CV Meaning
Fault indication
30
bit 0 (1)
= 1 Light short-circuit
bit 1 (2) = 1 Overheating
bit 2 (3) = 1 Motor short-circuit
CV Function mapping for function outputs:
33 In order to allocate a function of the digital system to a function
output, look for the section where the row of the desired function
–
meets the column of the desired function output. Enter the number
46
found in the respective CV. For the purpose of clarification, factory
settings are shown in bold print.
CV Function
output:
33 F0 forward
F0 backward
34
Function 1
35
Function 2
36
37 Function 3
38 Function 4
39 Function 5
40 Function 6
41 Function 7
42 Function 8
43
Function 9
44
Function 10
45
Function 11
46 Function 12
(*)-These values are not significant for SILVER 10432 and 10433.
50 Motor configuration
bits 0-3
Select motor type 0-5, enter as decimal number
(1-4)
Bit 5 (6) =0 EMF switch inactive
=1 EMF switch active
Bit 6 (7) =0 Control switched on
=1 Control switched off
Bit 7 (8) =0 High-frequency motor control (approx. 23 kHz)
=1 Low-frequency motor control (approx. 19 Hz)
Braking configuration
51
bit 0 (1) = 1 Constant braking distance activated
bit 1 (2)) = 1 ABC activated
bit 2 (3)
= 1 ABC direction-dependency deactivated
bit 3 (4) = 1 Activate push-pull operation without
intermediate stop
bit 4 (5) = 1 Activate push-pull operation with intermediate
stop
A B C
8 16 32
8 32
16
8 16
32
8 16 32
8 16 32
1 2 4
1 2 4
1 2 4
1 2 4
1 2 4
This range does not allow
mapping of functions
9
Factory
Range
setting
0 (dec)
0,1 [1] 0
0,1 [2] 0
0,1 [4] 0
Factory
setting
D
64 8
64 16
64 32
64
64
64 128 (*)
8 32 (*)
8 64 (*)
8 128 (*)
8 0
8 0
0
1
0
1
0
1
1 0
0 (dec)
0,1 0
[0-5]
0,1 0
[32]
0,1 0
[64]
0,1 0
[128]
0 (dec)
0,1 [1] 0
0,1 [2] 0
0,1 [4] 0
0,1 [8] 0
0,1 [16] 0
