3.10

Connecting to Data Gateway Interface

The Atmel-ICE supports a limited Data Gateway Interface (DGI) when debugging and programming is not in use.
Functionality is identical to that found on Microchip Xplained Pro kits powered by the Microchip EDBG device.
The Data Gateway Interface is an interface for streaming data from the target device to a computer. This is meant as
an aid in application debugging as well as for a demonstration of features in the application running on the target
device.
DGI consists of multiple channels for data streaming. The Atmel-ICE supports the following modes:
• USART
• SPI
Table 3-9. Atmel-ICE DGI USART Pinout
AVR Port SAM Port
3 6
4 1
8 7
9 8
2, 10 3, 5, 9
Table 3-10. Atmel-ICE DGI SPI Pinout
AVR Port
1
3
4
5
9
2, 10
Important: SPI and USART interfaces cannot be used simultaneously.
Important: DGI and programming or debugging cannot be used simultaneously.
©
2020 Microchip Technology Inc.
DGI USART Pin
TX
VTG
RX
CLK
GND
SAM Port DGI SPI Pin
4 SCK
6 MISO
1 VTG
2 nCS
8 MOSI
3, 5, 9 GND
Programmers and Debuggers
Connecting the Atmel-ICE
Description
Transmit pin from Atmel-ICE to the target device
Target voltage (reference voltage)
Receive pin from the target device to Atmel-ICE
USART clock
Ground
Description
SPI clock
Master In Slave Out
Target voltage (reference voltage)
Chip select active low
Master Out Slave In
Ground
