User's Guide
®
www.fetco.com
Model:
Hot Water Dispenser HWD_2102
With Portion Control
USERS GUIDE-Preliminary Edition
NOTICE TO INSTALLER: Please leave this book with the machine.
FETCO®, and Driven To Innovation™ are trademarks or trade names of Food Equipment Technologies Company.
© 2012 Food Equipment Technologies Company
May-2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HWD 2102 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fetco HWD 2102

Summary of Contents for Fetco HWD 2102

  • Page 1 Hot Water Dispenser HWD_2102 With Portion Control USERS GUIDE-Preliminary Edition NOTICE TO INSTALLER: Please leave this book with the machine. FETCO®, and Driven To Innovation™ are trademarks or trade names of Food Equipment Technologies Company. © 2012 Food Equipment Technologies Company May-2012...

  • Page 2: Fetco Hot Water Dispenser Hwd_2102

    FETCO Hot Water Dispenser HWD_2102 Contact Information FETCO Phone: (800) 338-2699 (US & Canada) ® Food Equipment Technologies Company (847) 719-3000 600 Rose Road Fax: (847) 719-3001 Lake Zurich • IL • 60047-0429 • USA Email: sales@fetco.com techsupport@fetco.com Internet: www.fetco.com Description &...
  • Page 3 CONTROL PANEL LAYOUT DIAGRAM FOR HWD_2102 HOT WATER DISPENSER Power Lamp (Unit is energized) Ready Lamp -Dispense will operate when lit, -Temperature is low when not lit Heating Lamp For hot water tank (is “ON” when heater is activated) Touch Function Selector selects and activates selected option Border of UNLOCK/DISPENSE pad will: glow white when ready to unlock...

  • Page 4: Cleaning And Maintenance

    Cleaning & Maintenance Daily: • Check the drip tray and empty if necessary. Quarterly: • Inspect all fittings and hoses for leaks. • Inspect inside of tank for lime deposits. De-lime tank and probes if necessary. (This procedure should be performed by a qualified service technician) Notice: •...

  • Page 5: Specifications

    Specifications For qualified service technicians Electrical Rating Chart Configuration Heater Electrical Maximum Flow Rate Voltage Phase Wires Code Configuration Connection Amp draw Per hour* DOMESTIC CONFIGURATION H210210 1 X 1.4 KW 100-120 single NEMA 5-15P 12.5 3.6 Gal/13.6 liters H210220 1 X 2.1 KW 100-120 single NEMA 5-20P...

  • Page 6: Installation

    The installation must comply with applicable federal, state, and local codes having jurisdiction at your location. Utilize only qualified beverage equipment service technicians for installation. A Service Company Directory may be found on our website, http://www.fetco.com. Warning: Legs are to be adjusted only to level the unit.
  • Page 7 HWD_2102 service setup and adjustment, temperature and portion control Two Upper Dials (Marked: S3 and S2 ) Temperature selection. Base temperature begins at 50°C/122°F, in Celsius units. Remove all screws and -Factory set, is 88°C/190°F panels to access control Add dial position numerical value in degrees Celsius board for adjustments.
  • Page 8 Problem with Water Supply -INITIAL FILL Power lamp–(steady) Hot water tank not filled in 6 minutes. READY lamp (1X) slower blinking Problem with water supply. HEATING lamp (2X) faster blinking Problem with fill valve. Touch Pad (INACTIVE) Problem with Water Supply -REFILL Hot Water Tank not filling or Power lamp–(steady)
  • Page 9 HWD_2102 Wiring Diagram...
  • Page 10 HWD_2102 Parts Drawing 1101.00121.00 HWD_2102 Hot Water Dispenser Parts Diagram...
  • Page 11 LABEL "FOR USE ON IND. CIRCUIT" 1029.00025.00 FOOT, ANTI-SLIP 1023.00155.00 PLUG, BOTTOM BASE, HWD-2100 1082.00065.00 SCREW #8-32 X 1 1/2", FLAT HD PH, 18-8 SS CORD, POWER Consult FETCO CONNECTOR, IEC POWER EN60320 C20, 0722 SERIES Consult FETCO BUSHING--CORD, POWER Consult FETCO...
  • Page 12 HWD_2102 Hot Water Tank Parts 1104.00034.00 TANK ASSEMBLY, HWD-2102 1114.00052.00 TANK WELDMENT, HWD-2102 1107.00014.00 HEATER ASSEMBLY, IMMERSION 1440W/120VAC 1107.00008.00 HEATER ASSEMBLY, IMMERSION 2100W/120VAC 1107.00015.00 HEATER ASSEMBLY, IMMERSION 3200W/240VAC 1013.00008.00 FITTING 3/8" HOSE ID WATER INLET/DRAIN 1003.00109.00 BRACKET, HEAT SINK 1059.00001.00 TRIAC 40A, 600V 1024.00014.00 O-RING, 1/2 X 3/32 CS, DASH # 112 1013.00011.00 NUT FOR 3/8 HOSE ID FITTING 1013.00070.00 FITTING 1/2"...
