Silver+ Locomotive decoder
The DIGITAL plus SILVER+ locomotive decoder is suitable for all DC locomotives
with continuous current draw of 1.0 Amp. or less. The characteristics of the
decoder are:
∗
Super smooth and silent high frequency back-emf motor control
∗
Full RailCom NMRA DCC Bi-directional support
∗
Five function outputs rated at 500mA each
∗
Each function output supports F0-F28 with simplified function mapping
∗
Directional or independent lighting with dimming and special effects
∗
Support for automatic uncoupling control
∗
Asymmetric DCC support including directional stopping
∗
Adjustable precision stopping control
∗
Low speed gear for switching operations
∗
Selectable for operation with 14/27, or 28/128 speed steps
∗
Operation on conventional DC layouts is possible or can be disabled
∗
Motor output = 1A continuous, 1.6A max, > 5 A stall
∗
Motor and function outputs protected
∗
Support for Advanced Consist Control and Extended Addressing
∗
Support for all forms of programming as described in RP-9.2.1 & RP-9.2.3
∗
Supports service mode decoder lock
∗
Size: L 0.90" x W 0.65"x H 0.12" L 23mm x W 16.5mm x H 3.0mm
Silver+ Silent-Back EMF
DCC Decoder
Art. No. 10331-01
December 2009
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Lenz Elektronik Digital plus Silver+
Summary of Contents for Lenz Elektronik Digital plus Silver+
- Page 1 Silver+ Locomotive decoder The DIGITAL plus SILVER+ locomotive decoder is suitable for all DC locomotives with continuous current draw of 1.0 Amp. or less. The characteristics of the decoder are: ∗ Super smooth and silent high frequency back-emf motor control ∗...
- Page 2 The following contains a short introduction of the features of the SILVER+ decoder as well as information on how to use them. For more detailed information please refer to the "SILVER+ decoder" information which can be downloaded from the Lenz Elektronik GmbH website: www.lenz.com. Capacity and protection equipment...
-
Page 3: Special Features
Silver+ Locomotive decoder Special Features RailCom The Silver+ is equipped with RailCom technology. In addition to the locomotive address, other data (e.g. speed, CV content) can be transmitted from the locomotive via the track back to the system. The information sent is received by a RailCom detector and then displayed. Which data the decoder is to send is set in CV28. - Page 4 Silver+ Locomotive decoder will travel a settable, pre-defined braking distance. This braking distance does not depend on the speed of the locomotive/train. Enable the constant braking distance function (this requires setting Bit 0(1) in CV51. If this bit is not set, the decoder will use the normal speed- dependent braking delay).
- Page 5 Silver+ Locomotive decoder Lighting effect at function outputs Special lighting effects can be assigned to each of the function outputs. The lighting effects for the function outputs A and B are set in CV60 and for the function outputs C and D in CV62. If you wish to switch the effects with a function of the digital system, you can make the allocations to functions F1 to F8 in CV61 (for function outputs A and B) and CV64 (for function outputs C and D).
-
Page 6: Wiring Options
Silver+ Locomotive decoder The SILVER+ decoder cannot be set up for simultaneous use for 2-rail pickup and overhead cantenary or trolley operation. If the locomotive is turned the wrong way, the decoder could get twice the track voltage, which would destroy it! Wiring Options There are two wiring options for installing the SILVER+, depending on how the locomotive is constructed. - Page 7 Silver+ Locomotive decoder Five wires connect the headlights and functions to the decoder: • White wire (Pin #6) to the forward headlight or the function controlled by Output A. If the bulb is isolated, connect the blue wire (Pin #7) to the other terminal.
- Page 8 Silver+ Locomotive decoder Table of supported CVs Range / Factory Description setting 1-127 Basic locomotive address. Whenever this CV is changed, CV19 (consist address) is automatically removed and Bit 6 (use of extended address) is deleted in CV29. 0-255 Minimum starting voltage 0-255 Starting delay 0-255...
- Page 9 Silver+ Locomotive decoder 0-31 F0 forward 0-31 F0 backward 0-31 Function 1 forward 0-31 Function 2 0-31 Function 3 0-31 Function 4 0-31 Function 5 0-31 Function 6 0-31 Function 7 0-31 Function 8 0-31 Function 9 0-31 Function 10 0-31 Function 11 0-31...
- Page 10 Silver+ Locomotive decoder function output B: stands for function output A 0 No effect 0 No effect 1 Marslight 1 Marslight 2 Gyrolight 2 Gyrolight 3 Strobe 3 Strobe 4 Double strobe 4 Double strobe 0-255 Function mapping: lighting effect at function outputs A and B 0-255 Lighting effect at function outputs C and D.
- Page 11 Silver+ Locomotive decoder 0-31 Function 28 Function allocation coupling control forward Function output: Function allocation coupling control backward Function output: 0-255 Coupler kick duration: Can be set in multiples of 0.016 seconds. The default setting is 30x0.016 seconds = 0.48 seconds.
-
Page 12: North American Warranty
Silver+ Locomotive decoder North American Warranty Lenz GmbH does everything it can do to ensure that its products are free from defects and will operate for the life of your model railroad equipment. From time to time even the best engineered products fail either due to a faulty part or from accidental mistakes in installation.
