Lenz Elektronik Digital Plus Manual page 8

Silver Direct Locomotive decoder
Table of supported CVs
CV Meaning
1 Basic locomotive address. This number is the short address
used to control the locomotive. When writing this CV, CV19
(consist address) is automatically cleared and CV29 Bit 6
(use of extended address) is deleted is set to 0.
2 Minimum starting voltage
3 Starting delay
4 Braking delay
5 Maximum speed
Mid speed Vmid (a value of 60 will give a linear curve)
6
Version number
7
Manufacturer's ID
8
9 Back EMF Repetition Rate
17 Extended locomotive address, high-order byte
18 Extended locomotive address, low-order byte
19 Consist address
29 Decoder Configuration, Byte 1:
bit 0 Locomotive direction of travel:
0 = locomotive's direction is normal
(1)
1 = locomotive's direction is reversed
bit 1 Headlight mode:
(2) 0 = Operation with 14 or 27 speed step systems..
1 = Operation with 28, 55 or 128 speed steps.
Note: your system must be set to the same mode.
bit 2 Usage on conventional DC layouts:
(3) 0 = locomotive operates in digital mode only
1 = locomotive can operate on either conventional DC
and on DCC
Not Used
bit 3
(4)
bit 4 Speed Curve Selection:
(5) 0 = factory pre-set speed curve is used
1 = user defined speed curve is used. Please enter the
appropriate values into CV 67 to 94 before setting this
bit.
bit 5 Extended Addressing
(6) 0= Normal addressing
1= Four digit extended addressing
bit 6 bit 7 always 0
8
8
Factory
Range
setting
1-127 3
0-255 0
0-255 6
0-255 5
0-255 255
0-255 48
- 78
- 99
0-63 15
192-231 192
0-255 100
1-99 0
6 (dec)
0,1 0
[1]
0,1 1
[2]
0,1 1
[4]
0 0
0,1 0
[16]
0-1 0
[32]
0 0
