Dimensions; Vzh028-035-044G/J Single Version; Vzh028-035-044G/J Manifold Version - Danfoss VZH028 Application Manuallines

Application Guidelines
VZH028-035-044G/J
single version
Discharge line
1/2"
(95.25)
129.5
(34°)
70.6
14
FRCC.PC.034.A2.02

Dimensions

Top of sensor bracket
Ø164.5
Suction
3/4"
360.4
404.4
Oil Sight Glass
1 1/8"
Schrader valve
and cover
230.5
78.0
55.0
11
239
190.5
Ø19.5
4X
109.7
14°±2°
(31°)
45°±2°
Terminal box (quick connect spade terminals)
Earth grounding
EMC bracket to
terminations of
shielded wire
VZH028-035-044G/J
manifold version
Ø164.5
Discharge line
1/2"
Oil level sensor
prism
42.5
239
190.5
(95.25)
129.5
(60°)
(34°)
Note: Manifolding drawing is preliminary version
Mounting Grommet
29.5
Recommended torque for
mounting bolts: 11 Nm (±1 Nm)
Single compressors
Overall height:
Top of sensor bracket
Suction line
3/4"
404.4
360.4
Organ pipe
tting
230.5
Schrader valve
and cover
78.0
55.0
11
Ø19.5
4X
109.7
Suction line
(17°)
111.3
discharge line
14°±2°
(31°)
45°±2°
All dimensions in mm
Ø11
Ø 41
