CaptiveAire EWC Installation, Operation And Maintenance Manual page 42

1
11
10
Item Number
1
2
3
4
5
6
7
8
9
10
11
Figure 36 - Firestat
2
3
Table 13 - Firestat Components
Part Number
12-F28021-005360
Series 08-80
32-00002
32-00002
N/A
N/A
32-00002
32-00002
59361-1/2
100-BW
N/A
N/A
6
Description
Normally Open, Close on Rise @ 360°F
Normally Open, Close on Rise @ 360°F
1/2" NPT Quik Seal (Adapter Body)
1/2" NPT Quik Seal (Gasket)
Hood/Duct (External Surface)
1-1/8" – 1-1/4" Diameter Hole
1/2" NPT Quik Seal (Lock Washer)
1/2" NPT Quik Seal (Nut)
Extension Ring
Extension Ring Cover
2 White Wires
2 Black Wires
42
4
5
7
8
9
