1/18-scale ready-tO-run Mini MOnster truck
Operation Manual
Before operating this vehicle, please read all printed
materials thoroughly.
CONNECT - REGISTER - WIN
Visit WWW.LOSI.COM and follow the product registration link to stay
connected.
For registering your Losi Product you will be automatically entered for
a chance to win the Losi Pick-Your-Prize Sweepstakes of $1,000 (retail
value) based on winner preference.
Not responsible for errors. All prices
subject to change without notice. Losi, a
Division of Horizon Hobby, Inc.
Advertisement
Table of Contents
Related Manuals for Team Losi Mini HIGHroller
Summary of Contents for Team Losi Mini HIGHroller
- Page 1 1/18-scale ready-tO-run Mini MOnster truck Operation Manual Before operating this vehicle, please read all printed materials thoroughly. CONNECT - REGISTER - WIN Visit WWW.LOSI.COM and follow the product registration link to stay connected. Not responsible for errors. All prices subject to change without notice. Losi, a For registering your Losi Product you will be automatically entered for Division of Horizon Hobby, Inc.
-
Page 2: Table Of Contents
If you are an experienced RC hobbyist, or new to RC vehicles, it will benefit you to read all enclosed information. If after review of this manual and prior to running your 1/18 Mini HIGHroller, you determine this RC vehicle is not what you want—DO NOT proceed and DO NOT run the 1/18 Mini HIGHroller. -
Page 3: Getting Started
Getting Started STEP 1 STEP 2 Plug the charger into the proper wall Remove the transmitter battery cover, install receptacle then the battery into the charger four (4) AA batteries (Pay close attention to and let it charge for 3 hours for the first time. the polarity of the positive (+) and negative (-) For subsequent charges allow 5 to 6 hours ends) and replace cover. - Page 4 STEP 4 STEP 5 Always turn on the transmitter first. Once the transmitter has been powered on, turn on HIGHroller The small red and green lights above the switch the Mini by sliding the switch on the should both light up. If not, you need to check for ESC to the “On”...
-
Page 5: Safety Precautions
This is a sophisticated radio controlled model that must be operated with caution and common sense. Failure to operate your Mini HIGHroller in a safe and responsible manner could result in damage to the model and property. The Mini HIGHroller is not intended for use by children without direct adult supervision. Losi and Horizon Hobby shall not be liable for any loss or damages, whether direct, indirect, special, incidental, or consequential, arising from the use, misuse, or abuse of this product or any product required to operate it. -
Page 6: Radio System Binding
Radio System Binding The Losi Radio System with Spektrum 2.4GHz DSM included in the Mini HIGHroller operates on a frequency of 2.4GHz, and provides 79 different “channels” which are automatically selected when the transmitter and vehicle are turned on. -
Page 7: Esc Setup
To track test, turn the Mini HIGHroller on and place it on the ground. As you push it backwards allowing it to roll freely, punch the throttle. - Page 8 This is really helpful when you are on slick, as well as high-traction surfaces. If your Mini HIGHroller turns too sharply and/or spins out easily, try turning the steering rate down by rotating the knob counterclockwise (to the left).
-
Page 9: Maintenance
Maintainence If you have any problems other than those covered in the troubleshooting section, please call the service department at (877) 504-0233. They will be able to give your specific problem additional attention and instruct you as to what needs to be done. - Page 10 This would be good for short layouts or when running hotter motors. The pinion on the Mini HIGHroller offers the best balance of both. To change the pinion, remove the gear cover, loosen the motor screws, and slide the motor back.
-
Page 11: Troubleshooting
1/18 MINI HIGHROLLER TROUBLESHOOTING GUIDE Symptom Possible Cause(s) Possible Solution(s) Battery not charged or plugged in Charge battery/plug in Doesn’t operate Receiver switch not “On” Turn on receiver switch Transmitter not “On” or low battery Turn on/replace batteries Pinion not meshing with spur gear... -
Page 12: Rebuilding/Refilling The Shocks
Rebuilding/Refilling the Shocks Step 1 Step 2 After removing the shock, Turn the shock upside down push up on the lower spring and remove the black shock cup and remove it from the cartridge/shaft assembly shaft. Remove the spring and from the shock body by preload spacers. -
Page 13: Warranty Information
Warranty Information the individual price of the Product on which liability is asserted. As Horizon has no control over use, setup, final assembly, modification or misuse, no liability shall be Age recommendAtion assumed nor accepted for any resulting damage or injury. 14 years or over. -
Page 14: Warranty Inspection And Repairs
WArrAnty insPection And rePAirs Germany: Electronics and engines requiring inspection or repair To receive warranty service, you must include your should be shipped to the following address: original sales receipt verifying the proof-of-purchase date. Provided warranty conditions have been met, your Product will be repaired or replaced free of charge. -
Page 15: Declaration Of Conformity
Champaign, IL 61822 USA declaration of conformity (in accordance with isO/iec 17050-1) no. HH20091129 Product(s): lOs 1/18 Mini HiGHroller rtr item number(s): lOsB0207 equipment class: The object of declaration described above is in conformity with the requirements of the specifications listed below, following the provisions of the european r&tte directive 1999/5/ec:... -
Page 16: Notes Sheet
Notes:... - Page 17 1/18-SCALE READY-TO-RUN MINI MONSTER TRUCK...
-
Page 18: Parts/Option Parts List
Replacement Parts Price List Option Parts lOsB0805 losi dsM transmitter lOsB0837 insane 370 BB motor lOsB0806 losi dsM receiver lOsB1013 track dots, neon Orange (12) lOsB0813 Ms20dsl servo with long lead lOsB1100 F/r Ball Bearing set (8) lOsB0826 Msc20rB electronic speed control lOsB1110 aluminum shock set lOsB1009... - Page 20 1/18-SCALE READY-TO-RUN MINI MONSTER TRUCK 2010 Losi, A division of Horizon Hobby, Inc. Not responsible for typographical errors. Printed 01/10 17369 The Spektrum trademark is used with permission of Bachmann Industries, Inc. Spektrum radios and accessories are exclusively available from Horizon Hobby, Inc. Printed in China...
