Zephyr Roma Groove Use, Care And Installation Manual page 20

Installation Instructions
3. Remove the baffle filters from the hood. Place
the charcoal filters to the back side of the
baffle filters. Secure the charcoal filters in
place with rubber clips or magnets, depending
on the filter design.
NOTE: Remove all of the black foam from the
filter opening before installing the charcoal
filters. (FIG. D)
4. Re-install the baffle filters. For more details
refer to manual included with recirculating kit.
5. Charcoal filters must be replaced after every
120 hours of use (or approximately every 3 to
4 months based on an average of 1 - 2 hrs. of
daily cooking time).
Charcoal Filter Replacements
Hood Model Part Number
ZRG Z0F-C005
DO NOT WASH CHARCOAL FILTERS. Charcoal
filters may need to be changed more often
depending on cooking habits.
20
Quantity to
Order
2
Roma Groove Use, Care, and Installation Guide
Clip Magnet
Clip
FIG. D
C O R E
R O M A G R O O V E
WA L L
Magnet
