Model:
Touchscreen Hot Water Dispenser HWB-2105
HW
B-2105 and HWB-2110 5 & 10 gallon per hour heavy-duty commercial hot water dispensers
NOTICE TO INSTALLER: Please leave this book with the machine.
Contact Information ........................................................2
Description & Features ...................................................2
Specifications..................................................................2
Electrical Rating Chart ....................................................2
Dimensions & Utility Connections...................................3
Operating Instructions ....................................................4
© 2014 Food Equipment Technologies Company
HWB-2100
USERS GUIDE-North America Edition
XTS
Table of Contents
FETCO®, XTS are trademarks or trade names of Food Equipment Technologies Company.
User's Guide
& HWB-2110
XTS
Accessing Service Screens and Controls ......................5
Error Codes ..................................................................10
Installation Instructions .................................................11
Safety Notes .................................................................12
Parts and Service drawings..........................................14
Wiring Diagrams ...........................................................23
P134 - North America Edition December 2014
XTS
Advertisement
Table of Contents
Related Manuals for Fetco HWB-2105 XTS
Summary of Contents for Fetco HWB-2105 XTS
-
Page 1: Table Of Contents
Safety Notes ..............12 Dimensions & Utility Connections........3 Parts and Service drawings..........14 Operating Instructions ............4 Wiring Diagrams ............23 FETCO®, XTS are trademarks or trade names of Food Equipment Technologies Company. © 2014 Food Equipment Technologies Company P134 – North America Edition December 2014... -
Page 2: Contact Information
HWB-2110 Output Capacity: At least 38 liters/10 gallons of 96°C/205°F temperature hot water per hour Commercial electrical requirements below Specifications FETCO HWB-2105 and HWB-2110 5 & 10 gallon per hour heavy-duty commercial hot water dispensers Capacities & Measurements Empty Filled... -
Page 3: Dimensions & Utility Connections
Dimensions & Utility Connections HWB-2105 DRG 1201.00015.00 HWB-2110 DRG 1201.00016.00... -
Page 4: Operating Instructions
Equipment in now ready to use. NOTE: For best results-leave the HWB “ON”. FETCO hot beverage equipment is well insulated and is designed to be left “ON” overnight. An optional, automatic digital power saver ECO Mode may be activated if desired Temperature is factory set for 205°F/96°. -
Page 5: Accessing Service Screens And Controls
Operator Access Screens, Continued Set Tank Temp. HWB-2100 205 °F TURN POWER ON _____________[]_ © 2015 All Rights Reserved Press and TURN POWER OFF hold to EXIT turn on Control screen to turn unit off or on ” “OFF” button turns unit “OFF Press and hold to progress to control screen (to right) to turn on the HWB-2100... - Page 6 Service Menu General Service Menu, Inputs Service Menu, Outputs Service Menu and Other Service Menu. -Enter Service Menu by accessing the power switch on back of the panel—switching into Power “OFF” state -After at least thirty seconds: Turn power switch “ON” -Touch and hold Upper HWB Logo to enter the programming screens.
- Page 7 All FETCO commercial hot beverage equipment have well insulated hot water tanks to limit energy consumption. Effective insulation increases equipment life and lowers building HVAC costs. FETCO has the best energy savings of all major suppliers.
- Page 8 Service Menu screens, continued: Second/Third Service Menu screen INPUTS & OUTPUTS Programming Factory set Programming Range INPUTS Notes Items Default (display) Level probe Low Level probe High Temp. Probe 1 Temp. Probe 1 • Input 205F Display Inputs Summery Temp. Probe 2 Temp.
- Page 9 Service Menu screens, continued: Fourth Service Menu screen: OTHER Programming Factory set Programming Range OTHER Notes Items Default (display) ERRORS Last 4 errors Error Codes • Display Errors (Codes) Chart is below (most recent at bottom) !!Errors must be Reset •...
-
Page 10: Error Codes
Error Codes Recommended Corrective Action for Description Remedy Service No error There was a problem with the internal SOFTWARE ERROR replace board program The internal data memory malfunction EE CRC WRONG replace board (EE CRC) TEMP SENSOR SHORT 1 50 Short circuit in temperature probe T1 Check board or probe TEMP SENSOR OPEN 1 51 Temperature probe circuit is open T1... -
Page 11: Installation Instructions
Installation Instructions Equipment Setup 1. Read User Guide noting all instructions. Review the dimensions for the unit you are installing. Verify that it will fit in the space intended for it. Verify that the counter or table will support the total weight of the equipment and any dispensers when filled. 2. -
Page 12: Safety Notes
Tank Set Temp. °F Ready Heating Filling HWB-2100 display on start-up Tank Set Temp. °F Ready Heating Filling HWB-2100 display” Ready” Screens shown in Final Setup #5 Final Setup 1. Turn on the incoming water supply line and inspect both inside and outside of the equipment for leaks in all fittings and tubes 2. - Page 13 Installation safety and hygiene directions 1. Access to the service area is restricted to persons having safety/hygiene knowledge and practical experience of the coffee brewer. This appliance must be installed in locations where it can be overseen by trained personnel. 2.
-
Page 14: Parts And Service Drawings
Parts and Service drawings Drawing 1101.00201(229)(217).00 HWB-2105 Complete Parts... - Page 15 HOSE CLAMP, NYLON BLACK, Ø1.25"-1.437" RANGE CLAMP 1025.00095.00 TUBE, 9/16 OD x 5/16 ID x 2.25 LG. 1001.00181.00 COVER FRONT, CBS-2100 XTS 1041.00021.00 LABEL FETCO, ETCHED GLASS TYPE, 10.375" L 1041.00022.00 LABEL, HWB-2105 1046.00036.00 LABEL,HOT WATER CAUTION, HWB-2100 1046.00035.00 LABEL, WARNING, HWB-2100...
- Page 16 HWB-2110 Complete Parts Drawing 1101.00202.00...
- Page 17 HOSE CLAMP, NYLON BLACK, Ø1.25"-1.437" RANGE CLAMP 1025.00095.00 TUBE, 9/16 OD x 5/16 ID x 2.25 LG. 1001.00181.00 COVER FRONT, CBS-2100 XTS 1041.00021.00 LABEL FETCO, ETCHED GLASS TYPE, 10.375" L 1041.00023.00 LABEL, HWB-2110 1046.00035.00 LABEL, WARNING, HWB-2100 1046.00036.00 LABEL,HOT WATER CAUTION, HWB-2100...
- Page 18 HWB-2105 Hot Water Tank Drawing 1104.00072(78)
- Page 19 HWB-2105 Hot Water Tank Drawing 1104.00072(78) PART NO DESCRIPTION 1114.00107.00 WELDMENT, TANK, HWB-2105 1024.00053.00 LEVEL AND TEMP PROBE GROMMET 1102.00234.00 PROBE ASSEMBLY, TEMP. AND LLC 12" LONG 1024.00050.00 GROMMET, SILICONE, 11.4mm ID 1023.00166.00 FITTING, COLD WATER INLET, GROMMET DESIGN 1003.00005.00 BRACKET, ONE SHOT THERMOSTAT 1053.00004.00 THERMOSTAT, SINGLE SHOT, 25A...
- Page 21 HWB-2110 Hot Water Tank Drawing 1104.00077(73).00 PART NO DESCRIPTION 1114.00111.00 WELDMENT TANK, HWB-2110 1024.00053.00 LEVEL AND TEMP PROBE GROMMET 1102.00234.00 PROBE ASSEMBLY, TEMP. AND LLC 12" LONG 1024.00050.00 GROMMET, SILICONE, 11.4mm ID 1023.00166.00 FITTING, COLD WATER INLET, GROMMET DESIGN 1023.00212.00 FITTING, VENTING BOX 1112.00336.00 PROBE WELDMENT, WATER LEVEL 4.00"...
- Page 22 1102.00248.00 ASSEMBLY BACK PANEL, HWB-2110 UL PART NO DESCRIPTION 1112.00317.00 WELDMENT BACK PANEL, HWB-2110 1086.00008.00 CONNECTOR, CABLE CLAMP, 3/4" 1058.00024.00 SWITCH, POWER, DOUBLE POLE, 16A, 125/250 VAC 1003.00170.00 BRACKET, GUARD 1081.00006.00 SPACER, 6MM OD x 3.2MM ID x 5MM LG, Z/P 1052.00001.00 POWER SUPPLY, 90-264VAC/24VDC, 1.8A 1029.00012.00...
-
Page 23: Wiring Diagrams
1102.00247.00 ASSEMBLY BACK PANEL, HWB-2105 UL PART NO DESCRIPTION 1112.00313.00 WELDMENT BACK PANEL, HWB-2105 1086.00008.00 Cable Back Connector ¾” 1058.00024.00 SWITCH, POWER, DOUBLE POLE, 16A, 125/250 VAC 1003.00170.00 BRACKET, GUARD 1081.00006.00 SPACER, 6MM OD x 3.2MM ID x 5MM LG, Z/P 1052.00001.00 POWER SUPPLY, 90-264VAC/24VDC, 1.8A 1029.00012.00...
