1.3 Important Information
1.
The lubrication port should remained plugged at all times except when performing maintenance on a sampler that has
been isolated from pipeline pressure and/or removed from the pipeline.
2.
Prior to injecting Welker Great Barrier Sealant™ into the lubrication port, the plug must be removed and an
appropriately sized grease fitting installed.
3.
After Welker Great Barrier Sealant™ has been injected into the lubrication port, the grease fitting must be removed and
the plug reinstalled before the sampler can be exposed to pipeline pressure and returned to operation.
Failure to remove the grease fitting and return the plug to the lubrication port prior to exposing the sampler to pipeline
pressure could result in a product leak and/or injury to the operator.
1.4 Specifications
The specifications listed in this section are generalized for this equipment. Welker can modify the equipment according to your
company's needs. Please note that the specifications may vary depending on the customization of your equipment.
Products Sampled
Materials of Construction
Maximum Allowable
Operating Pressure
Fast Loop Connection
Sample Outlet Connection
Utility Requirements
Sample Volume
Features
5
IOM-195
MODEL: INLOOP™ ACE
Table 1: inLoop™ ACE Specifications
Condensate, Crude Oil, Liquid Products Compatible With the Materials of
Construction, Refined Hydrocarbons, and Water
316/316L Stainless Steel Wetted Parts, Aluminum Non-Wetted Parts, PTFE, Kalrez®
Wetted Seals, and Viton® Non-Wetted Seals
Others Available
1440 psig @ -20 °F to 100 °F (99 barg @ -28 °C to 37 °C)
1" – 600 ANSI RF
¼" FNPT
Hydraulic or Pneumatic Supply for Motor Operation: 100–150 psig (6–10 barg)
Inert Gas Supply for Purge Operation: ¼" FNPT Connection
D-Style Collection Head: 0.5–10 cc
External Adjustment
External Sand Relief
Purge Tube
V-ring Packing
REV: B
