DA-WM2050 INSTALLATION MANUAL
Mounting
Mount the bracket to the wall as follows:
1
Mount bracket 1 to the wall by using
the provided anchors and screws.
2
Insert cables from external devices,
network and power adapter through
the hole in bracket 1 and the rear of
bracket 2.
3
Screw bracket 2 to bracket 1.
4
Assemble bracke 3, which is purchased
separately, into bracket 2 and fix it by
using the screws.
This manual is intended for users of the DA-WM2050 wall
mounting bracket. It includes instructions for mounting the
DA-WM2050 wall mounting bracket to a wall.
• This bracket is intended to be used with a
specific model of camera. Do not use it with
other models of cameras except for those
approved by the dealer or distributor.
• This installation should be performed
by a qualified service personnel in conformance
to all local codes.
• You may need to reinforce the wall. If the wall
is not strong enough to support the camera,
the camera may fall.
• Do not use this product for other purposes.
Bracket 3
Bracket 1
Bracket 2
or
Bracket 1
Bracket 1
Cable
Bracket 2
Cable
