k) If one of these errors exists, the firmware will repeatedly attempt to perform this operation as long
as the controller remains in this mode. This allows you to insert (or modify and insert) an SD card
without having to reset the controller. Each time you insert the SD card, the operations in steps (e-
f) are repeated.
l) If the operation successfully completes, the parameterization data is saved.
PPdn indicating Port Parameterization Done is displayed on the front panel.
m) To return to normal operation, turn off power to the base, remove the controller from the base, set
Module Switch 4 to the O
n) On power up, the firmware performs subnet validation on the saved values. If valid, those values
are written into system parameter data and network parameters (IP Address and Subnet mask) is
displayed.

Janus Controller Configuration via Web Server

At this point, the Janus Controller should have valid network parameters that allow it to be configured via
the embedded web server. The web server can be accessed by typing the IP address of the controller into
the URL box of your browser and pressing the E
If the network settings were obtained from DHCP server, you should assign a fixed IP Address.
See Chapter 4 in the Janus Controller Installation and Operation Guide for information on controller
configuration.

Development Software

Janus Workbench Software (Order# 2500P-WB-USB) is required for application development and
configuration of communications in the Janus Controllers. Contact CTI for more information. Contact
information is listed at the bottom of this document.

Firmware Update

Prior to using the Janus Controller, you should verify that the controller firmware is current. The firmware
version number displayed in the Product Information page of the embedded web server.
The current firmware version is available on the CTI web site at the following link:
http://www.controltechnology.com/support/software-revision/
See Chapter 6 in the Janus Controller Installation and Operation Guide for information on updating
firmware.

Technical Assistance

If you need assistance from CTI please email CTI Technical Support at
contact call us at 865-584-0440 or 800-537-8398 (USA only).
Page 4
position, re-install the module into the base, and restore power.
PEN
key.
NTER
.
support@controltechnology.com
CTI Janus Controller Quick Start Guide (P/N 062-000471)
or
