 1 to 6 GEO M6 STACKED ON SUB Page 29 / 64 System Manual GEOM6... -
Page 30: To 3 (Maximum) Geo M6 Pole Mounted
IMPORTANT (NEXO SUB POLE STAND) - NEXO VXT-PLSTD pole stand only should be used for mounting on top of NEXO SUB - NEXO SUB must always be installed on a horizontal surface; - Ensure that public is not allowed within a safety area which radius is equal or higher than assembly height. - Page 31 GEO M6 HARDWARE SETUP PROCEDURE Procedure Attach the GMT-LBPADPT to the GMT-LBUMP by using the screws, washers and bolts provided with GMT-LBPDAPT; Use the 2 pins provided with VNT-POLE to attach L-BUMP at required vertical angle, according to below drawings; Bottom GEO M6 at 0°...
-
Page 32: To 3 Geo (Maximum) M6 Truss Or Cable Mounted
GEO M6 HARDWARE SETUP PROCEDURE 1 to 3 GEO (maximum) M6 truss or cable mounted Required items 1 x GMT-LBUMP 1 x GMT-LBPADPT 1 x VNT-TCBRK (truss mounting) or 1 x VNT-XHBRK (cable mounting) 3 x VXT-BL515 for first GEO M6 4 x VXT-BL515 for second and third GEO M6 IMPORTANT Ensure that suspension point is strong enough to hold 4 times GEO M6 cluster weight (35 kg) -
Page 33: To 6 (Maximum) Geo M6 Stacked On Sub
GEO M6 HARDWARE SETUP PROCEDURE 1 to 6 (maximum) GEO M6 stacked on Sub Required items 1 x GMT-BUMPER 1 x GMT-BPADPT-2 4 VXT-BL515 per GEO M6 IMPORTANT GMT-BPADPT is rated for a maximum of 6 x GEO M6 on a single LS18 in any inter cabinet angle configuration, provided the stack is assembled according to below rules: - LS18 must always be installed on a horizontal surface;... -
Page 34: To 12 (Maximum) Geo M6 Flown
GEO M6 HARDWARE SETUP PROCEDURE 4 to 12 (maximum) GEO M6 flown Required items 1 or 2 hoists (not provided). 1 x GMT-BUMPER 1 x GMT-EXBAR for extended positive and negative bumper angles 4 VXT-BL515 per GEO M6 1 x GMT-6CASE for 6 x GEO M6 IMPORTANT Maximum GEO M6 quantity for flown vertical cluster is 12 (and eventually less). - Page 35 GEO M6 HARDWARE SETUP PROCEDURE lift assembly to sufficient height in order to connect additional set GEO M6 if required set inter-angle values IMPORTANT Ensure all pins are properly locked into Geo M6 lift cluster to NS-1 defined rigging height, secure cluster horizontally to prevent it from rotating Secure bumper with secondary safety steel.
- Page 36 GEO M6 HARDWARE SETUP PROCEDURE Procedure with flight case set horizontally Open upper cover while the flight case is on its wheels Connect GMT-BUMPER to top cabinet 4 x VXT-BL515 quick release pins If required, connect GMT-EXBAR to GMT-BUMPER by inserting EXBAR clevis pins into GMT-BUMPER “B” and “D” holes Connect single hoist to required hole as indicated in NS1 design “A”, “B”, “C”, “D”...
-
Page 37: Testing And Maintenance Of The System
After cleaning, the rigging system must be treated with a suitable lubricant to prevent rusting. NEXO recommends the use of Scottoil FS365 which is a water-based lubricant with a mixture of machine oil, surfactant and anti-rust treatment. -
Page 38: System Check Alignment Guidelines
Cluster design must be done with NS-1, which provides very intuitive and fast method to determine all cluster geometry parameters in relation to venue where cluster is implemented. NS-1 is a freeware available for all NEXO users at nexo-sa.com IMPORTANT Never install a GEO M6 cluster without checking its acoustical performances and mechanical safety in NS- 1 prior to installation. -
Page 39: Driving The Ls18S From The Aux Send
Angle (in radians)=3.142 x Angle (in degrees)/180 Computer – Laptop or Desktop PC running Windows XP with the current version of NEXO NS-1 installed. It is not possible to configure a Geo tangent array properly without using NS-1. Note that, when NS-1 designs are prepared prior to arrival at the venue, it is often necessary to modify or update the design to accommodate special circumstances. -
Page 40: Geo M6 - Ls18 System Check List
SYSTEM CHECK ALIGNMENT GUIDELINES GEO M6 – LS18 System check list It is essential to execute all these check steps prior to perform a sound check on the “front end” to the system. Following this checklist step by step will prevent many troubles and will save time in the end. Are the speakers properly connected and angled? Attach the first series of modules to the bumper. -
Page 41: Technical Specifications
TECHNICAL SPECIFICATIONS ECHNICAL PECIFICATIONS LS18 and LS18-E Subwoofers System specifications LS18 WITH NEXO TDCONTROLLER SETUP Frequency Response @-6 dB 32Hz - 130 Hz Sensitivity 1W@1m 107 dB SPL Nominal Peak SPL@1m 137 to 140 dB Available Crossover Frequencies 35-60, 35-85, 35-120 Hz... -
Page 42: Dimensions
TECHNICAL SPECIFICATIONS Dimensions Page 42 / 64 System Manual GEOM6... -
Page 43: Geo M620 Module
TECHNICAL SPECIFICATIONS GEO M620 Module System specifications GEO M620 (without CDD GEO M620 (with CDD GEOM620 WITH NEXO TDCONTROLLER SETUP Frequency Response @-6 dB 75 Hz to 20 kHz Sensitivity 1W@1m 95 dB SPL Nominal Peak SPL@1m 128 dB Vertical Dispersion 20°... -
Page 44: Dimensions
TECHNICAL SPECIFICATIONS Dimensions Page 44 / 64 System Manual GEOM6... -
Page 45: Geo M6B Module
TECHNICAL SPECIFICATIONS GEO M6B Module System specifications GEOM6B WITH NEXO TDCONTROLLER SETUP Frequency Response @-6 dB 70 Hz to 1kHz Sensitivity 1W@1m 94 dB SPL Nominal Peak SPL@1m 125 dB Nominal Impedance 8 Ohms Recommended Power 450 Watts PRODUCT FEATURES LF Component 1 x 6.5' 8 Ohms long excursion driver... -
Page 46: Dimensions
TECHNICAL SPECIFICATIONS Dimensions Page 46 / 64 System Manual GEOM6... -
Page 47: Geo M6 Accessories Gmt-Bumper
TECHNICAL SPECIFICATIONS GEO M6 Accessories GMT-BUMPER Parts Dimensions Weight : 3,5 kg / 7.7 lb Page 47 / 64 System Manual GEOM6... -
Page 48: Gmt-Exbar
TECHNICAL SPECIFICATIONS GMT-EXBAR Parts Dimensions Weight : 1,9 kg / 4.2 lb Page 48 / 64 System Manual GEOM6... -
Page 49: Gmt-Lbump
TECHNICAL SPECIFICATIONS GMT-LBUMP Parts X4 (Torx M6x20) Dimensions Weight : 2,7 kg / 6 lb Page 49 / 64 System Manual GEOM6... -
Page 50: Gmt-Bpdapt-2
TECHNICAL SPECIFICATIONS GMT-BPDAPT-2 Parts Dimensions Weight : 0,5 kg / 1.1 lb Page 50 / 64 System Manual GEOM6... -
Page 51: Gmt-Lbpadpt
TECHNICAL SPECIFICATIONS GMT-LBPADPT Parts Dimensions Weight : 1,6 kg / 3.5 lb Page 51 / 64 System Manual GEOM6... -
Page 52: Vnt-Pole
TECHNICAL SPECIFICATIONS VNT-POLE Parts Dimensions Weight : 0,9 kg / 2.2 lb Page 52 / 64 System Manual GEOM6... -
Page 53: Vnt-Xhbrk
TECHNICAL SPECIFICATIONS VNT-XHBRK Parts Dimensions Weight : 0,35 kg / 0.8 lb Page 53 / 64 System Manual GEOM6... -
Page 54: Vnt-Tcbrk
TECHNICAL SPECIFICATIONS VNT-TCBRK Parts Dimensions Weight : 0,78 kg / 1.8 lb Page 54 / 64 System Manual GEOM6... -
Page 55: Vxt-Bl515
TECHNICAL SPECIFICATIONS VXT-BL515 Parts Dimensions Weight : 0,0125 kg / 0.0275 lb Page 55 / 64 System Manual GEOM6... -
Page 56: Gmt-Flg
TECHNICAL SPECIFICATIONS GMT-FLG Parts Dimensions Weight : 0,2 kg / 0.44 lb Page 56 / 64 System Manual GEOM6... -
Page 57: Gmi-Bnfix
TECHNICAL SPECIFICATIONS GMI-BNFIX Parts Dimensions 13,8 Weight : 0,2 kg / 0.44 lb Page 57 / 64 System Manual GEOM6... -
Page 58: Gmi-Ipcov
TECHNICAL SPECIFICATIONS GMI-IPCOV Parts Dimensions Weight : 0,3 kg / 0.66 lb Page 58 / 64 System Manual GEOM6... -
Page 59: Vni-Ws15
TECHNICAL SPECIFICATIONS VNI-WS15 Parts X1 (Arm) X1 (Adapter) Dimensions Weight : 2,8 kg / 6.2 lb Page 59 / 64 System Manual GEOM6... -
Page 60: Gmt-6Case
TECHNICAL SPECIFICATIONS GMT-6CASE Parts Dimensions Weight : 57 kg / 125.7 lb Page 60 / 64 System Manual GEOM6... -
Page 61: Geo M6 Series Modules & Accessories List
GEO M6 SERIES MODULES & ACCESSORIES LIST GEO M6 S & ERIES MODULES ACCESSORIES REFERENCE DRAWING DESCRIPTION GEO M620 GEO M620 Module GEO M6B GEO M6B Module DTD-IU Digital TD Controller Installation Version DTD-IN Digital TD Controller Installation Version - Dante... - Page 62 GEO M6 SERIES MODULES & ACCESSORIES LIST REFERENCE DRAWING DESCRIPTION Main GEOM6 Bumper GMT-BUMPER (up to 12 x GEO M6 maximum) GMT-EXBAR Extension Bar for GMT-BUMPER Light GEO M6 Bumper GMT-LBUMP (up to 3 x GEO M6 maximum) GMT-BPADPT-2 Stacking adaptor for GMT-BUMPER...
-
Page 63: 10 User Notes
USER NOTES 10 USER NOTES Page 63 / 64 System Manual GEOM6... - Page 64 Tel: +33 3 44 99 00 70 NEXO S.A. Fax: +33 3 44 99 00 30 E-mail: info@nexo.fr Parc d’activité de la Dame eanne nexo-sa.com F-60128 PLAILLY System Manual GEOM6...
