LE1000 Value-line Decoder
The DIGITAL by Lenz LE1000 value-line locomotive decoder is suitable for all DC
motors with continuous current draw of 1.0 Amp. or less. The characteristics of the
decoder are:
Conforms to all NMRA Standards and RPs (NMRA Warrant #04-01)
Selectable for operation with 14/27, 28 or 128 speed steps.
Operation on conventional DC layouts is possible or can be disabled.
Provides 1A continuous motor current.
One function output
Function dimming through a selectable second function input
Support for Advanced Consist Control and Extended Addressing
Support for programming on the mainline
Support for all forms of programming as described in NMRA RP-9.2.3
Programmable locomotive address, starting speed, acceleration, brake
momentum and configuration.
Size: L 0.9" x W 0.63"x H 0.13" L 22.9mm x W 16mm x H 3.2 mm
Value-Line DCC Decoder
1
LE1000W
Art. No. 10100
Version 10
January 2004
