- Page 1 Gaming Case Series Quick User Guide...
-
Page 3: Table Of Contents
6. Install a 3.5”/2.5” HDD/SDD ......09 7. Care ............... 10 8. Options ............10 • Specifications Table ........... 12 Thank you for purchasing a Rosewill Computer Case Please read the instruction manual before using and retain it for your future reference. -
Page 4: Product Overview
Gaming Case METEOR XR Series Quick User Guide Product Overview Product Diagram (Components vary by country) Top Dust Filter 120 mm Fan Right Side Panel Left Side Panel 120 mm Fan Botton Dust Filter Front Panel Side I/O Pin-out USB 3.0 CONNECTOR... -
Page 5: Side I/O Diagram
Gaming Case METEOR XR Series Quick User Guide Side I/O Diagram Top I/O Diagram USB 3.0 USB 3.0 Reset Button Power Button Accessory Kit Image Part Name Function/Component Screw-A Screw-B Motherboard Screw-C 2.5” SSD Standoff Motherboard Nut Setter Standoff Cable Tie... -
Page 6: Installation Guide
Gaming Case METEOR XR Series Quick User Guide Installation Guide 1. Open the Unit 1-1. Remove the thumbscrews and take off panel R and L (Figure 1). -
Page 7: Install The Power Supply
Gaming Case METEOR XR Series Quick User Guide 2. Install the Power Supply 2-1 Seat the power supply unit (PSU) in the bottom-rear of the case and secure with Screw-A (Figure 2). 3. Install the Motherboard 3-1. Place the motherboard standoffs based on the form factor (Figure 3a). -
Page 8: Install The Add-On Card
Gaming Case METEOR XR Series Quick User Guide 3-2. Secure the motherboard down with Screw-B (Figure 3b). 4. Install the Add-on Card 4-1. Unscrew to remove the slot cover (Figure 4a). -
Page 9: Install An External 5.25" Device
Gaming Case METEOR XR Series Quick User Guide 4-2. Install the add-on card and secure with screws (Figure 4b). 5. Install an External 5.25” Device 5-1. Remove the front panel (Figure 5a). - Page 10 Gaming Case METEOR XR Series Quick User Guide 5-2. Remove the slot cover (Figure 5b). 5-3. Put back the front panel and insert the 5.25” drive (Figure 5c).
-
Page 11: Install A 3.5"/2.5" Hdd/Sdd
Gaming Case METEOR XR Series Quick User Guide 6. Install a 3.5”/2.5” HDD/SDD 6-1. Take out the 3.5” HDD tray/unscrew to remove the 2.5” SSD tray from the chassis (Figure 6a/6b). 6-2. Install the 3.5” HDD on the tool-less tray/secure 2.5”SSD on the tray with Screw-C (Figure 6c/6d/6e). -
Page 12: Care
Gaming Case METEOR XR Series Quick User Guide 7. Care To prevent damage, keep all panels closed and secured. 7-1. Put the side panels back in place and secure with thumbscrews. 7-2. Clean the dust filters on top/bottom regularly to ensure adequate airflow. - Page 13 Gaming Case METEOR XR Series Quick User Guide Instruction of installing 240/280 mm water cooling radiator on top: a. Remove the top dust filter. b. Secure the radiator with screws and put the dust filter back. (Figure 8b)
-
Page 14: Specifications Table
Gaming Case METEOR XR Series Quick User Guide Specifications Table Model Model Name METEOR XR Specifications Type ATX Mid Tower Color Black Case Material Steel / Plastic / Tempered Glass Power Supply Included Power Supply Mounted Bottom Motherboard Compatibility ATX, Micro ATX, Mini ITX... - Page 16 Technical Support Information techsupport@rosewill.com 1-800-575-9885 ---------------------------------------------------------------------------------- Thank you for purchasing a quality Rosewill product. Please register your product at : www.rosewill.com for complete warranty information and support for your product. METEOR XR Series_A...
