Idis DA-LM1100 Installation Manual

DA-LM1100 INSTALLATION MANUAL
Mounting
Mount the bracket to the pole as follows:
1
Mount the bracket 1 to the pole. Fasten the
bracket 1 to the pole by adjusting the strap
length. You can adjust the strap length by
tightening or loosening the clamp screw.
2
Mount the bracket 2 to the bracket 1.
This manual is intended for users of the DA-LM1100 pole mounting
bracket. It includes instructions for mounting the DA-LM1100 pole
mounting bracket to a pole.
• This bracket is intended to be used with DC-S series model
of cameras. Do not use it with other models of cameras.
• This installation should be performed by a qualified service
personnel in conformance to all local codes.
• You may need to reinforce the pole. If the pole is not strong
enough to support the camera, the camera may fall.
• Do not use this product for other purposes.
Pole DIA. 76~230mm (2.99~9.06")
Strap [Length max.
Clamp Screw
750mm (29.53")]
Bracket 1
Bracket 1
Bracket 2
Pole
