Application Guidelines

CDS803 frequency converter

B
D
b
Enclosure
Frame IP Class
H3 IP20
H4 IP20
H5 IP20
A Including decoupling plate.
1)
The dimensions are only for the physical units, but when installing in an application it is necessary to add space for free air passage both above and below the units. The amount
of space for free air passage is listed in "frequency converter dimensions - Clearance above/below (mm/inch)".
16
FRCC.PC.034.A2.02
Dimensions
Height (mm)
A A a
1)
255 329 240
296 359 275
334 402 314
e
e
Width (mm) Depth (mm)
B b C
100 74 206
135 105 241
150 120 255
Single compressors
99 99
Decoupling Plate
Decoupling Plate Illustration
Mounting hole (mm)
d e f
11 5.5 8.1
12.6 7 8.4
12.6 7 8.5
Max. Weight
kg
4.5
7.9
9.5
