Lenz Elektronik Digital Plus Manual page 10

Silver Direct Locomotive decoder
bit 5 (6) = 1 Stopping with DC independent of the polarity
(only if Bit 3 is deleted in CV29).
bits 6-7 (7-8)
Not used
CV Meaning
52 Braking distance with activated constant braking
distance
Slow approach with ABC
53
Stopping time in push-pull operation, 1 to 256 sec
54
55 Sets brightness at function outputs A and C, 255=max
56 Sets brightness at function outputs B and D, 255=max
57 Function mapping:
Each bit of the CV stands for a function of the digital
-
system: Bit 0(1) for function 1, Bit 1(2) for function 2
59
and so on up to Bit 7(8) for function 8. If you wish to
allocate a function for dimming, the respective bit in
CV 57 must be set.
57 Dimming function (no factory setting)
58
Switching speed function (factory setting F3)
acceleration and deceleration delay function (factory
59
setting F4)
60 Lighting effect at function outputs A and B. The units
digit of the value stands for function output A, the tens
digit for function output B:
0 No effect
1 Marslight
2 Gyrolight
3 Strobe
4 Double strobe
Function mapping: lighting effect at function outputs A
61
and B
62 Lighting effect at function outputs C and D.
The tens digit of the value stands
for function output D:
0 No effect
1 Flashing at same time as
function output C
2 Flashing alternately to function
output C
3 Flickering type 2 (less smooth)
4 Flickering type 3 (excitedly)
5 Dimming with value from CV56
63 Flashing frequency for function outputs C and D:
default approx. 1 sec, f = 1 / ( 0.03 * (1 + CV63))
64 Function mapping: lighting effect at function outputs C and
D
67.. Values for user defined speed table, default = factory
speed curve
94
105 User Identification #1
10
0,1 [32]
Range
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-255
The units digit of the value stands for
function output C:
0 No effect
1 Flashing
2 Flickering type 1 (smooth)
3 Dimming with value from CV55
0-255
0-255
10
0
Factory
setting
50
48
4
255
255
0
4
8
0
0
0
32
0
255
