Fetco HWB-5 User Manual
Hide thumbs
Also See for HWB-5:
- Users manual and operator instructions (30 pages) ,
- User manual (16 pages) ,
- Installation (3 pages)
Advertisement
Quick Links
See also:
Installation
www.fetco.com
www.fetco.com
www.fetco.com
www.fetco.com
Hot Water Dispensers
Hot Water Dispensers
Hot Water Dispensers
Hot Water Dispensers
Contact Information ................................................... 2
Specifications............................................................. 2
Dimensions ................................................................ 3
Installation.................................................................. 4
FETCO®, and Driven To Pioneer Innovation™ are trademarks or trade names of Food Equipment Technologies Company.
© 2009 Food Equipment Technologies Company
All manuals and user guides at all-guides.com
Table of Contents
User's Guide
User's Guide
User's Guide
User's Guide
Maritime Versions
Maritime Versions
Maritime Versions
Maritime Versions
Operating Instructions.................................................6
Programming ..............................................................7
Wiring Diagrams .........................................................8
Parts .........................................................................10
Rated IP44
Rated IP44
Rated IP44
Rated IP44
Part # P113
REV. 001
Advertisement
Related Manuals for Fetco HWB-5
Summary of Contents for Fetco HWB-5
-
Page 1: Table Of Contents
Specifications............. 2 Programming ..............7 Dimensions ..............3 Wiring Diagrams ............8 Installation..............4 Parts .................10 FETCO®, and Driven To Pioneer Innovation™ are trademarks or trade names of Food Equipment Technologies Company. © 2009 Food Equipment Technologies Company Part # P113 REV. 001... -
Page 2: Contact Information
Hours: 7:00 AM - 6:00 PM Central, Monday - Friday 600 Rose Road Phone: (800) 338-2699 (US & Canada) (847) 719-3000 Lake Zurich • IL • 60047-0429 • USA Fax: (847) 719-3001 Internet: www.fetco.com Email: techsupport@fetco.com Specifications Specifications Specifications Specifications... -
Page 3: Dimensions
All manuals and user guides at all-guides.com Dimensions Dimensions Dimensions Dimensions HWB-5 HWB-10... -
Page 4: Installation
• Utilize only qualified beverage equipment service technicians for installation. A Service Company Directory may be found on our web site, http://www.fetco.com. Do not adjust the thermostat settings unless absolutely necessary. They are set at the factory for optimum •... - Page 5 All manuals and user guides at all-guides.com 3. A terminal block is provided for connecting the incoming power wires. Consult local codes to determine if a cord and plug can be installed, or if the unit must be hard wired. 4.
-
Page 6: Operating Instructions
All manuals and user guides at all-guides.com Operating Instructions Operating Instructions Operating Instructions Operating Instructions Turn the power switch to the ON position. The power switch will illuminate to indicate that the dispenser has power and is operating. When the ready light illuminates, the dispenser is fully up to temperature and ready to dispense hot water through the faucet. -
Page 7: Programming
Select the model and actual voltage to determine the correct %FV setting for step 5. Heater Actual Model Configuration Voltage Phase Setting HWB-5 1 X 3000 watt 1 ph. 1 ph. HWB-10 2 X 3000 watt 3 ph. 3 ph. factory setting... -
Page 8: Wiring Diagrams
All manuals and user guides at all-guides.com Wiring Diagrams Wiring Diagrams Wiring Diagrams Wiring Diagrams HWB-5... - Page 9 All manuals and user guides at all-guides.com HWB-10...
-
Page 10: Parts
All manuals and user guides at all-guides.com Parts Parts Parts Parts Figure 1 – HWB-5 – Main Assembly... - Page 11 LABEL GROUND 402141 HARNESS, LOW AMP, HWB-2005 22076 INSULATION, TANK BOTTOM, HWB-2005 402142 HARNESS, HIGH AMP, HWB-5, IP44, HALOGEN FREE 102223 ASSEMBLY, WATER LEVEL PROBE, HWB-2000, CBS-70'S 401370 WIR.DIAG., HWB-5, L1, L2+GRND,240VAC, 1 HTR 58086 BOOT, PROTECTIVE, NEON LAMP, IP44...
- Page 12 All manuals and user guides at all-guides.com Figure 2 – HWB-5 – Tank Assembly, Part # 104042 ITEM # PART # DESCRIPTION 004027 WELDMENT, TANK HWB-2005 53071 THERMOSTAT, SINGLE SHOT, 25A NOT AVAILABLE FOR SALE NOT AVAILABLE FOR SALE 31117 LOCKNUT 1/4"-18 NPT...
- Page 13 All manuals and user guides at all-guides.com Figure 3 – HWB-10 – Main Assembly...
- Page 14 All manuals and user guides at all-guides.com ITEM # PART # DESCRIPTION NOT AVAILABLE FOR SALE 104044 ASSEMBLY, TANK HWB-2010 (SEE FIG. 4) 22107 INSULATION, TANK BOTTOM, HWB-2010 102223 ASSEMBLY, WATER LEVEL PROBE, HWB-2000, CBS-70'S 102213 ASSEMBLY, DIGITAL TEMP. PROBE, 12.0"LG/34"LG WIRE 102222 ASSEMBLY, WATER LEVEL PROBE, HWB-2000 NOT AVAILABLE FOR SALE...
- Page 15 All manuals and user guides at all-guides.com Figure 4 – HWB-10 – Tank Assembly, Part # 104044 ITEM # PART # DESCRIPTION 004028 WELDMENT, TANK HWB-2010 53071 THERMOSTAT, SINGLE SHOT, 25A NOT AVAILABLE FOR SALE NOT AVAILABLE FOR SALE 31117 LOCKNUT 1/4"-18 NPT 107004 ASSEMBLY, HEATER, IMMERSION, 3000W/240VAC...
- Page 16 All manuals and user guides at all-guides.com...
