Generac Power Systems 004920-0 Owner's Manual page 37

10
9
15
10
26
7
11
ITEM PART NO. QTY.
1 0E4278 1
2 0A8785 1
3 0D8657 1
4 0D8660 2
5 0A7568 2
6 0D8659 1
7 0D8662 1
8 0D8661 1
9 0D8658 1
10 067042 2
11 0C2454 24
12 033121 3
13 051716 3
11
4
13
14 15
12 "Y"
11
17
"Y"
18
4
19
5
8
10
19
18
6
17
19
18
25
DESCRIPTION
ROOF COMPARTMENT PRO-
SOLUTIONS
PLUG BUTTON 3" DIA.
SUPPORT RADIATOR 1.5L MITSU
BRACE SIDE 1.5L MITSU
DOOR WELDMENT 1.5EPS
CORNER POST REAR RH SIDE 1.5L
DOOR REAR COMPARTMENT 1.5L
BRACE REAR 1.5L MITSU
CORNER POST REAR LH SIDE 1.5L
LATCH & CAM
SCREW TH-FRM M6-1 X 16 N WA Z/JS
SCREW HHC #10-32 X 1/2
NUT HEX M5-0.8 G8 YEL CHR
Section 7 - Exploded Views and Parts
Generac Liquid-cooled 20 kW Generator
Compartment — Drawing No. 0E4563-A
21
1
22
23
2
11
15
17
25
10
5
ITEM PART NO. QTY.
14 022152
15 0912970064
16 023762
17 0912970063
18 022264
19 067035
20 022127
21 0C2634A
22 022473
23 022097
24 056967
25 0D2023
26 0C2164
WELD STUD UNDER ROOF
PANEL FOR ACCESS COVER CABLE
24
3
17
NOTE:
USE DOOR LATCH
FASTENER TO SECURE
GROUND WIRE.
DESCRIPTION
3 WASHER LOCK #10
3 ASSMBLY BASE-DOOR GROUND WIRE
3 WASHER SHAKEPROOF EXT #10 STL
3 GRD WIRE ASS'Y 99HSB
6 WASHER LOCK #8-M4
6 SCREW PPHM #8-32 X 5/16
1 NUT HEX 1/4-20 STEEL
1 ASSEMBLY COVER ACCESS
1 WASHER FLAT 1/4 ZINC
1 WASHER LOCK M6-1/4
4 PLUG PLASTIC .375
1 GASKET CLIP-ON SELF GRIPPING
(252" LG)
1 LATCH AND CAM
Generac ® Power Systems, Inc. 35
