Jarvis NBS-1 Operation And Maintenance Instructions

Table neck bone saw
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
0
EQUIPMENT
SELECTION
. . . . . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . .
Instrument Package
JARVIS
6207019:
Model NBS- -1
Table Neck Bone Saw
Ordering No.
4007046
1023473
. . . .
3025018
®
TABLE OF
CONTENTS
. . . . . . . . . . . . . . . . . . . . . . . . . . .
• Notice to Employer and Safety Director
• Notice to Operators, Maintenance and
Cleanup Personnel
• Major Components and Dimensions
. . . . . . . . . . . . . . . . . . . . . .
UNITED STATES OF AMERICA E--MAIL.
TEL. 860-347-7271
FAX. 860-347-6978
. . . . . . . . . . . . . . . . . .
. . .
. . . . . . . . . . . . . . .
. . . . . . . . . . . . . .
. . . . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . . . .
. . . . . . . . . . . .
jarvis.products.corp@snet.net
jarvisproducts.com
WWW.
Page
2
3
4
5
19
26
26
26
28
28

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NBS-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Jarvis NBS-1

Summary of Contents for Jarvis NBS-1

  • Page 1: Table Of Contents

    • Operation Instructions ....• Maintenance Instructions ... . JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net...

  • Page 2: Model Nbs--1

    9. Avoid injury. Do not permit the machine to be misused. 10. If you resell or distribute a Jarvis product, you must provide the purchaser with the appropriate safety sheets and machine brochure. Additional copies of safety sheets and machine brochures will be provided upon request.
  • Page 3 9. Never depress the start button(s) unless you want to use the machine. 10. Never make modifications or alterations to the machine. Replace any missing or illegible labels. JARVIS PRODUCTS CORPORATION ®...
  • Page 4 Lifting Blocks 29.3 " Right Side View Shown Without Side Guard 79.5 " " Note: Dimensions shown in inches. JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978...
  • Page 5 1032561 Side Support Plate 1059113 Hydraulic Hose Assy, 66 in 1055049 Socket Head Cap Screw 1059114 Hydraulic Hose Assy, 71 in JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX.
  • Page 6 1022066 Air Regulator with item 9 3011024 Rod Clevis with item 38 1055755 Hex Head Screw 1042444 Pivot Clamp Brkt. w/item 38 JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL.
  • Page 7 Idler Shaft 1055044 Hex Head Screw 1024244 Left Side Sprocket Guard 1024245 Left Side Sprocket Guard 1066007 Connecting Link JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978...
  • Page 8 Socket Head Cap Screw 1042578 Bracket 1007297 Hex Lock Nut 1007331* Hex Lock Nut 1020342 Shaft 1004286 Washer JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978 WWW.

  • Page 9: 12 Inch Blade

    Gearbox Assy (includes items 2--26, 28--41) 3008269 Motor and Gearbox Assy (incls. items 7--26, 28--41) 3016438 Gearbox Assy (includes items 7--26, 28, 29) JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL.
  • Page 10 15 Junction Box (not shown) 3025018 Instrument Assy (includes 3022087 Valve Manifold (includes items 1--9) items 13--24 and 26) JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX.
  • Page 11 1020334* Shaft Extension 1021487 Ball Bearing 1055492* Socket Set Screw, Cup Pt 1020388 Lead Screw Shaft 1006061* Knob JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978...
  • Page 12 1028140 Lift Mechanism Lever 1032603 Travel Stop Plate 1004462 Washer 1006061 Knurled Flat Knob 1007338 Hex Lock Nut 1055105 Knurled Head Screw JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX.
  • Page 13 Quick Connect Socket 1022263 Needle Valve 1059112* Hyd Hose Assy, 23 inch 1051059 Hex Pipe Nipple 1059117** Hyd Hose Assy, 48 inch JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX.
  • Page 14 Oil View Gage 1054166 Drain plug with Magnet 1034071 Suction Strainer 1034008 Suction Strainer 1061878 100 Gal Reservoir JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978...
  • Page 15 3063279 Rt. Mach. Junction Box 1055010 Pan Head Screw Assembly (items 1, 3--5, 7, 1004022 Internal Lock Washer 8, 12--16 and 19--26) JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL.
  • Page 16 Mounting Plate 1017085 Danger Label 1042471 Rail Terminal 1001146 White Jumper Wire 1 ft 1063496 Block Terminal JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978 WWW.
  • Page 17 Internal Lock Washer 1055490 Pan Head Screw 1072121 Contactor Relay 1042374 Terminal Rail 1017085 Danger Label 1063363 Terminal Marker JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978 WWW.
  • Page 18 1005151 Push Button Switch 1005147 Switch Operator 1016629 Plastic Enclosure 1005148 Contact Block 1011243 Strain Relief Connector JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978 WWW.

  • Page 19: Installation Information

    Model NBS--1 page 19 of 32 HYDRAULIC SCHEMATIC Figure 1 JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978 WWW.
  • Page 20 Model NBS--1 page 20 of 32 WIRING DIAGRAM Figure 2 JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978 WWW.
  • Page 21 Model NBS--1 page 21 of 32 WIRING DIAGRAM Figure 3 JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978 WWW.
  • Page 22 Model NBS--1 page 22 of 32 WIRING DIAGRAM Figure 4 JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978 WWW.
  • Page 23 Model NBS--1 page 23 of 32 WIRING DIAGRAM Figure 5 JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978 WWW.
  • Page 24 24 of 32 MOUNTING DIAGRAM Figure 6 Mount manifold horizontally not vertically Horizontal Vertical Manifold Support Figure 7 JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978...
  • Page 25 Carriage Power--On Button Right Start Button Stop Button Switch (Green) (Amber Light) Left Start Button (Green) Automatic/OFF/Manual Button JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL. 6207019: jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978...

  • Page 26: Specifications

    10) to 450 psi. vided on machine. Do not lift at table top or angle Note: Never exceed 500 psi. irons and floor grate (item 55, figure E, page 8). JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net...
  • Page 27 7.1 Unlatch adjustable draw latch (item 8, figure E, page 8). Figure 10 7.2 Lift either left or right side tunnel (item 20 or 36, figure E, page 8). JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL.

  • Page 28: Operation Instructions

    LOCKOUT/TAGOUT PROCEDURES are working correctly. Depress each START but- 1910.147) BEFORE PERFORMING ANY MAINTENANCE OR ton separately and the machine should not start. REPAIRS. JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL.
  • Page 29 1.2 Make sure that the dual anti-tie down start buttons to prevent blade from turning. Jarvis tool, part are working correctly. Depress each START but- number 8039174 (item 1, figure F, page 9) is pro- ton separately and the machine should not start.
  • Page 30 (item 29). semblies. 7.9 Remove screws (item 7) securing base plate (item 6.1.2 Add a light amount of Jarvis 1315 White 36) from slide bracket (item 9) or plate (item 38). Grease to outside surface of taper lock hub 8 SLIDE INSTALLATION: (item 30) before installing driver gear (item 29).
  • Page 31 Gear reducer is filled with oil at factory, and sealed for 9. See special notes below: life. If servicing is required, return unit to Jarvis. 10.1.1 If replacing floating linear bearing (item 25, 13.1.1 Align new roller chain sprocket (item 14) be- figure B, page 5), discard old bushings.
  • Page 32 (item 13) to push the roller chain sprocket (item 14) from sprocket hub (item 13). Pillow Block Bearing 15.11 Remove sprocket hub (item 13) and roller chain JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL.
