Silver Locomotive decoder
The DIGITAL plus SILVER locomotive decoder is suitable for all DC locomotives with continuous
current draw of 1.0 Amp. or less. The characteristics of the decoder are:
∗
Super smooth and silent high frequency back-emf motor control.
∗
Asymmetrical DCC support including directional stopping
∗
Adjustable precision stopping control
∗
Low speed gear for switching operations
∗
Selectable for operation with 14/27, or 28/128 speed steps.
∗
Operation on conventional DC layouts is possible or can be disabled.
∗
Motor output = 1A continuous, 1.8A max, > 5 A stall.
∗
Motor and function outputs protected
∗
Four function outputs rated at 100mA each with advanced function mapping
∗
Directional or independent lighting with dimming and special effects.
∗
Support for Advanced Consist Control and Extended Addressing
∗
Support for programming on the mainline (operations mode programming)
∗
Support for all form of programming as described in NMRA RP-9.2.3
∗
Supports service mode decoder lock
∗
Size: L 0.91" x W 0.66"x H 0.12" L 23mm x W 16.6mm x H 2.9mm
Silver Silent-Back EMF
DCC Decoder
Art. No. 10331
November 2006
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Lenz Elektronik Digital plus Silver 10331
Summary of Contents for Lenz Elektronik Digital plus Silver 10331
- Page 1 Silver Locomotive decoder The DIGITAL plus SILVER locomotive decoder is suitable for all DC locomotives with continuous current draw of 1.0 Amp. or less. The characteristics of the decoder are: ∗ Super smooth and silent high frequency back-emf motor control. ∗...
-
Page 2: Special Features
For more detailed information please refer to the "SILVER decoder" information which can be downloaded from the Lenz Elektronik GmbH website: www.lenz.com. Capacity and protection equipment The motor output has a current-carrying capacity of up to 1A without any concern for cooling! The short-term maximum current-carrying capacity is 1.8A. - Page 3 Silver Locomotive decoder Function for disabling of acceleration and deceleration delay Use function F4 (function assignment can be altered in CV59) to disable the acceleration and braking delay as well as the constant braking distance during operation. The delays are disabled as long as the function is active. Switching speed function The switching speed halves the speed table.
- Page 4 Silver Locomotive decoder The constant braking distance does not function in analogue DC mode. Mapping function outputs Using function mapping (CVs 33-46) you can define which functions of the digital system are used to control the A, B, C and D function outputs. The outputs A, B and C can be allocated to function F0 (direction-dependent) or functions F1 to F8 as desired.
-
Page 5: Wiring Options
Silver Locomotive decoder Some advice on installing the decoder: Although the SILVER decoder has many internal safeguards to prevent damage, you must not allow any metal part of the locomotive to touch the surface components of the decoder. This could cause a direct internal short circuit and the decoder will be destroyed. - Page 6 Silver Locomotive decoder compared to using the rail as a common and the directional headlights will function while operating on conventional DC layouts. Step by Step Installation If the locomotive has a NMRA JST decoder plug simply remove the dummy plug from the locomotive’s JST connector and plug the locomotive JST plug into the decoder.
- Page 7 Silver Locomotive decoder You can alter the content of CVs both through "Programming in operational mode (PoM)" (except for CV1, CV17 and CV18) or "Programming on the programming track". For detailed instructions on how to program using the above-mentioned devices, please refer to the operating manuals which accompany those devices.
- Page 8 Silver Locomotive decoder Table of supported CVs Factory CV Meaning Range setting Basic locomotive address. This number is the short address 1-127 used to control the locomotive. When writing this CV, CV19 (consist address) is automatically cleared and CV29 Bit 6 (use of extended address) is deleted is set to 0.
- Page 9 Silver Locomotive decoder Fault indication 0 (dec) bit 0 (1) = 1 Light short-circuit 0,1 [1] bit 1 (2) = 1 Overheating 0,1 [2] bit 2 (3) = 1 Motor short-circuit 0,1 [4] Function mapping for function outputs: Factory In order to allocate a function of the digital system to a function setting output, look for the section where the row of the desired function –...
- Page 10 Silver Locomotive decoder Braking distance with activated constant braking 0-255 distance 0-255 Slow approach with ABC 0-255 Stopping time in push-pull operation, 1 to 256 sec 0-255 Sets brightness at function outputs A and C, 255=max Sets brightness at function outputs B and D, 255=max 0-255 Function mapping: Each bit of the CV stands for a function of the digital...
- Page 11 Silver Locomotive decoder 128 Decoder Software Version – read only...
- Page 12 Silver Locomotive decoder...
-
Page 13: North American Warranty
Silver Locomotive decoder North American Warranty Lenz GmbH does everything it can do to ensure that its products are free from defects and will operate for the life of your model railroad equipment. From time to time even the best engineered products fail either due to a faulty part or from accidental mistakes in installation.
